B120A-E3/61T

Description
DIODE 1 A, 20 V, SILICON, SIGNAL DIODE, DO-214AC, ROHS COMPLIANT, PLASTIC, SMA, 2 PIN, Signal Diode
CategoryDiscrete semiconductor    diode
File Size72KB，4 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric Compare View All

B120A-E3/61T Overview

DIODE 1 A, 20 V, SILICON, SIGNAL DIODE, DO-214AC, ROHS COMPLIANT, PLASTIC, SMA, 2 PIN, Signal Diode

B120A-E3/61T Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
Parts packaging codeDO-214AC
package instructionR-PDSO-C2
Contacts2
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresFREE WHEELING DIODE, LOW POWER LOSS
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JEDEC-95 codeDO-214AC
JESD-30 codeR-PDSO-C2
JESD-609 codee3
Humidity sensitivity level1
Number of components1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
Maximum output current1 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Maximum repetitive peak reverse voltage20 V
surface mountYES
technologySCHOTTKY
Terminal surfaceMatte Tin (Sn)
Terminal formC BEND
Terminal locationDUAL
Maximum time at peak reflow temperature40

Preview

Download Datasheet
B120A thru B160A
Preliminary
Vishay General Semiconductor
Surface Mount Schottky Barrier Rectifier
FEATURES
• Low profile package
• Ideal for automated placement
• Guardring for overvoltage protection
• Low power losses, high efficiency
• Low forward voltage drop
DO-214AC (SMA)
• Meets MSL level 1, per J-STD-020C, LF max peak
of 260 °C
• Solder Dip 260 °C, 40 seconds
• Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
TYPICAL APPLICATIONS
For use in low voltage, high frequency inverters, free-
wheeling, dc-to-dc converters, and polarity protection
applications.
MECHANICAL DATA
Case:
DO-214AC (SMA)
Epoxy meets UL-94V-0 flammability rating
Terminals:
Matte tin plated leads, solderable per
J-STD-002B and JESD22-B102D
E3 suffix for commercial grade
Polarity:
Color band denotes the cathode end
MAJOR RATINGS AND CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
V
F
T
j
max.
1.0 A
20 V to 60 V
30 A
0.50 V, 0.75 V
125 °C, 150 °C
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Device marking code
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current at T
L
(see Fig. 1)
Peak forward surge current 8.3 ms single half sine-wave
superimposed on rated load
Voltage rate of change (rated V
R
)
Operating junction temperature range
Storage temperature range
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
dv/dt
T
J
T
STG
- 65 to + 125
- 65 to + 150
SYMBOL
B120A
B12
20
14
20
B130A
B13
30
21
30
B140A
B14
40
28
40
1.0
30
10000
- 65 to + 150
B150A
B15
50
35
50
B160A
B16
60
42
60
UNIT
V
V
V
V
A
A
V/µs
°C
°C
Document Number 88905
06-Jul-06
www.vishay.com
1
