Type SF
Lighting Capacitors, 90 °C Rated, Oil Filled
AC Rated, Oil Filled/Impregnated, Metallized Polypropylene Capacitors
For better performance in HID Lighting and HV Ballasts,
Type SF oval and round oil filled metallized polypropylene
lighting capacitors are built for operating in the high tem
perature environments for high intensity discharge (HID) light
ing and other high voltage ballast applications. Each HID
catalog capacitor includes an external resistor that discharges
the capacitor to less than 50V in one minute, and the oil
filled process assures better reliability than dry capacitors.
Highlights
♦
♦
♦
♦
♦
Protected: UL recognized under E71645
Meets EIA Standard EIA-456-A
Resistors: Internal or external are optional
Casing: tin-plated steel standard, aluminum optional
Paint: (U.L. recognized) optional
5 µF to 55 µF
280 Vac to 525 Vac, other available
±3%
–25 °C, +90 °C with specials rated to +100 °C
Operating frequency: 50 - 60 Hz
Specifications
Outline Drawings
.81
± .06
D ±.06
Capacitance range:
Voltage range:
Capacitance Tolerance:
Temperature Range:
Operating Frequency:
.
81
± .06
B ± .06
H +.12
–.06
0.5 Max.
Dimensions (Inches)
Case Code
A
B
C
D
A
1.31
1.56
1.91
1.97
B
2.16
2.69
2.91
3.66
H
see Ratings
see Ratings
see Ratings
see Ratings
Case Code
P
S
T
D (Inches)
1.87
2.12
2.62
A ± .06
.50 Max
H + .12
- .06
H
see Ratings
see Ratings
see Ratings
Part Numbering System
SF
Series
SF
C
Case
A=
1 1/4" Oval
B=
1 1/2" Oval
C=
1 3/4" Oval
D=
2.0" Oval
P
= 1 3/4" Round
S
= 2.0" Round
33
AC Volt
24
= 240 Vac
28
= 280 Vac
30
= 300 Vac
33
= 330 Vac
40
= 400 Vac
48
= 480 Vac
22.5
Cap
C
Tol. ±%
1
Case Material
1
= Tin plated steel
2
= Painted steel
3
= Aluminum
F
No. of Tines
F=
2-tine + fork
2
= 2-tine
4
= 4-tine
R
Optional
R=
External Resistor
15
= 15.0 µF
A=
±10%
22.5
= 22.5 µF
B=
±6%
C=
±3%
Z
= Special
CDE Cornell Dubilier•1605 E. Rodney French Blvd.•New Bedford, MA 02744•Ph: (508)996-8561•Fax: (508)996-3830•
www.cde.com
Type SF
Lighting Capacitors, 90 °C Rated, Oil Filled
Ratings - Round Case Style
Cap.
(µF)
5.0
7.0
10.0
12.0
14.0
17.5
20.0
35.0
48.0
55.0
10.0
12.0
14.0
16.0
20.0
22.5
24.0
26.0
28.0
30.0
10.0
15.0
19.5
20.5
24.0
12.0
15.0
18.0
19.0
21.0
24.0
16.0
26.0
32.0
Ratings - Oval Case Style
Cap.
(µF)
5.0
7.0
10.0
12.0
14.0
17.5
20.0
35.0
48.0
55.0
10.0
12.0
14.0
16.0
20.0
22.5
24.0
26.0
28.0
30.0
10.0
15.0
19.5
20.5
24.0
12.0
15.0
18.0
19.0
21.0
24.0
16.0
26.0
32.0
Catalog
Case
H
Part Number
Code
(Inches)
Round 280 Vac 90 °C Case Temperature
SFP285C1FR
SFP287C1FR
SFP2810C1FR
SFP2812C1FR
SFP2814C1FR
SFP2817.5C1FR
SFP2820C1FR
SFP2835C1FR
SFP2848C1FR
SFS2855C1FR
SFP3010C1FR
SFP3012C1FR
SFP3014C1FR
SFP3016C1FR
SFP3020C1FR
SFP3322.5C1FR
SFP3324C1FR
SFP3326C1FR
SFP3328C1FR
SFP3330C1FR
SFP4010C1FR
SFP4015C1FR
SFP4019.5C1FR
SFP4020.5C1FR
SFP4024C1FR
SFP4812C1FR
SFP4815C1FR
SFP4818C1FR
SFP4819C1FR
SFP4821C1FR
SFP4824C1FR
SFS5216C1FR
SFT5226C1FR
SFT5232C1FR
P
P
P
P
P
P
P
P
P
S
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
S
T
T
2.38
2.38
2.38
2.38
2.38
2.38
2.88
2.88
3.88
2.88
2.38
2.38
2.38
2.38
2.38
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
3.72
2.88
2.88
2.88
2.88
2.88
3.75
2.88
3.91
3.91
Catalog
Case
H
Part Number
Code
(Inches)
Oval 280 Vac 90 °C Case Temperature
SFA285C1FR
SFA287C1FR
SFA2810C1FR
SFA2812C1FR
SFA2814C1FR
SFA2817.5C1FR
SFS2820C1FR
SFC2835C1FR
SFC2848C1FR
SFC2855C1FR
SFA3010C1FR
SFA3012C1FR
SFA3014C1FR
SFC3016C1FR
SFC3020C1FR
SFC3322.5C1FR
SFC3324C1FR
SFC3326C1FR
SFC3328C1FR
SFC3330C1FR
SFA4010C1FR
SFC4015C1FR
SFC4019.5C1FR
SFC4020.5C1FR
SFC4024C1FR
SFC4812C1FR
SFC4815C1FR
SFC4818C1FR
SFC4819C1FR
SFP4821C1FR
SFC4824C1FR
SFC5216C1FR
SFD5226C1FR
SFD5232C1FR
A
A
A
A
A
C
C
C
C
C
A
A
A
C
C
C
C
C
C
C
A
C
C
C
C
C
C
C
C
C
C
C
D
D
1.59
1.59
2.88
2.88
2.88
2.88
2.88
2.88
3.88
3.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
2.88
3.38
2.88
2.88
2.88
2.88
2.88
3.38
3.88
3.88
3.88
Round 300 Vac 90 °C Case Temperature
Oval 300 Vac 90 °C Case Temperature
Round 330 Vac 90 °C Case Temperature
Oval 330 Vac 90 °C Case Temperature
Round 400 Vac 90 °C Case Temperature
Oval 400 Vac 90 °C Case Temperature
Round 480 Vac 90 °C Case Temperature
Oval 480 Vac 90 °C Case Temperature
Round 525 Vac 90 °C Case Temperature
Oval 525 Vac 90 °C Case Temperature
Hardware and Brackets:
See Capacitor Hardware, page
5.000.
