SA
surge absorbers
features
•
Surge absorber elements in discharge
tube with a microgap
•
The small size requires less board space
•
No need to distinguish polarity
•
Quick response to surge voltage
•
Stable against repeated surges
•
Available for high frequency circuits due
to the low-electrostatic capacitance
•
Marking: Color code
•
Products meet EU RoHS requirements
dimensions and construction
Dumet
Wire
Glass
Special
Gas
Special Chip
Marking
EU
Type
ød
Lead Wire
SA05
Dimensions
inches
(mm)
L
D
d
l
.150±.020 .071±.012
.020
1.18±.118
(3.8±0.5)
(1.8±0.3)
(0.5)
(30±3)
L
D
ordering information
SA
Product
Code
05
Surge
Current
Capacity
05: 500A
circuit
protection
C
Terminal
Surface
Material
C: SnCu
T52
Taping
T52: 52mm
taping
A
Packaging
A: Ammo
301
DC Spark-
Over Voltage
201: 200V
241: 240V
251: 250V
301: 300V
401: 400V
501: 500V
701: 700V
N
DC Spark-
Over Voltage
Tolerance
M: ±20%
N: ±30%
ratings
Type
Vs
DC Spark-
Over
Voltage
200V
240V
250V
300V
400V
500V
700V
Vs
Tolerance
±20%
IR
Insulation
Resistance
Measurement
Voltage
C
Electrostatic
Capacitance
Surge
Current
Capacity
Surge Life
Taping &
Q’ty pcs
T52A
DC100V
±30%
100MΩ min.
DC250V
SA05C
1pF Max.
(1kHz-6V
Max.)
500A
(8/20μs)
200 times
(1500pF-10kV-0Ω)
2,000
Operating Temperature Range: -40°C - +85°C
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
12/16/09
256
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
SA
surge absorbers
environmental applications
Marking
First color code
Second color code
Third color code
Vs
DC Spark-Over Voltage
200V
240V
250V
300V
400V
500V
700V
First color
code
Red
Orange
Yellow
Green
Purple
Color Code
Second
Third color code
color code
Black
Yellow
Green
DC Spark-Over Voltage
Tolerance
M ±20%: Plain
Black
N ±30%: White
Performance Characteristics
Test Items
Spark-Over Voltage
Insulation Resistance
Electrostatic Capacitance
Resistance to Soldering Heat
Solderability
Terminal Strength
Rapid Change of
Temperature
Cold Resistance
Heat Resistance
Humidity Resistance
Surge Current Capacity
Surge Life
Test Methods
Spark-over voltage refers to voltage that starts discharging.
Discharge current shall be 0.5mA or under.
Measuring an insulatiuon resistance between terminals.
For measurement voltage, refer to a rating table.
1kHz, 6Vmax.
260°C±5°C, 10s±1s
235°C±5°C, 5s±0.5s
(Direct load); 5N,10s
(Bending test); 2.5N, 90°, 2 times
-40°C (30min.)/+125°C (30min.) 25 cycles
-40°C±3°C, 1000h
125°C±2°C, 1000h
40°C±2°C, 90%–95%RH, 1000h
8/20μs, 500A, 3 times
1500pF-10kV-0Ω, 200 times
Performance Requirements
Within regulated tolerance.
Within specified IR.
Within specified C.
Vs, IR, and C to be within specified values.
95% Coverage min.
No mechanical damage.
Vs, IR, and C to be within specified values.
Vs, IR, and C to be within specified values.
Vs, IR, and C to be within specified values.
Vs, IR, and C to be within specified values.
With no mechanical damage.
∆Vs/Vs≤30%
IR and C to be within specified values.
circuit
protection
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
12/16/09
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
257
