284050-2 Product Details
Live Product Chat
Line Drawing
Terminal Block Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (12)
Product Feature Selector
C ontact Us About This Product
284050-2
T E I nternal N umber: 2 8 4 0 5 0 - 2
Product Highlights:
l
C onnector
l
C onnector Type = Plug (right-hand)
l
Housing C olor = Green
l
Not Side Stackable
l
Without Screw Flange
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
TERMINAL BLOC K VERTIC AL PLUG STAC KING, RIGHT HAND 10...
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
Terminal Block Stacking C onnectors
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= Plug (right-hand)
l
Number of Positions
= 2
l
Mount Angle
= Vertical
l
Screw Material = Brass
l
Screw Size = M3
Mechanical Attachment:
l
Screw Plating = Nickel
Electrical Characteristics:
l
Amperes (Amps.) = 15.0
l
Voltage (VAC ) = 600
Body Related Features:
l
Side Stackable
= No
l
C enterline (mm [in])
= 10.00 [0.394]
l
Wire Entry Diameter (Solid Wire) (mm?)
= 0.03 – 2.50
l
Wire Entry Diameter (Stranded Wire) (mm?)
= 0.03 – 1.50
l
Wire Entry Angle
= Side
l
Interlock
= Without
l
Wire Range (mm [AWG]) = 0.05-3.00 [30-12]
l
Flammability Rating = UL 94V-0
Contact Related Features:
l
Screw Flange
= Without
l
C ontact Base Material = Phosphor Bronze
l
C ontact Mating Area Plating Material = Tin
Housing Related Features:
l
Housing C olor
= Green
l
Housing Material = PA 6.6
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = Buchanan
Additional Information:
l
Product Line Information
