NPN SILICON RF POWER TRANSISTOR
DESCRIPTION:
BLV32F
is Designed for in
linear v.h.f. amplifiers of television
transmitters and transporters.
FEATURES:
• Diffused emitter ballasting resistors
• P
G
= 16dBat10W/224MHz
•
Omnigold™
Metalization System
PACKAGE STYLE .500 6L FLG
MAXIMUM
TF:
lbO/4,06
MAXIMUM RATINGS
Ic
VCBO
VCEO
VCES
VEBO
PDISS
4.0 A
60V
32V
60V
4.0V
82 W @ T
C
= 25°C
-65 °C to +200 °C
-65°Cto+150°C
L™
Tj
TSTG
e
JC
2.1 °C/W
1= Collector 2= Base 3 and 4= Emitter
