MBRB4035CTTRLP

Description
Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, LEAD FREE, PLASTIC, SMD-220, D2PAK-3
CategoryDiscrete semiconductor    diode
File Size311KB，10 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric Compare View All

MBRB4035CTTRLP Overview

Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, LEAD FREE, PLASTIC, SMD-220, D2PAK-3

MBRB4035CTTRLP Parametric

Parameter NameAttribute value
MakerVishay
Parts packaging codeTO-263
package instructionLEAD FREE, PLASTIC, SMD-220, D2PAK-3
Contacts3
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresFREE WHEELING DIODE, HIGH RELIABILITY
applicationGENERAL PURPOSE
Shell connectionCATHODE
ConfigurationCOMMON CATHODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JESD-30 codeR-PSSO-G2
Maximum non-repetitive peak forward current210 A
Number of components2
Phase1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-65 °C
Maximum output current20 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Certification statusNot Qualified
Maximum repetitive peak reverse voltage35 V
surface mountYES
technologySCHOTTKY
Terminal formGULL WING
Terminal locationSINGLE

Preview

Download Datasheet
Bulletin PD-20051 rev. C 01/07
MBR4045CT
MBRB4045CT
MBR4045CT-1
SCHOTTKY RECTIFIER
40 Amp
I
F(AV)
= 40Amp
V
R
= 45V
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangular waveform
(Per Device)
I
FRM
@ T
C
= 118°C
(Per Leg)
V
RRM
I
FSM
@ tp = 5
μs
sine
V
F
T
J
@ 20 Apk, T
J
= 125°C
range
40
45
900
0.58
- 65 to 150
A
V
A
V
°C
Description/ Features
Units
A
This center tap Schottky rectifier has been optimized for low
reverse leakage at high temperature. The proprietary barrier
technology allows for reliable operation up to 150° C junction
temperature. Typical applications are in switching power
supplies, converters, free-wheeling diodes, and reverse bat-
tery protection.
150° C T
J
operation
Center tap TO-220, D
2
Pak and TO-262 packages
Low forward voltage drop
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
Values
40
Case Styles
MBR4045CT
MBRB4045CT
MBR4045CT-1
Base
Common
Cathode
2
Base
Common
Cathode
2
Base
Common
Cathode
2
1
Anode
2
Common
Cathode
3
1
Anode
Anode
2
Common
Cathode
3
1
Anode
Anode
2
Common
Cathode
3
Anode
TO-220AB
D
2
PAK
TO-262
Document Number: 93451
www.vishay.com
1

MBRB4035CTTRLP Related Products

MBRB4035CTTRLP MBR4035CT MBR4035CTPBF MBRB4035CTPBF MBRB4035CTTRR MBRB4035CTTRRP MBR4035CT-1 MBR4035CT-1PBF MBRB4035CTTRL MBRB4035CT
Description Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, LEAD FREE, PLASTIC, SMD-220, D2PAK-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, TO-220AB, PLASTIC PACKAGE-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, TO-220AB, LEAD FREE, PLASTIC PACKAGE-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, LEAD FREE, PLASTIC, SMD-220, D2PAK-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, PLASTIC, SMD-220, D2PAK-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, LEAD FREE, PLASTIC, SMD-220, D2PAK-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, TO-262AA, PLASTIC,TO-262, 3 PIN Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, TO-262AA, LEAD FREE, PLASTIC,TO-262, 3 PIN Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, PLASTIC, SMD-220, D2PAK-3 Rectifier Diode, Schottky, 1 Phase, 2 Element, 20A, 35V V(RRM), Silicon, PLASTIC, SMD-220, D2PAK-3
Parts packaging code TO-263 TO-220AB TO-220AB TO-263 TO-263 TO-263 TO-262AA TO-262AA TO-263 TO-263
package instruction LEAD FREE, PLASTIC, SMD-220, D2PAK-3 PLASTIC PACKAGE-3 LEAD FREE, PLASTIC PACKAGE-3 LEAD FREE, PLASTIC, SMD-220, D2PAK-3 PLASTIC, SMD-220, D2PAK-3 LEAD FREE, PLASTIC, SMD-220, D2PAK-3 R-PSIP-T3 LEAD FREE, PLASTIC,TO-262, 3 PIN PLASTIC, SMD-220, D2PAK-3 PLASTIC, SMD-220, D2PAK-3
Contacts 3 3 3 3 3 3 3 3 3 3
Reach Compliance Code unknown unknown compliant compliant unknown unknown unknown compliant unknown unknown
ECCN code EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99 EAR99
Other features FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY FREE WHEELING DIODE, HIGH RELIABILITY
application GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE GENERAL PURPOSE
Shell connection CATHODE CATHODE CATHODE CATHODE CATHODE CATHODE CATHODE CATHODE CATHODE CATHODE
Configuration COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS COMMON CATHODE, 2 ELEMENTS
Diode component materials SILICON SILICON SILICON SILICON SILICON SILICON SILICON SILICON SILICON SILICON
Diode type RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE
JESD-30 code R-PSSO-G2 R-PSFM-T3 R-PSFM-T3 R-PSSO-G2 R-PSSO-G2 R-PSSO-G2 R-PSIP-T3 R-PSIP-T3 R-PSSO-G2 R-PSSO-G2
Maximum non-repetitive peak forward current 210 A 210 A 210 A 210 A 210 A 210 A 210 A 210 A 210 A 210 A
Number of components 2 2 2 2 2 2 2 2 2 2
Phase 1 1 1 1 1 1 1 1 1 1
Number of terminals 2 3 3 2 2 2 3 3 2 2
Maximum operating temperature 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C 150 °C
Minimum operating temperature -65 °C -65 °C -65 °C -65 °C -65 °C -65 °C -65 °C -65 °C -65 °C -65 °C
Maximum output current 20 A 20 A 20 A 20 A 20 A 20 A 20 A 20 A 20 A 20 A
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE FLANGE MOUNT FLANGE MOUNT SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE IN-LINE IN-LINE SMALL OUTLINE SMALL OUTLINE
Certification status Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified
Maximum repetitive peak reverse voltage 35 V 35 V 35 V 35 V 35 V 35 V 35 V 35 V 35 V 35 V
surface mount YES NO NO YES YES YES NO NO YES YES
technology SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY SCHOTTKY
Terminal form GULL WING THROUGH-HOLE THROUGH-HOLE GULL WING GULL WING GULL WING THROUGH-HOLE THROUGH-HOLE GULL WING GULL WING
Terminal location SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE SINGLE
