IDCS-5020
Vishay Dale
High Current, Shielded, Surface Mount Inductors
FEATURES
•
•
•
•
•
•
High energy storage
Low resistance
Magnetically shielded
Tape and reel packaging for automatic handling
Compliant to RoHS Directive 2002/95/EC
Halogen-free according to IEC 61249-2-21
definition
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 μH to 390.0 μH, tested at 1.0 V
RMS
Inductance Tolerance:
20 %, tighter tolerance available
upon request
Operating Temperature:
- 40 °C to + 125 °C
Resistance to Solder Heat:
260 °C for 10 s
MECHANICAL SPECIFICATIONS
Core:
Ferrite
Wire:
Enamelled copper wire
Base:
LCP
Terminals:
Nickel bronze
Adhesive:
Epoxy resin
DCR MAX. ()
0.021
0.022
0.032
0.039
0.054
0.075
0.101
0.150
0.207
0.334
0.472
0.210
0.340
0.380
0.420
0.460
0.520
0.700
0.800
1.100
1.200
1.400
I
SAT
(A)
5.6
5.2
5.0
3.9
3.2
2.8
2.4
2.0
1.6
1.4
1.0
0.95
0.90
0.85
0.80
0.70
0.60
0.65
0.50
0.45
0.40
0.35
I
RMS
(A)
5.0
4.5
3.8
3.3
2.7
2.2
2.0
1.5
1.3
1.1
0.80
0.90
0.82
0.75
0.68
0.60
0.55
0.50
0.45
0.40
0.35
0.33
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE (μH)
TOLERANCE
1.0
± 20 %
1.5
± 20 %
2.2
± 20 %
3.3
± 20 %
4.7
± 20 %
6.8
± 20 %
10
± 20 %
15
± 20 %
22
± 20 %
33
± 20 %
47
± 20 %
56
± 20 %
68
± 20 %
82
± 20 %
100
± 20 %
120
± 20 %
150
± 20 %
180
± 20 %
220
± 20 %
270
± 20 %
330
± 20 %
390
± 20 %
Notes
• Inductance drop = 10 % typ. at I
SAT
•
T
= 15 °C typ. at I
RMS
TEST FREQUENCY L (kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DIMENSIONS
in inches [millimeters]
A
Max.
B
Max.
D
Max.
E
G
F
H
J
I
A (Max.)
0.510 [12.95]
B (Max.)
0.370 [9.40]
D (Max.)
0.200 [5.08]
E
0.100 [2.54]
F
0.100 [2.54]
G
0.300 [7.62]
H
0.115 [2.92]
I
0.290 [7.37]
J
0.110 [2.79]
DESCRIPTION
IDCS-5020
MODEL
10 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
D
C
S
5
0
SIZE
2
0
E
R
1
0
INDUCTANCE
VALUE
0
M
INDUCTANCE
TOLERANCE
