AYPG3113S-4A

Description
Dual Color LED Array, Yellow/green, Pastel Clear, 3.3mm,
CategoryLED optoelectronic/LED    photoelectric
File Size93KB，2 Pages
ManufacturerStanley Electric Co
Download Datasheet Parametric Compare View All

AYPG3113S-4A Overview

Dual Color LED Array, Yellow/green, Pastel Clear, 3.3mm,

AYPG3113S-4A Parametric

Parameter NameAttribute value
MakerStanley Electric Co
Reach Compliance Codeunknown
colorYELLOW/GREEN
Configuration4 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS
Maximum forward current0.03 A
Lens typePASTEL CLEAR
Nominal luminous intensity10.0 mcd
Installation featuresRADIAL MOUNT
Number of functions4
Number of terminals8
Optoelectronic device typesDUAL COLOR LED ARRAY
total height16.6 mm
method of packingBULK
peak wavelength580/560 nm
shapeROUND
size3.3 mm
surface mountNO
Terminal pitch2.5 mm

Preview

Download Datasheet
Product Guide
3113S-4A, 3MX4H, 3864X-SLM140-LP, and 3368S-1H Series
s
Outline Dimensions
3113S-4A Series
s
Outline Dimensions
3MX4H Series
4.45
3.9
φ
3.3
10.7
4.3
φ
3.3
14
13.97
17.8
16.6
10.16
12.7
20.3
6.35
2.54
2.3
0.5
2.5
6.22
3xP1.9
0.5
2.88
3xP1.9
7.6
1.02
1.02
2.5
1.4
2.3
1.4
Unit (mm)
2.5
Unit (mm)
s
3113S-4A Series
Type No.
Electro-Optical Characteristics and Absolute Max Rating
Lens
Color
Luminous
Intensity
IV
MIN.
TYP.
I
F
(Ta=25°C)
Material Emitted
Color
GaAsP
Yellow
Green
Orange
Green
Red
Green
Wave Length
Peak
λ
p
TYP.
Spectral Line
Dominant Half Width
λ
d
I
F
TYP
TYP.
Forward
Voltage
V
MAX.
F
Reverse Absolute Max
Current
IR
Rating
MAX.
V
R
I
F
Forward
Reverse
Current (I
F
) Voltage (V
R)
AYPG3113S-
4A
AAPG3113S-
4A
VRPG3113S-
4A
5
5
Pastel
Clear
10
10
10
10
10
10
mcd
20
20
20
20
20
20
mA
580
560
605
560
630
560
590
567
606
567
624
567
nm
20
20
20
20
20
20
mA
2.2 2.8
2.1 2.8
2.2 2.8
2.1 2.8
2.0 2.8
2.1 2.8
V
20 100
20 100
20 100
20 100
20 100
20 100
mA µA
4
4
4
4
4
4
V
30
25
25
25
30
25
mA
4
4
4
4
4
4
V
GaP
GaAsP
GaP
GaAsP
GaP
5
5
5
5
Units
Derate linerly from 25°C: AY & VR = 0.40 mA/°C, AA & PG = 0.33 mA/°C
s
3MX4H Series
Type No.
Electro-Optical Characteristics and Absolute Max Rating
Lens
Color
Luminous
Intensity
IV
MIN.
TYP.
I
F
(Ta=25°C)
Material Emitted
Color
GaAsP
Yellow
Green
Orange
Green
Red
Green
Wave Length
Peak
λ
p
TYP.
Spectral Line
Dominant Half Width
λ
d
I
F
TYP
TYP.
Forward
Voltage
V
MAX.
F
Reverse Absolute Max
Current
IR
Rating
MAX.
V
R
I
F
Forward
Reverse
Current (I
F
) Voltage (V
R)
AYPG3MX4H
GaP
GaAsP
AAPG3MX4H
GaP
GaAsP
VRPG3MX4H
GaP
5
5
White
Diffused
10
10
10
10
10
10
mcd
20
20
20
20
20
20
mA
580
560
605
560
630
560
590
567
606
567
624
567
nm
20
20
20
20
20
20
mA
2.2 2.8
2.1 2.8
2.2 2.8
2.1 2.8
2.0 2.8
2.1 2.8
V
20 100
20 100
20 100
20 100
20 100
20 100
mA µA
4
4
4
4
4
4
V
30
25
25
25
30
25
mA
4
4
4
4
4
4
V
5
5
5
5
Units
Derate linerly from 25°C: AY & VR = 0.40 mA/°C, AA & PG = 0.33 mA/°C

AYPG3113S-4A Related Products

AYPG3113S-4A AAPG3113S-4A VRPG3113S-4A AAPG3MX4H AYPG3MX4H
Description Dual Color LED Array, Yellow/green, Pastel Clear, 3.3mm, Dual Color LED Array, Orange/green, Pastel Clear, 3.3mm, Dual Color LED Array, Red/green, Pastel Clear, 3.3mm, Dual Color LED Array, Orange/green, White Diffused, 3.3mm, Dual Color LED Array, Yellow/green, White Diffused, 3.3mm,
Reach Compliance Code unknown unknown unknown unknown unknown
color YELLOW/GREEN ORANGE/GREEN RED/GREEN ORANGE/GREEN YELLOW/GREEN
Configuration 4 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS 4 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS 4 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS 4 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS 4 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS
Maximum forward current 0.03 A 0.025 A 0.03 A 0.025 A 0.03 A
Lens type PASTEL CLEAR PASTEL CLEAR PASTEL CLEAR WHITE DIFFUSED WHITE DIFFUSED
Nominal luminous intensity 10.0 mcd 10.0 mcd 10.0 mcd 10.0 mcd 10.0 mcd
Installation features RADIAL MOUNT RADIAL MOUNT RADIAL MOUNT RADIAL MOUNT RADIAL MOUNT
Number of functions 4 4 4 4 4
Number of terminals 8 8 8 8 8
Optoelectronic device types DUAL COLOR LED ARRAY DUAL COLOR LED ARRAY DUAL COLOR LED ARRAY DUAL COLOR LED ARRAY DUAL COLOR LED ARRAY
total height 16.6 mm 16.6 mm 16.6 mm 20.3 mm 20.3 mm
method of packing BULK BULK BULK BULK BULK
peak wavelength 580/560 nm 605/560 nm 630/560 nm 605/560 nm 580/560 nm
shape ROUND ROUND ROUND ROUND ROUND
size 3.3 mm 3.3 mm 3.3 mm 3.3 mm 3.3 mm
surface mount NO NO NO NO NO
Terminal pitch 2.5 mm 2.5 mm 2.5 mm 2.5 mm 2.5 mm
Base Number Matches - 1 1 1 1
