1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994.
2. CONTROLLING DIMENSION: INCH.
DIM
A
A1
b
b1
c
D
E
e
e1
L
L1
H
E
MIN
1.50
0.02
0.60
2.90
0.24
6.30
3.30
2.20
0.85
0.20
1.50
6.70
0°
MILLIMETERS
NOM
MAX
1.63
1.75
0.06
0.10
0.75
0.89
3.06
3.20
0.29
0.35
6.50
6.70
3.50
3.70
2.30
2.40
0.94
1.05
−−−
−−−
1.75
2.00
7.00
7.30
10°
−
MIN
0.060
0.001
0.024
0.115
0.009
0.249
0.130
0.087
0.033
0.008
0.060
0.264
0°
INCHES
NOM
0.064
0.002
0.030
0.121
0.012
0.256
0.138
0.091
0.037
−−−
0.069
0.276
−
MAX
0.068
0.004
0.035
0.126
0.014
0.263
0.145
0.094
0.041
−−−
0.078
0.287
10°
D
b1
4
H
E
E
1
2
3
e1
b
e
A
q
L
L1
C
q
0.08 (0003)
A1
STYLE 1:
PIN 1.
2.
3.
4.
BASE
COLLECTOR
EMITTER
COLLECTOR
SOLDERING FOOTPRINT*
3.8
0.15
2.0
0.079
2.3
0.091
2.3
0.091
6.3
0.248
2.0
0.079
1.5
0.059
mm
inches
SCALE 6:1
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
