Produktdatenblatt | Version 1.1
LY E65B
www.osram-os.com
LY E65B
Power TOPLED
®
Lens
PowerTOPLED with lens, a powerful member of
the TOPLED family. Thanks to their high luminous
efficacy, the LEDs are ideal for rear light clusters
and indicators on vehicles and for display panels for
traffic control systems.
Applications
—
Interior Illumination (e.g. Ambient Map)
—
Signalling
—
Traffic Lights
Features:
—
Package: white PLCC-4 package, colorless clear resin
—
Chip technology: InGaAlP
—
Typ. Radiation: 60°
—
Color:
λ
dom
= 587 nm (● yellow)
—
Corrosion Robustness Class: 3B
—
ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
1
Version 1.3
| 2018-09-21
LY E65B
Ordering Information
Type
Luminous Intensity
1)
I
F
= 50 mA
I
v
1120 ... 3550 mcd
Ordering Code
LY E65B-AACA-26-1
Q65110A2354
2
Version 1.3
| 2018-09-21
LY E65B
Maximum Ratings
Parameter
Operating Temperature
Storage Temperature
Junction Temperature
Forward current
T
S
= 25 °C
Surge Current
t ≤ 10 µs; D = 0.005 ; T
S
= 25 °C
Reverse voltage
2)
T
S
= 25 °C
ESD withstand voltage
acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
Symbol
T
op
T
stg
T
j
I
F
I
FS
V
R
V
ESD
min.
max.
min.
max.
max.
max.
max.
max.
Values
-40 °C
100 °C
-40 °C
100 °C
125 °C
70 mA
100 mA
12 V
2 kV
3
Version 1.3
| 2018-09-21
LY E65B
Characteristics
I
F
= 50 mA; T
S
= 25 °C
Parameter
Peak Wavelength
3)
Dominant Wavelength
3)
I
F
= 50 mA
Spectral Bandwidth at 50% I
rel,max
Viewing angle at 50 % I
V
Forward Voltage
4)
I
F
= 50 mA
Reverse current
2)
V
R
= 12 V
Temperature Coefficient of Peak Wavelength
-10°C ≤ T ≤ 100°C
Temperature Coefficient of Dominant Wavelength
-10°C ≤ T ≤ 100°C
Temperature Coefficient of Forward Voltage
-10°C ≤ T ≤ 100°C
Real thermal resistance junction/solderpoint
5)
Symbol
λ
peak
λ
dom
typ.
min.
typ.
max.
typ.
typ.
min.
typ.
max.
typ.
max.
typ.
typ.
typ.
typ.
max.
Values
594 nm
580 nm
587 nm
595 nm
15 nm
60 °
1.90 V
2.20 V
2.50 V
0.01 µA
10 µA
0.13 nm / K
0.1 nm / K
-3.7 mV / K
110 K / W
130 K / W
∆λ
2φ
V
F
I
R
TC
λpeak
TC
λdom
TC
VF
R
thJS real
4
Version 1.3
| 2018-09-21
LY E65B
Brightness Groups
Group
Luminous Intensity
1)
I
F
= 50 mA
min.
I
v
1120 mcd
1400 mcd
1800 mcd
2240 mcd
2800 mcd
Luminous Intensity.
1)
I
F
= 50 mA
max.
I
v
1400 mcd
1800 mcd
2240 mcd
2800 mcd
3550 mcd
Luminous Flux
6)
I
F
= 50 mA
typ.
Φ
V
1590 mlm
2020 mlm
2560 mlm
3190 mlm
4020 mlm
AA
AB
BA
BB
CA
Forward Voltage Groups
Group
Forward Voltage
4)
I
F
= 50 mA
min.
V
F
1.90 V
2.05 V
2.20 V
2.35 V
Forward Voltage
4)
I
F
= 50 mA
max.
V
F
2.05 V
2.20 V
2.35 V
2.50 V
3A
3B
4A
4B
Wavelength Groups
Group
Dominant Wavelength
3)
I
F
= 50 mA
min.
λ
dom
580 nm
583 nm
586 nm
589 nm
592 nm
Dominant Wavelength
3)
I
F
= 50 mA
max.
λ
dom
583 nm
586 nm
589 nm
592 nm
595 nm
2
3
4
5
6
5
Version 1.3
| 2018-09-21
