IFC-0603
Vishay Dale
High Q/SRF, Low Value Chip Inductors
FEATURES
High reliability
Surface mountable
High self-resonant frequency
2 % tolerance available
Temperature range: - 40 °C to + 125 °C (no load)
- 40 °C to + 85 °C (full rated current)
• Compliant to RoHS directive 2002/95/EC
•
•
•
•
•
STANDARD ELECTRICAL SPECIFICATIONS
L
100
MHz
(nH)
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
RATED
DC
DCR
SRF
100 800 1700 TYP. MAX. CURRENT
L
MHz MHz MHz (MHz)
(mA)
(Ω)
TOL.
0.3 nH
11
38
42 > 15 000 0.06
1000
0.3 nH
10
35
50 > 15 000 0.06
1000
0.3 nH
10
40
47
14 000 0.08
1000
0.3 nH
10
38
51
13 000 0.12
1000
5 %, 10 % 10
41
53
10 000 0.15
1000
5 %, 10 % 10
36
51
8000
0.20
500
5 %, 10 % 10
38
55
7000
0.21
500
5 %, 10 % 10
38
48
5100
0.29
500
5 %, 10 % 10
38
47
4900
0.32
500
5 %, 10 % 10
38
58
3700
0.35
500
5 %, 10 % 10
34
40
3600
0.42
500
5 %, 10 % 11
36
45
3200
0.50
500
5 %, 10 % 12
32
24
2600
0.60
400
5 %, 10 % 11
30
23
2500
0.75
400
Q TYPICAL
DIMENSIONS
in inches [millimeters]
D
B
C
A
MODEL
IFC-0603
A
B
C
D
0.063 ± 0.004 0.031 ± 0.004 0.020 ± 0.004 0.015 Max.
[1.60 ± 0.1]
[0.80 ± 0.1]
[0.50 ± 0.1] [0.38 Max.]
Note
• L, Q, SRF measured on HP-4291A and HP-8753D
PERFORMANCE GRAPHS: INDUCTANCE AND Q VS. FREQUENCY
100
90
80
70
60
50
40
30
20
10
0
10
100
INDUCTANCE (nH)
3.9
3.3
6.8
8.2
18
Q
10
8.2
6.8
3.9
3.3
18
100
1000
FREQUENCY (MHz)
10 000
1
10
1000
100
FREQUENCY (MHz)
10 000
DESCRIPTION
IFC-0603
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
F
PRODUCT
FAMILY
C
0
6
SIZE
0
3
E
R
1
0
INDUCTANCE
VALUE
N
J
TOL.
PACKAGE
CODE
Document Number: 34012
Revision: 10-Aug-06
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
1
