EMM5329ZW
Single Pole Double Throw Switch
0.1 - 6 GHz Wireless LAN Transmit / Receive Applications
FEATURES
•
•
•
•
High Input P0.1dB: 33dBm
Low Insertion Loss: 0.55 dB at 6 GHz
GaAs PHEMT technology
Small size and low-cost SC-70 / SOT363 package
APPLICATIONS
•
•
•
802.11a,b,g Wireless LAN T/R switching
802.16d,e WiMAX T/R switching
UWB T/R switching
Lead(Pb) Free Package
2.0 mm x 2.1 mm x 1.0 mm
DESCRIPTION
EMM5329ZW is a single-pole double-throw (SP2T) GaAs PHEMT switch designed for WLAN transmit /
receive switching applications in the entire 802.11a,b,g frequency ranges.EMM5329ZW is ideally suited
for applications where high linearity, low control voltage, low insertion loss, small size, and low cost are
required. The device is in a low-cost, miniature 6-pin SOT-363/SC-70 package.
INDEX
RF1 1
6 V1
RF1 1
6
V1
GND
2
5 RFC
GND 2
5
RFC
RF2 3
4 V2
RF2 3
4
V2
Pin Configuration
(Top View)
Rev 0.2
January 31 , 2007
Function Block Diagram
1
Eudyna Devices Inc. Confidential
EMM5329ZW
Single Pole Double Throw Switch
0.1 - 6 GHz Wireless LAN Transmit / Receive Applications
ABSOLUTE MAXIMUM RATINGS
(Ambient Temperature Ta=25°C)
Parameter
DC Input Voltage
Input Power
Storage Temperature
Operating Case Temperature
Symbol
V1, V2
Pin
Tstg
Top
Rating
+6
+34
-40 to +150
-40 to +85
Unit
V
dBm
°C
°C
ELECTRICAL SPECIFICATIONS
(Case Temperature Tc=25°C, with off chip DC blocks)
Parameter
Frequency range
Control Voltage for V1, V2
Control Current (per line)
Input P- 0.1dB
Insertion Loss
Isolation
Return Loss
Symbol
F
Vhigh
Vlow
Icontrol
P0.1dB
I.L.
ISO
RL
High
Low
No RF, V1 or V2 = 3.0 V
Vhigh= 3.0V, Vlow= 0V
Freq = 0.5 - 2.5 GHz
Freq = 5.0 - 6.0 GHz
Freq = 0.5 - 2.5 GHz
Freq = 5.0 - 6.0 GHz
Freq = 0.5 - 2.5 GHz
16
16
15
15
31
Condition/comments
Min
0.1
2.5
-0.2
3.0
0
10
33
0.45
0.55
18
18
20
18
0.60
0.75
Typ
Max
6.0
3.6
+0.2
50
Unit
GHz
V
V
uA
dBm
dB
dB
dB
Freq = 5.0 - 6.0 GHz
(Unless otherwise specified Zsource=Zload=50
Ω
System, Tc=25°C)
TRUTH TABLE
V1
High
Low
V2
Low
High
RF1-RFC
ON
OFF
RF2-RFC
OFF
ON
Specifications are subject to change without notice.
Rev 0.2
January 31 , 2007
2
Eudyna Devices Inc. Confidential
EMM5329ZW
Single Pole Double Throw Switch
0.1 - 6 GHz Wireless LAN Transmit / Receive Applications
TYPICAL PERFORMANCE CURVES
Insertion Loss vs. Frequency
0.0
Insertion Loss[dB]
-0.2
-0.4
-0.6
-0.8
-22
Isolation[dB]
-10
-12
-14
-16
-18
-20
Isolation vs. Frequency
-1.0
0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
Freq.[GHz]
-24
0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
Freq.[GHz]
Return Loss vs. Frequency
0
-5
Return Loss[dB]
-10
-15
-20
-25
-30
0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
Freq.[GHz]
Insertion Loss[dB]
-0.3
-0.4
-0.5
-0.6
-0.7
-0.8
Insertion Loss vs. Pin
20
22
24
26
28
30
32
34
Pin[dBm] (V=3V/0V)
Rev 0.2
January 31 , 2007
3
Eudyna Devices Inc. Confidential
EMM5329ZW
Single Pole Double Throw Switch
0.1 - 6 GHz Wireless LAN Transmit / Receive Applications
Package Marking
CN01
Part No. Code
Year Code
Week Code
Year Code
Year
N
2006
O
2007
P
2008
R
2009
S
2010
T
2011
U
2012
PACKAGE DIMENSIONS
Dimension
Symbol
A
A1
A2
b
c
D
E
E1
e
Rev 0.2
January 31 , 2007
Min
-
0.025
0.85
0.15
0.10
1.90
1.25
Measurement (mm)
Nom
-
0.075
0.88
-
-
2.00
2.10 BSC
1.30
0.65 BSC
Max
1.00
0.10
0.90
0.30
0.20
2.10
1.35
4
Eudyna Devices Inc. Confidential
