3008 POWER INDUCTORS
High Reliability Power Inductors
ML369PJB
■
High temperature materials allow operation in ambient
temperatures up to 155°C
■
Special construction allows it to pass vibration testing to
80 G and shock testing to 1000 G.
Core material
Ferrite
Terminations
Silver-palladium-platinum-glass frit.
Weight
22 – 25 mg
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
1000/7″ reel
Plastic tape: 12 mm wide, 0.23 mm thick, 8 mm pocket spacing,
1.37 mm pocket depth
Recommended pick and place nozzle
OD: 3 mm; ID:
≤1.5
mm
Part number
1
ML369PJB561MLZ
ML369PJB801MLZ
ML369PJB102MLZ
ML369PJB152MLZ
ML369PJB222MLZ
ML369PJB332MLZ
ML369PJB472MLZ
ML369PJB562MLZ
ML369PJB682MLZ
ML369PJB822MLZ
ML369PJB103MLZ
ML369PJB123MLZ
ML369PJB183MLZ
ML369PJB223MLZ
ML369PJB333MLZ
ML369PJB473MLZ
ML369PJB683MLZ
ML369PJB104MLZ
ML369PJB124MLZ
ML369PJB154MLZ
ML369PJB184MLZ
ML369PJB224MLZ
ML369PJB334MLZ
Inductance
2
±20% (µH)
0.56
0.80
1.0
1.5
2.2
3.3
4.7
5.6
6.8
8.2
10
12
18
22
33
47
68
100
120
150
180
220
330
DCR max
3
(Ohms)
0.072
0.092
0.125
0.134
0.175
0.285
0.350
0.450
0.500
0.600
0.650
0.790
1.25
1.50
2.30
3.00
4.75
6.85
7.00
8.00
9.00
11.50
18.00
SRF (MHz)
4
min
typ
231
330
178
255
154
220
119
170
105
150
79.8
114
60.9
87
54.6
78
52.5
75
42.7
61
39.2
56
34.3
49
26.6
38
24.5
35
16.1
23
14.7
21
12.6
18
9.8
14
9.1
13
7.7
11
7.0
10
6.3
9
4.9
7
10% drop
1.8
1.6
1.3
1.1
1.0
0.81
0.68
0.62
0.58
0.52
0.46
0.45
0.35
0.29
0.27
0.22
0.18
0.15
0.084
0.080
0.070
0.067
0.059
Isat
(A)
5
20% drop
2.0
1.7
1.4
1.3
1.1
0.86
0.73
0.67
0.61
0.56
0.51
0.48
0.38
0.33
0.30
0.23
0.19
0.16
0.094
0.088
0.078
0.073
0.064
30% drop
2.1
1.8
1.5
1.3
1.1
0.88
0.74
0.70
0.63
0.58
0.52
0.50
0.40
0.34
0.31
0.24
0.20
0.16
0.10
0.092
0.082
0.076
0.066
Irms
(A)
6
20°C rise 40°C rise
1.1
1.6
0.88
1.3
0.72
1.0
0.70
0.96
0.68
0.88
0.59
0.76
0.54
0.64
0.46
0.58
0.40
0.54
0.36
0.48
0.34
0.45
0.30
0.40
0.26
0.35
0.23
0.30
0.20
0.26
0.17
0.22
0.14
0.18
0.13
0.17
0.11
0.15
0.10
0.14
0.10
0.13
0.080
0.12
0.070
0.10
1. When ordering, please specify
testing
code:
ML369PJB104MLZ
Testing: Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10004
2. Inductance tested at 100 kHz, 0.1 Vrms using an Agilent/HP 4192A or
equivalent.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using an Agilent/HP 8753ES or equivalent.
5. Typical DC current at which the inductance drops the specified amount
from its value without current.
6. Typical current that causes the specified temperature rise from 25°C
ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information.
Document ML438-1
Revised 08/11/11
