Abrasion-Resistant Polyurethane Jacket
provides cold temperature flexibility and
high strength. Low smoke/zero halogen
material meets requirements for low
toxicity.
90% Tinned Copper Braid
is terminated
directly to connector with stainless steel
BAND-IT®
strap.
Watertight Overmold
provides strain
relief and protection.
Series 805 Harsh Environment Shielded Cordsets
These overmolded cordsets withstand abrasion and chemical exposure. Low smoke zero halogen jacket reduces the amount of
toxic and corrosive gasses emitted during combustion. Cable construction features silver coated stranded conductors with TFE
insulation, tinned copper braid shield and extruded polyurethane jacket. Choose single-ended pigtails or double-ended "back-
to-back" versions. Braid shield is attached directly to connector with
BAND-IT®
straps. Semi-rigid polyamide overmold provides
strain relief and environmental sealing.
Series 801 cordsets are now available with size #20HD, #16 and #12 contacts. Ordering information is found on the following
pages.
HARSH ENVIRONMENT CORDSET SPECIFICATIONS
Cable Jacket Material
Cable Shield
Conductors
BAND-IT®
Shield Termination Band
Current Rating
Test Voltage (Dielectric Withstanding Voltage)
Insulation Resistance
Operating Temperature
Solvent Resistance, Polyamide Overmold
Shielding Effectiveness
Cable jacket Flammability and Toxicity
Thermoplastic Polyurethane, Black, Low-Smoke, Zero-Halogen
Tin-Coated Copper Braid, 90% Minimum Coverage
Silver Coated Stranded Wire, TFE Insulated, Per M22759/11
Stainless Steel
#23 5 Amps, #20HD 7.5 Amps, #16 13 Amps, #12 23 Amps
#23 500 VAC, #20HD 750 VAC, #16 and #12 1800 VAC Sea Level
200 megohms minimum
-30° C. to +105° C.
Excellent Resistance to Most Solvents, Fuels, and Oils; Poor Resistance to
Strong Acids and Bipolar Solvents (Alcohol)
50 dB minimum from 100MHz to 1000MHz.
Toxicity Index 3.9 per NES 713
Oxygen Index 28% per ASTM D-2863
Smoke Index 24 per NES 711
H
© 2010 Glenair, Inc.
www.glenair.com
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
H-21
01-JANUARY-2010
Series 805
Series 805 Mighty Mouse Triple-Start
Overmolded Cordset Ordering Information
A
805-009
-B
B
C
D
E
F
G
H
J
K
L
M
Series 805
Series 805 Mighty Mouse Triple-Start
Overmolded Cordset Ordering Information
805-009 and 805-018
HOW TO ORDER 805-009 CORDSETS WITH #23 CONTACTS
Sample Part Number
A
End B
Connector
A
Plug, with Male
Pin Contacts
2
Wire
Size
2
M
Shell Material /
Finish
M
Nickel
8-4
P
A
-36
Series
805-009
Overmolded
Cordset,
Shielded,
with Low
Smoke/ Zero
Halogen
Jacket, with
Size #23
Contacts
End A
Connector
-A
Plug, with
Male Pin
Contacts
Insert Protective Shell
Arr.
Cover
Key Pos. Length
8-4
8-6
8-7
9-10
10-13
11-19
12-26
15-37
18-55
19-85
P
Metal
Protective
Covers
Included
A
Position A
(Normal)
#22 AWG
Aluminum / Electroless
Overall
Length In
Inches
12 Inch
Min
.
B
4
NF
Aluminum / Cadmium
with Olive Drab
Chromate
B
Position B
-B
Plug, with
Female
Socket
Contacts
Plug, with Female
#24 AWG
Socket Contacts
C
N
No Covers
Supplied
Position C
C
Receptacle,
with Male Pin
Contacts
ZNU
Aluminum / Zinc-Nickel
with Black Chromate
D
Position D
-C
Receptacle,
with Male
Pin Contacts
D
Receptacle, with
Female Socket
Contacts
MT
Aluminum / Nickel-
PTFE
Z1
Stainless Steel /
Passivated
-D
Receptacle,
with Female
Socket
Contacts
N
No Connector
(Single-Ended)
11-210HOW TO ORDER 805-018 CORDSETS WITH #20HD CONTACTS
Sample Part Number
805-018
Series
805-018
Overmolded
Cordset,
Shielded,
with Low
Smoke/ Zero
Halogen
Jacket, with
Size #20HD
Contacts
-A
End A
Connector
-A
Plug, with Male
Pin Contacts
N
End B
Connector
A
Plug, with Male
Pin Contacts
0
Wire
Size
0
#20
AWG
ZNU
Shell Material /
Finish
M
Aluminum / Electroless
Nickel
11-210
N
B
A
Position A
(Normal)
-72
Length
Overall
Length In
Inches
12 Inch
Min
.
Insert Protective Shell
Arr.
Cover
Key Pos.
P
8-23
Metal
9-25
Protective
10-28
Covers
11-210
Included
15-220
N
18-235
No Covers
19-241
Supplied
-B
Plug, with
Female Socket
Contacts
B
Plug, with Female
Socket Contacts
2
#22
AWG
NF
Aluminum / Cadmium
with Olive Drab
Chromate
B
Position B
C
Position C
C
Receptacle,
with Male Pin
Contacts
ZNU
Aluminum / Zinc-Nickel
with Black Chromate
D
Position D
-C
Receptacle,
with Male Pin
Contacts
MT
Aluminum / Nickel-
PTFE
D
Receptacle, with
Female Socket
Contacts
-D
Receptacle,
with Female
Socket
Contacts
Z1
Stainless Steel /
Passivated
N
No Connector
(Single-Ended)
© 2010 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
H-22
09-JULY-2010
E-Mail: sales@glenair.com
805-015 and 805-016
HOW TO ORDER 805-015 CORDSETS WITH #16 CONTACTS
805-015
Series
805-015
End A
Connector
Plug, with
Male Pin
Contacts
Plug, with
Female
Socket
Contacts
Receptacle,
with Male
Pin Contacts
Receptacle,
with Female
Socket
Contacts
-B
End B
Connector
Plug, with Male
Pin Contacts
A
Wire
Size
6
8
6
Sample Part Number
Shell Material /
Finish
M
M
19-14
Insert Protective Shell
Arr.
Cover
Key Pos. Length
8-1
10-2
11-4
11-19
12-5
15-7
18-12
19-14
Metal
Protective
Covers
Included
P
A
-36
Overmolded
Cordset,
Shielded,
with Low
Smoke/ Zero
Halogen
Jacket, with
Size #16
Contacts
-A
A
B
C
#16 AWG
Aluminum / Electroless
P
Nickel
Position A
(Normal)
Position B
Position C
Position D
A
B
C
D
Overall
Length In
Inches
12 Inch
Min
.
-B
Plug, with Female
#18 AWG
Socket Contacts
Receptacle,
with Male Pin
Contacts
Receptacle, with
Female Socket
Contacts
No Connector
(Single-Ended)
Aluminum / Cadmium
with Olive Drab
Chromate
Aluminum / Zinc-Nickel
with Black Chromate
Aluminum / Nickel-
PTFE
Stainless Steel /
Passivated
NF
ZNU
MT
Z1
No Covers
Supplied
N
-C
D
-D
N
HOW TO ORDER 805-016 CORDSETS WITH #12 CONTACTS
805-016
Series
805-016
End A
Connector
Plug, with Male
Pin Contacts
Plug, with
Female Socket
Contacts
Receptacle,
with Male Pin
Contacts
Receptacle,
with Female
Socket
Contacts
-A
-A
-B
End B
Connector
Plug, with Male
Pin Contacts
Plug, with Female
Socket Contacts
Receptacle,
with Male Pin
Contacts
Receptacle, with
Female Socket
Contacts
No Connector
(Single-Ended)
N
A
B
C
Wire
Size
#12
AWG
#14
AWG
2
2
4
Sample Part Number
Shell Material /
Finish
Aluminum / Electroless
Nickel
Aluminum / Cadmium
with Olive Drab
Chromate
Aluminum / Zinc-Nickel
with Black Chromate
Aluminum / Nickel-
PTFE
Stainless Steel /
Passivated
ZNU
M
12-2
9-1
12-2
15-2
15-3
18-5
19-7
Insert Protective Shell
Arr.
Cover
Key Pos.
Metal
Protective
Covers
Included
No Covers
Supplied
N
P
B
A
B
C
D
-72
Length
Overall
Length In
Inches
12 Inch
Min
.
H
Overmolded
Cordset,
Shielded,
with Low
Smoke/ Zero
Halogen
Jacket, with
Size #12
Contacts
NF
Position A
(Normal)
Position B
Position C
Position D
ZNU
MT
Z1
N
-C
D
-D
N
© 2010 Glenair, Inc.
www.glenair.com
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
H-23
01-JANUARY-2010
Series 805
Series 805 Mighty Mouse Triple-Start
Overmolded Cordset Ordering Information
A
A MAX.
B
C
D
E
C MAX.
F
E
MAX.
G
H
K
L
M
© 2010 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
Series 805
B MAX.
SERIES 805 PLUG
D
MAX.
Series 805 Mighty Mouse Triple-Start Threaded
Overmolded Corset Dimensions
LENGTH
+ 2.0/-0.0 (+50.8/ -0.0)
12 IN. (300 mm.) MIN.
POLYAMIDE
OVERMOLDED STRAIN
RELIEF
SHIELDED JACKETED
CABLE
SERIES 805
RECEPTACLE
OPTIONAL
PROTECTIVE COVER
WITH POLYURETHANE
WIRE ROPE
RIGHT ANGLE CORDSETS
LENGTH + 2.0/-0.0 (+50.8/ -0.0)
12 IN. (300 mm.) MIN.
MASTER
KEY
LOCATED 180°
FROM CABLE EXIT
How To Order Right Angle Cordsets
Insert the letter “R” after the End A or End B
Connector letter designator.
Example
Straight cable 805-009-AC4NF18-55PA-72
Right Angle
805-009-ARCR4NF18-55PA-72
DIMENSIONS
J
Shell
Size
8
9
10
11
12
15
18
19
A Max.
In.
mm.
2.4
2.4
2.5
2.8
2.8
3.1
3.4
3.9
61.0
61.0
63.5
71.1
71.1
78.7
86.4
99.1
B Max.
In.
mm.
0.6
0.7
0.8
0.9
0.9
1.1
1.3
1.4
15.2
17.8
19.1
21.6
21.6
28.0
33.0
35.6
C Max.
In.
mm.
1.5
1.5
1.6
1.9
1.9
2.2
2.5
3.0
38.1
38.1
40.6
48.3
48.3
55.9
63.5
76.2
D Max.
In.
mm.
0.6
0.7
0.8
0.9
0.9
1.1
1.3
1.4
15.2
17.8
19.1
21.6
21.6
28.0
33.0
35.6
E Max.
In.
mm.
2.1
2.3
2.4
2.6
2.6
3.1
3.5
3.7
53.3
58.4
61.0
66.0
66.0
78.7
88.9
94.0
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
01-JANUARY-2010
H-24
E-Mail: sales@glenair.com
