Multilayer Chip Inductors
Special Features
• Ceramic core, wirewound for superior reliability
• High self resonant frequency
• Very stable electrical characteristic
• Flat top surface for automated pick & place
• Operating temperature -40 to +125 °C
• Tape & reel packaged 10,000/reel
Part
Number
PM0402C-1N0-RC
PM0402C-2N0-RC
PM0402C-2N2-RC
PM0402C-3N3-RC
PM0402C-3N6-RC
PM0402C-3N9-RC
PM0402C-5N1J-RC
PM0402C-5N6J-RC
PM0402C-6N2J-RC
PM0402C-7N5J-RC
PM0402C-8N2J-RC
PM0402C-9N0J-RC
PM0402C-10NJ-RC
PM0402C-11NJ-RC
PM0402C-12NJ-RC
PM0402C-15NJ-RC
PM0402C-19NJ-RC
PM0402C-23NJ-RC
PM0402C-27NJ-RC
PM0402C-36NJ-RC
PM0402C-40NJ-RC
PM0402C-47NJ
L (nH)
±0.3
nH
1.0
2.0
2.2
3.3
3.6
3.9
±5 %
5.1
5.6
6.2
7.5
8.2
9.0
10
11
12
15
19
23
27
36
40
47
PM0402C Series
Test
Q Typ.
Q
Freq.
@900
Min (MHz)
(MHz)
16
16
19
19
19
19
20
20
20
22
22
22
21
24
24
24
24
24
24
24
24
20
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
77
54
59
65
45
50
56
54
52
60
57
62
50
52
53
55
50
49
49
44
44
38
SRF
(MHz)
Min.
6000
6000
6000
6000
6000
5800
5800
5800
5800
5800
4400
4160
3900
3680
3600
3280
3040
2720
2480
2320
2240
2100
DCR
Ω
Max.
0.045
0.070
0.070
0.066
0.066
0.066
0.083
0.083
0.083
0.104
0.104
0.104
0.195
0.120
0.120
0.172
0.202
0.214
0.298
0.403
0.438
0.830
I dc *
(mA)
1360
1040
960
840
840
840
800
760
760
680
680
680
480
640
640
560
480
400
400
320
320
150
Typical Applications
• Small cellular phones
• PDA
• Pagers
• Hand-held organizers
• High frequency wireless communication devices
• Laptop computers
• Network cards
• Industrial electronics
• Entertainment electronic devices
Notes
* Current to cause approx. 15 °C of temperature rise
0.66
Max.
0.46
0.64
Max.
0.66
1.19
Max.
0.36
Dimensions: mm
Pad Layout
Tel. (877) 426-8767 • Fax (951) 781-5006
4.2
www.bourns.com
REV. 06/07
