DQXO3SM OSCILLATOR
1 Hz to 10 kHz*
®
Surface Mount Low Frequency Crystal Oscillator
DESCRIPTION
The DQXO3SM oscillator consists of a CMOS-compatible
hybrid circuit hermetically sealed in a standard 24-pin
ceramic leadless chip carrier. Precision tuning of the
oscillator allows for very tight calibration tolerances and
eliminates the need for a trimming capacitor, a major
source of long-term frequency drift. The specifications
and characteristics of the DXQ03SM vary with frequency.
The characteristics of the 400 Hz model are presented in
this data sheet.
3SM
QXO kHz
D 10
* Contact factory for frequencies below 1 Hz or
multiple frequency outputs.
FEATURES
PACKAGE DIMENSIONS
C
B
22
Standard 24-pin ceramic LCC
CMOS compatible
Low power consumption
Low aging
Full military testing available
Various voltage options available
High shock resistance
Multiple frequency outputs available
G
E
F
D
24
1
2
3
D
4
C
8
16
APPLICATIONS
10
Industrial, Computer & Communications
General purpose clock oscillator
Data Logger
Remote sensor
Liquid level sensing
Medical test and diagnostics
Military
Portable field communication
Military high speed modem
Flight recorder
PIN CONNECTIONS
A
DIM
A
B
C
D
E
F
G
INCHES
0.410 MAX
0.080 MAX
0.300 MAX
0.050 TYP
0.085 TYP
0.050 TYP
0.025 TYP
mm
10.16 MAX
2.03 MAX
7.62 MAX
1.27 TYP
2.16 TYP
1.27 TYP
0.64 TYP
Pin
23,24
5,6
13,14
Connection
Ground
V
DD
Output
10144 - Rev C
S
YS
All Others NC
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256 www.statek.com
C
ERT
I
F
I
C
TEM
AT
01
Pb
N
IO
IS
O
90
SPECIFICATIONS: DQXO3SM at 400 Hz
ABSOLUTE MAXIMUM RATINGS
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice.
Supply Voltage (V
DD
)
Calibration Tolerance
1
_
5 V
+
10% (3.3 V available)
_
_
A:
+
0.01% (
+
100 ppm)
_
B:
+
0.1%
_
C:
+
1.0%
Supply Voltage V
DD
Storage Temperature
-0.3 V to 7V
-55
O
C to +125
O
C
Max Process Temperature 260
O
C for 20 sec
ELECTRICAL CHARACTERISTICS
DQXO3SM 400 kHz
Frequency Stability
2
-55
O
C to +125
O
C -350 ppm TYP
-600 ppm MAX
-40
O
C to +85
O
C -150 ppm TYP
-300 ppm MAX
All parameters are measured at ambient temperature
with a 10 MΩ and 10 pF load at 5 V.
SYMBOL PARAMETER
V
OH
V
OL
*t
r
*t
f
MIN
TYP
4.95
0.05 0.4
60
60
40
50
150
150
60
MAX UNIT
V
V
ns.
ns.
%
Voltage Coefficient
Aging
Shock, survival
Vibration, survival
3 ppm/V TYP
10 ppm/V MAX
10 ppm/year MAX
1000 g peak, 1 ms,
1/2
sine
3 ppm MAX
10 g peak rms, 10-2000 Hz
3 ppm MAX
Output Voltage High 4.8
Output Voltage Low
Rise Time (10%-90%)
Fall Time (10%-90%)
Duty Cycle
I
DD
5V
Supply Current
f
o
= 32.768 kHz, CL=10pF
150
250
Frequency Change vs.
10%Output Load Change 1 ppm MAX
Operating Temp. Range
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to +125
O
C (Military)
µ
A
* Models with faster rise and fall time available, consult factory.
PACKAGING
1. Tighter tolerances available
2. Does not include calibration tolerance.
Positive variations small compared to negative variations.
DQXO3SM
-Tray Pack (Standard)
OUTPUT WAVEFORM
V
DD
V
OH
90%*
V
OL
0
10%*
*Of
V
DD
t
r
t
f
HOW TO ORDER DQXO3SM CRYSTAL OSCILLATORS
DQXO3SM
S
“S” if special or
custom design
Blank if standard
SM3
Blank = SM1
= Gold Plated
(Lead Free)
SM3 = Solder Dipped
SM5 = Solder Dipped
(Lead Free)
400H
Frequency
H = Hz
K = kHz
,
100
Calibration
Tolerance
@ 25
O
C
(in ppm)
/
I
Operating Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
10144 - Rev C
S
YS
C
ERT
I
F
I
C
TEM
AT
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256 www.statek.com
01
Pb
N
IO
IS
O
90
