TAK CHEONG
PRELIMINARY DATASHEET
500mW SOD-123 SURFACE MOUNT
Flat Lead Surface Mount Plastic Package
Zener Voltage Regulators
Absolute Maximum Ratings
Symbol
P
D
T
STG
T
OPR
Power Dissipation
Storage Temperature Range
Operating Temperature Range
T
A
= 25°C unless otherwise noted
Value
500
-65 to +150
-65 to +150
Units
mW
°C
°C
SOD-123 Flat Lead
Parameter
These ratings are limiting values above which the serviceability of the diode may be impaired.
Specification Features:
Wide Zener Voltage Range Selection, 2.4V to 75V
VZ Tolerance Selection of ±5% (C Series)
Flat Lead SOD-123 Plastic Package
Surface Device Type Mounting
Moisture Sensitivity Level 1
Clip Bonding Construction, Good Thermal Capability
RoHS Compliant
Matte Tin(Sn) Lead Finish
Band Indicates Cathode
Cathode
ELECTRICAL SYMBOL
Anode
Electrical Characteristics
Device
Type
TCMMSZ2V0
TCMMSZ2V2
TCMMSZ2V4
TCMMSZ2V7
TCMMSZ3V0
TCMMSZ3V3
TCMMSZ3V6
TCMMSZ3V9
TCMMSZ4V3
TCMMSZ4V7
TCMMSZ5V1
TCMMSZ5V6
TCMMSZ6V2
TCMMSZ6V8
TCMMSZ7V5
TCMMSZ8V2
TCMMSZ9V1
TCMMSZ10V
TCMMSZ11V
TCMMSZ12V
TCMMSZ13V
TCMMSZ15V
TCMMSZ16V
Device
Marking
Min
2V0Z
2V2Z
2V4Z
2V7Z
3V0Z
3V3Z
3V6Z
3V9Z
4V3Z
4V7Z
5V1Z
5V6Z
6V2Z
6V8Z
7V5Z
8V2Z
9V1Z
10VZ
11VZ
12VZ
13VZ
15VZ
16VZ
1.90
2.09
2.28
2.57
2.85
3.14
3.42
3.71
4.09
4.47
4.85
5.32
5.89
6.46
7.11
7.79
8.65
9.50
10.45
11.40
12.35
14.25
15.20
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
(Volts)
Nom
2.0
2.2
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
Max
2.10
2.31
2.52
2.84
3.15
3.47
3.78
4.10
4.52
4.94
5.36
5.88
6.51
7.14
7.86
8.61
9.56
10.50
11.55
12.60
13.65
15.75
16.80
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
I
ZT
(mA)
Z
ZT
@ I
ZT
(Ω)
Max
100
100
100
100
100
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
I
ZK
(mA)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Z
ZK
@ I
ZK
(Ω)
Max
600
600
564
564
564
564
564
564
564
470
451
376
141
75
75
75
94
141
141
141
160
188
188
I
R
@ V
R
(µA)
Max
120
120
45
18
9
4.5
4.5
2.7
2.7
2.7
1.8
0.9
2.7
1.8
0.9
0.63
0.45
0.18
0.09
0.09
0.09
0.045
0.045
V
R
(Volts)
0.5
0.7
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10.5
11.2
July 2007, Revision C
Page 1
TCMMSZ2V0 through TCMMSZ75V
®
TAK CHEONG
PRELIMINARY DATASHEET
Electrical Characteristics
Device
Type
Device
Marking
Min
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
(Volts)
Nom
Max
I
ZT
(mA)
Z
ZT
@ I
ZT
(Ω)
Max
45
55
55
70
80
80
80
90
130
150
170
180
200
215
240
255
I
ZK
(mA)
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Z
ZK
@ I
ZK
(Ω)
Max
212
212
235
235
282
282
306
329
329
353
353
376
400
423
447
470
I
R
@ V
R
(µA)
Max
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
V
R
(Volts)
12.6
14.0
15.4
16.8
18.9
21.0
23.0
25.2
27.3
30.1
33.0
35.7
39.2
43.4
47.6
52.5
TCMMSZ18V
18VZ
17.10
18
18.90
5
TCMMSZ20V
20VZ
19.00
20
21.00
5
TCMMSZ22V
22VZ
20.90
22
23.10
5
TCMMSZ24V
24VZ
22.80
24
25.20
5
TCMMSZ27V
27VZ
25.65
27
28.35
5
TCMMSZ30V
30VZ
28.50
30
31.50
5
TCMMSZ33V
33VZ
31.35
33
34.65
5
TCMMSZ36V
36VZ
34.20
36
37.80
5
TCMMSZ39V
39VZ
37.05
39
40.95
5
TCMMSZ43V
43VZ
40.85
43
45.15
5
TCMMSZ47V
47VZ
44.65
47
49.35
5
TCMMSZ51V
51VZ
48.45
51
53.55
5
TCMMSZ56V
56VZ
53.20
56
58.80
5
TCMMSZ62V
62VZ
58.90
62
65.10
5
TCMMSZ68V
68VZ
64.60
68
71.40
5
TCMMSZ75V
75VZ
71.25
75
78.75
5
V
F
Forward Voltage = 900mV Maximum @
I
F
= 10 mA for all types
Notes:
1.
2.
3.
4.
The Zener Voltage (V
Z
) is tested under pulse condition of 10mS.
The device numbers listed have a standard tolerance on the nominal zener voltage of ±5%.
For detailed information on price, availability and delivery of nominal zener voltages between the voltages shown and tighter
voltage tolerances, contact your nearest Tak Cheong Electronics representative.
The zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an rms value equal to
10% of the dc zener current (I
ZT
or
I
ZK
) is superimposed to
I
ZT
or
I
ZK.
Flat Lead SOD-123 Package Outline
July 2007, Revision C
Page 2
®
TAK CHEONG
PRELIMINARY DATASHEET
This datasheet presents technical data of Tak Cheong’s Zener Diodes. Complete specifications for the individual devices are
provided in the form of datasheets. A comprehensive Selector Guide is included to simplify the task of choosing the best set of
components required for a specific application. For additional information, please visit our website
http://www.takcheong.com.
Although information in this datasheet has been carefully checked, no responsibility for the inaccuracies can be assumed by Tak
Cheong. Please consult your nearest Tak Cheong’s sales office for further assistance.
Tak Cheong reserves the right to make changes without further notice to any products herein to further improve reliability,
function or design, cost and productivity.
TAK CHEONG
July 2007, Revision C
®
and
are registered trademarks of Tak Cheong Electronics (Holdings) Co., Ltd.
Page 3
