VISHAY
BYW32 to BYW36
Vishay Semiconductors
Fast Avalanche Sinterglass Diode
\
Features
•
•
•
•
Glass passivated junction
Hermetically sealed package
Low reverse current
Soft recovery characteristics
Applications
Fast rectification and switching diode for example for
TV-line output circuits and switch mode power supply
Mechanical Data
Case:
Sintered glass case, SOD 57
Terminals:
Plated axial leads, solderable per
MIL-STD-750, Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:
370 mg, (max. 500 mg)
949539
Parts Table
Part
BYW32
BYW33
BYW34
BYW35
BYW36
Type differentiation
V
R
= 200 V; I
FAV
= 2 A
V
R
= 300 V; I
FAV
= 2 A
V
R
= 400 V; I
FAV
= 2 A
V
R
= 500 V; I
FAV
= 2 A
V
R
= 600 V; I
FAV
= 2 A
SOD57
SOD57
SOD57
SOD57
SOD57
Package
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Reverse voltage = Repetitive peak reverse
voltage
Test condition
see electrical characteristics
see electrical characteristics
see electrical characteristics
see electrical characteristics
see electrical characteristics
Peak forward surge current
Repetitive peak forward current
Average forward current
Junction and storage temperature range
Non repetitive reverse avalanche energy
I
(BR)R
= 0.4 A
ϕ
= 180 °
t
p
= 10 ms, half sinewave
Sub type
BYW32
BYW33
BYW34
BYW35
BYW36
Symbol
V
R
=
V
RRM
V
R
=
V
RRM
V
R
=
V
RRM
V
R
=
V
RRM
V
R
=
V
RRM
I
FSM
I
FRM
I
FAV
Value
200
300
400
500
600
50
12
2
Unit
V
V
V
V
V
A
A
A
°C
mJ
T
j
= T
stg
- 55 to +
175
E
R
10
Document Number 86048
Rev. 5, 07-Jan-03
www.vishay.com
1
BYW32 to BYW36
Vishay Semiconductors
Maximum Thermal Resistance
T
amb
= 25 °C, unless otherwise specified
Parameter
Junction ambient
Test condition
l = 10 mm, T
L
= constant
on PC board with spacing 25 mm
Sub type
Symbol
R
thJA
R
thJA
Value
45
100
VISHAY
Unit
K/W
K/W
Electrical Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Forward voltage
Reverse current
Reverse recovery time
I
F
= 1 A
V
R
= V
RRM
V
R
= V
RRM
, T
j
= 150 °C
I
F
= 0.5 A, I
R
= 1 A, i
R
= 0.25 A
Test condition
Sub type
Symbol
V
F
I
R
I
R
t
rr
Min
Typ.
0.95
1
60
Max
1.1
5
150
200
Unit
V
µA
µA
ns
Typical Characteristics
(T
amb
= 25
°C
unless otherwise specified)
R
thJA
– Therm. Resist. Junction / Ambient ( K/W )
120
2.5
100
80
60
l
40
20
0
0
5
10
15
T
L
=constant
20
25
30
l – Lead Length ( mm )
l
I
FAV
– Average Forward Current ( A )
V
R
=V
RRM
half sinewave
2.0
1.5
1.0
0.5
0.0
0
20
40
60
80 100 120 140 160 180
R
thJA
=100K/W
PCB: d=25mm
R
thJA
=45K/W
l=10mm
94 9552
16346
T
amb
– Ambient Temperature (
°C
)
Figure 1. Max. Thermal Resistance vs. Lead Length
Figure 3. Max. Average Forward Current vs. Ambient Temperature
100.000
I
R
– Reverse Current (
m
A )
1000
V
R
= V
RRM
I
F
– Forward Current ( A)
10.000
T
j
=175°C
T
j
=25°C
1.000
0.100
0.010
0.001
0.0
0.5
100
10
1
1.0
1.5
2.0
2.5
V
F
– Forward Voltage ( V )
3.0
16347
25
16345
50
75
100
125
150
T
j
– Junction Temperature (
°C
)
175
Figure 2. Forward Current vs. Forward Voltage
Figure 4. Reverse Current vs. Junction Temperature
www.vishay.com
2
Document Number 86048
Rev. 5, 07-Jan-03
BYW32 to BYW36
Vishay Semiconductors
Ozone Depleting Substances Policy Statement
It is the policy of
Vishay Semiconductor GmbH
to
1. Meet all present and future national and international statutory requirements.
VISHAY
2. Regularly and continuously improve the performance of our products, processes, distribution and
operatingsystems with respect to their impact on the health and safety of our employees and the public, as
well as their impact on the environment.
It is particular concern to control or eliminate releases of those substances into the atmosphere which are
known as ozone depleting substances (ODSs).
The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSs
and forbid their use within the next ten years. Various national and international initiatives are pressing for an
earlier ban on these substances.
Vishay Semiconductor GmbH
has been able to use its policy of continuous improvements to eliminate the
use of ODSs listed in the following documents.
1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments
respectively
2. Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental
Protection Agency (EPA) in the USA
3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively.
Vishay Semiconductor GmbH
can certify that our semiconductors are not manufactured with ozone depleting
substances and do not contain such substances.
We reserve the right to make changes to improve technical design
and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each
customer application by the customer. Should the buyer use Vishay Semiconductors products for any
unintended or unauthorized application, the buyer shall indemnify Vishay Semiconductors against all
claims, costs, damages, and expenses, arising out of, directly or indirectly, any claim of personal
damage, injury or death associated with such unintended or unauthorized use.
Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany
Telephone: 49 (0)7131 67 2831, Fax number: 49 (0)7131 67 2423
www.vishay.com
4
Document Number 86048
Rev. 5, 07-Jan-03
