Z: Tape and reel packing (picked from the 6/7/8/9/10-pin side)
Notes: 1. *48 V coil type: Single side stable only
2. In case of 5 V transistor drive circuit, it is recommended to use 4.5 V type relay.
–1–
ASCTB14E 201407-T
TQ
TYPES
■
Standard PC board terminal and self-clinching terminal
1. Standard (B.B.M.) type
1) Standard PC board terminal
Contact
arrangement
Nominal coil
voltage
3 V DC
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
48 V DC
Single side stable
Part No.
TQ2-3V
TQ2-4.5V
TQ2-5V
TQ2-6V
TQ2-9V
TQ2-12V
TQ2-24V
TQ2-48V
1 coil latching
Part No.
TQ2-L-3V
TQ2-L-4.5V
TQ2-L-5V
TQ2-L-6V
TQ2-L-9V
TQ2-L-12V
TQ2-L-24V
—
2 coil latching
Part No.
TQ2-L2-3V
TQ2-L2-4.5V
TQ2-L2-5V
TQ2-L2-6V
TQ2-L2-9V
TQ2-L2-12V
TQ2-L2-24V
—
2 Form C
Standard packing (2 Form C): Tube: 50 pcs.; Case: 1,000 pcs.
2) Self-clinching terminal
Contact
arrangement
Nominal coil
voltage
3
V DC
4.5 V DC
5 V DC
6 V DC
9
12
24
48
V DC
V DC
V DC
V DC
Single side stable
Part No.
TQ2H-3V
TQ2H-4.5V
TQ2H-5V
TQ2H-6V
TQ2H-9V
TQ2H-12V
TQ2H-24V
TQ2H-48V
1 coil latching
Part No.
TQ2H-L-3V
TQ2H-L-4.5V
TQ2H-L-5V
TQ2H-L-6V
TQ2H-L-9V
TQ2H-L-12V
TQ2H-L-24V
—
2 coil latching
Part No.
TQ2H-L2-3V
TQ2H-L2-4.5V
TQ2H-L2-5V
TQ2H-L2-6V
TQ2H-L2-9V
TQ2H-L2-12V
TQ2H-L2-24V
—
2 Form C
Note: Types (“-3” to the end of part No.) designed to withstand strong vibration caused, for example, by the use of terminal cutters, can also be ordered.
However, please contact us if you need parts for use in low level load.
2. M.B.B. type
1) Standard PC board terminal
Contact arrangement
Nominal coil voltage
3 V DC
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
Single side stable
Part No.
TQ2-2M-3V
TQ2-2M-4.5V
TQ2-2M-5V
TQ2-2M-6V
TQ2-2M-9V
TQ2-2M-12V
TQ2-2M-24V
2 Form C
Standard packing: Tube: 50 pcs.; Case: 1,000 pcs.
2) Self-clinching terminal
Contact arrangement
Nominal coil voltage
3 V DC
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
Single side stable
Part No.
TQ2H-2M-3V
TQ2H-2M-4.5V
TQ2H-2M-5V
TQ2H-2M-6V
TQ2H-2M-9V
TQ2H-2M-12V
TQ2H-2M-24V
2 Form C
Standard packing: Tube: 50 pcs.; Case: 1,000 pcs.
Notes: 1. Latching types are available by request. Please consult us for details.
3. Types (“-1” to the end of part No.) designed to withstand strong vibration caused, for example, by the use of terminal cutters, can also be ordered.
However, please contact us if you need parts for use in low level load and low thermal power.
–2–
ASCTB14E 201407-T
TQ
■
Surface-mount terminal
1) Tube packing
Contact
arrangement
Nominal coil
voltage
1.5 V DC
3 V DC
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
48 V DC
Single side stable
Part No.
TQ2S -1.5V
TQ2S -3V
TQ2S -4.5V
TQ2S -5V
TQ2S -6V
TQ2S -9V
TQ2S -12V
TQ2S -24V
TQ2S -48V
1 coil latching
Part No.
TQ2S -L-1.5V
TQ2S -L-3V
TQ2S -L-4.5V
TQ2S -L-5V
TQ2S -L-6V
TQ2S -L-9V
TQ2S -L-12V
TQ2S -L-24V
—
2 coil latching
Part No.
TQ2S -L2-1.5V
TQ2S -L2-3V
TQ2S -L2-4.5V
TQ2S -L2-5V
TQ2S -L2-6V
TQ2S -L2-9V
TQ2S -L2-12V
TQ2S -L2-24V
—
2c
: For each surface-mounted terminal identification, input the following letter. SA type: A, SL type: L, SS type: S
Standard packing: Tube: 50 pcs.; Case: 1,000 pcs.
2) Tape and reel packing
Contact
arrangement
Nominal coil
voltage
1.5 V DC
3 V DC
4.5 V DC
5 V DC
2 Form C
6
9
12
24
48
V DC
V DC
V DC
V DC
V DC
Single side stable
Part No.
TQ2S -1.5V-Z
TQ2S -3V-Z
TQ2S -4.5V-Z
TQ2S -5V-Z
TQ2S -6V-Z
TQ2S -9V-Z
TQ2S -12V-Z
TQ2S -24V-Z
TQ2S -48V-Z
1 coil latching
Part No.
TQ2S -L-1.5V-Z
TQ2S
TQ2S
TQ2S
TQ2S
TQ2S
TQ2S
-L-3V-Z
-L-4.5V-Z
-L-5V-Z
-L-6V-Z
-L-9V-Z
-L-12V-Z
2 coil latching
Part No.
TQ2S -L2-1.5V-Z
TQ2S
TQ2S
TQ2S
TQ2S
TQ2S
TQ2S
-L2-3V-Z
-L2-4.5V-Z
-L2-5V-Z
-L2-6V-Z
-L2-9V-Z
-L2-12V-Z
TQ2S -L-24V-Z
—
TQ2S -L2-24V-Z
—
: For each surface-mounted terminal identification, input the following letter. SA type: A, SL type: L, SS type: S
Standard packing: Tape and reel: 500 pcs.; Case: 1,000 pcs.
Note: Tape and reel packing symbol “-Z” is not marked on the relay. “X” type tape and reel packing (picked from 1/2/3/4-pin side) is also available.
RATING
■
Standard PC board terminal and self-clinching terminal
1. Coil data
[Standard (B.B.M.) type]
1) Single side stable (2 Form C)
Nominal coil
voltage
3
V DC
Pick-up voltage
(at 20°C
68°F)
Drop-out voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
46.7 mA
31.1
28.1
23.3
15.5
11.7
8.3
mA
mA
mA
mA
mA
mA
Coil resistance
[±10%] (at 20°C
68°F)
64.3
Ω
144.6
Ω
178
Ω
257
Ω
579
Ω
1,028
Ω
2,880
Ω
7,680
Ω
Nominal operating
power
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
48
V DC
140 mW
75%V or less of
nominal voltage*
(Initial)
10%V or more of
nominal voltage*
(Initial)
150%V of
nominal voltage
200 mW
300 mW
120%V of
nominal voltage
6.25 mA
2) 1 coil latching (2 Form C)
Nominal coil
voltage
3
V DC
75%V or less of
nominal voltage*
(Initial)
75%V or less of
nominal voltage*
(Initial)
Set voltage
(at 20°C
68°F)
Reset voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
33.3 mA
22.2 mA
20 mA
16.7 mA
11.1 mA
8.3 mA
6.3 mA
Coil resistance
[±10%] (at 20°C
68°F)
90
Ω
202.5
Ω
250
Ω
360
Ω
810
Ω
1,440
Ω
3,840
Ω
Nominal operating
power
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
100 mW
150%V of
nominal voltage
150 mW
–3–
ASCTB14E 201407-T
TQ
3) 2 coil latching (2 Form C)
Nominal coil
voltage
3
V DC
Set voltage
(at 20°C
68°F)
Reset voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
Set coil
Reset coil
66.7 mA
44.4 mA
40 mA
33.3 mA
22.2 mA
16.7 mA
12.5 mA
66.7 mA
44.4 mA
40 mA
33.3 mA
22.2 mA
16.7 mA
12.5 mA
Coil resistance
[±10%] (at 20°C
68°F)
Set coil
45
Ω
101.2
Ω
125
Ω
180
Ω
405
Ω
720
Ω
1,920
Ω
Reset coil
45
Ω
150%V of
nominal voltage
101.2
Ω
125
Ω
180
Ω
405
Ω
720
Ω
1,920
Ω
Nominal operating
power
Set coil
Reset coil
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24
V DC
75%V or less of
nominal voltage*
(Initial)
75%V or less of
nominal voltage*
(Initial)
200 mW
200 mW
300 mW
300 mW
120%V of
nominal voltage
[M.B.B. type]
Nominal coil
voltage
3
V DC
80%V or less of
nominal voltage*
(Initial)
10%V or more of
nominal voltage*
(Initial)
Pick-up voltage
(at 20°C
68°F)
Drop-out voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
66.7 mA
44.4 mA
40 mA
33.3 mA
22.2 mA
16.7 mA
8.3 mA
Coil resistance
[±10%] (at 20°C
68°F)
45
Ω
101
Ω
125
Ω
180
Ω
405
Ω
720
Ω
2,880
Ω
200 mW
Nominal operating
power
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
5 V DC
6
9
12
24
V DC
V DC
V DC
V DC
150%V of
nominal voltage
*Pulse drive (JIS C 5442-1986)
2. Specifications
Characteristics
Arrangement
Contact
Initial contact resistance, max.
Contact material
Nominal switching capacity
Max. switching power
Max. switching voltage
Max. switching current
Min. switching capacity (Reference value)*
1
Single side stable
Nominal
operating power 1 coil latching
2 coil latching
Insulation resistance (Initial)
Between open contacts
Electrical
characteristics
Breakdown
voltage (Initial)
Between contact and coil
Between contact sets
Temperature rise (at 20°C
68°F)
Operate time [Set time] (at 20°C
68°F)
Release time [Reset time] (at 20°C
68°F)
Shock
resistance
Vibration
resistance
Functional
Destructive
Item
2 Form C, 2 Form D (M.B.B.)
Max. 50mΩ (By voltage drop 6 V DC 1A)
Ag+Au clad
1 A 30 V DC, 0.5 A 125 V AC (resistive load)
30 W (DC), 62.5 V A (AC) (resistive load)
110 V DC, 125 V AC
1A
10μA 10mV DC
Standard (B.B.M) type: 140 mW (3 to 12 V DC), 200 mW (24 V DC), 300 mW (48 V DC)
M.B.B. type: 200 mW
100 mW (3 to 12 V DC), 150 mW (24 V DC)
200 mW (3 to 12 V DC), 300 mW (24 V DC)
Min. 1,000MΩ (at 500V DC)
Measurement at same location as “Initial breakdown voltage” section.
Standard (B.B.M) type: 750 Vrms for 1min. (Detection current: 10 mA),
M.B.B. type: 300 Vrms for 1 min. (Detection current: 10 mA)
1,000 Vrms for 1min. (Detection current: 10 mA)
1,000 Vrms for 1min. (Detection current: 10 mA)
Max. 50°C (By resistive method, nominal coil voltage applied to the coil; contact carrying current: 1A.)
Max. 3 ms [Max. 3 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.)
Max. 3 ms [Max. 3 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.)
(without diode)
Min. 490 m/s
2
(Half-wave pulse of sine wave: 11 ms; detection time: 10μs.)
Min. 980 m/s
2
(Half-wave pulse of sine wave: 6 ms.)
10 to 55 Hz at double amplitude of 3 mm (Detection time: 10μs.)
10 to 55 Hz at double amplitude of 5 mm
Standard (B.B.M) type: Min. 10
8
, M.B.B. type: Min. 10
7
Standard (B.B.M) type: Min. 2×10
5
(1 A 30 V DC resistive), Min. 10
5
(0.5 A 125 V AC resistive)
M.B.B. type: Min. 10
5
(1 A 30 V DC resistive)
Standard (B.B.M) type:
Ambient temperature: –40°C to +70°C
–40°F to +158°F;
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
M.B.B. type:
Ambient temperature: –40°C to +50°C
–40°F to +122°F;
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
20 cpm
Approx. 1.5 g
.053 oz
Specifications
Rating
Mechanical
characteristics
Functional
Destructive
Mechanical (at 180 cpm)
Electrical (at 20 cpm)
Expected life
Conditions
Conditions for operation, transport and
storage*
2
Max. operating speed (at rated load)
Unit weight
Notes: *1 This value can change due to the switching frequency, environmental conditions, and desired reliability level, therefore it is recommended to check this with the
actual load. TX/TX-S/TX-D relay AgPd contact type are available for low level load switching (10V DC, 10mA max. level).
*2 Refer to “AMBIENT ENVIRONMENT” in GENERAL APPLICATION GUIDELINES.
I'm a beginner
Want to know how to make 8 digital tubes display different numbers at the same time
My microcontroller does not have a latch.
It's best to write a program and see
Thanks...
As the title says. I know a little about CoOS, but I haven't seen uCOS-II. CoOS is free and open source for commercial or teaching use, but I don't know what uCOS-II is like?
Is there any expert who c...
Firefly was detained for being a hooligan, but he refused to accept it: Who was giving off electricity? Who was streaking? Who has an exhibitionist fetish? The toilet is dark and I am not allowed to t...
Dear experts, this is a dual-integration AD circuit for analog-to-digital conversion. The left in is the voltage to be measured, 0 to -5V negative value, the right three are the comparator inputs to t...
This paper establishes a fuel cell engine test platform based on the NI integrated hardware and software environment. This platform can realize the test and control of fuel cell engines and their a...[Details]
With the rapid development of intelligent control technology, computers and information technology, the trend of information appliances IA (Information Application), computers and communications integ...[Details]
12v Lead Acid batteries used in trucks, cars, RVs and uninterruptible power supplies are usually rated at 12V. This circuit monitors the battery, the charge and discharge curves, gives the cu...[Details]
Printed circuit boards ( PCBs
)
are used in most electrical products
. If a PCB has low
insulation resistance
(IR), the performance of the circuits on the PCB will be greatly reduced...[Details]
1. Overview
At present, an information revolution is in the ascendant around the world, led by microelectronics, computers and communication technologies, and centered on information technolog...[Details]
1 Introduction
With the improvement of people's quality of life, lamps are no longer just basic indoor lighting tools, but also a kind of practical art for architectural decoration. When ther...[Details]
With the rapid development of cities and the improvement of citizens' living standards, the number of various vehicles in cities is growing, and the demand for parking spaces in major commercial an...[Details]
introduction
Steam turbines are driven by high-temperature and high-pressure steam generated by boilers to run at high speed. They are key power equipment in thermal power plants. The emergenc...[Details]
Overview
By transmitting ultrasonic energy into the human body and receiving and processing the returning reflected signals, phased array ultrasound systems can generate images of organs and s...[Details]
As the global LED market demand continues to increase, my country's LED industry will face huge opportunities in the future. However, the core LED technology and patents are basically monopolized b...[Details]
Electric bicycles have long been a means of transportation for lower-income groups due to their affordability. The largest concentrated expense in the use of electric vehicles is the cost of replac...[Details]
summary
This article will briefly analyze the success and shortcomings of high-frequency DC-DC switching power supplies in the process of miniaturization (the second basic goal), and propose m...[Details]
1. Introduction
With the rapid development of computer technology, communication technology, and integrated circuit technology, the large-scale application of field control instruments and equ...[Details]
Current sensing in automotive applications includes controlling the current through solenoids and injectors. For example, during diesel injection, we rapidly increase the current to the induction i...[Details]
introduction
In the late 1990s, due to the great safety issues of liquid cobalt lithium-ion batteries, people studied and developed polymer lithium-ion batteries. In addition to the performanc...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
