SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 1
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0908□□□□L□-□□□
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
1
8
Marking
Dot is start winding
& Inductance code
101
4
A
5
A
B
C
E
F
F'
W
: 9.5±0.3
: 10.5 max.
: 7.5±0.3
: 2.5±0.3
: 11.0±0.5
: 12.7±0.8
: 0.6 typ.
m/m
m/m
m/m
m/m
m/m
m/m
m/m
F
F'
E
C
B
．SDS0908-101Y
~ 153Y
2.2
1.0
10.3
．SDS0908-1R5M
~ 820M
2.2
2.2
2.5
10.3
2.2
E
W
E
3.0
14.7
14.7
( PCB Pattern )
Ⅱ﹒SCHEMATIC
DIAGRAM：
.SDS0908-101Y ~ 153Y
1
4
.SDS0908-1R5M ~ 820M
1
½
4
5
½
8
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Core：Ferrite RI core
c﹒Wire
：Enamelled
copper wire ( class F )
d﹒Base：LCP
e﹒Terminal：Cu/Ni/Sn
f﹒Adhesive：Epoxy resin
g﹒Remark：Products comply with RoHS'
requirements
a
b
c
d
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
f
e
Forced Cooling Area
Reflow Area
+2.0 ~ 4.0
℃
-(1.0 ~ 5.0)
℃
/ sec max.
/ sec max.
Peak Temperature:
260℃
5 0sec max.
230℃
250
Temperature (
℃
)
Ⅳ﹒GENERAL
SPECIFICATION：
a﹒Temp. rise
：40℃
max.
b﹒Rated current
：Base
on temp. rise
&
△
L / LOA=10% max.
c﹒Storage temp.：-40℃ ----+125℃
d﹒Operating temp.：-40℃----+105℃
e﹒Resisance to solder heat：260℃. 10 secs.
AE-001A
200
150
7 0sec max.
100
50
0
50
100
150
Time ( seconds )
200
250
9.0
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 2
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0908□□□□L□-□□□
Ⅴ﹒ELECTRICAL
CHARACTERISTICS
：
DWG No.
Inductance
( µH )
Q
nom.
20
20
20
18
18
33
40
45
40
35
45
40
45
40
35
30
30
40
42
45
35
35
30
30
33
30
35
30
35
85
120
95
95
90
90
85
110
130
Test Freq. ( Hz )
L
Q
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
1K
7.960M
7.960M
7.960M
7.960M
7.960M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
2.520M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.252M
0.252M
0.252M
0.252M
0.252M
0.252M
0.252M
79.60K
79.60K
SRF
( MHz )
nom.
65.00
50.00
35.00
25.00
15.00
11.00
11.00
8.50
8.50
6.00
6.00
5.00
5.00
4.00
3.00
2.50
2.40
6.00
5.70
4.60
4.20
3.80
3.40
3.00
2.60
2.30
2.20
2.00
1.90
1.80
1.30
1.00
0.90
0.80
0.60
0.50
0.50
0.40
RDC
(
Ω
)
max
0.014
0.019
0.021
0.027
0.032
0.040
0.050
0.065
0.075
0.080
0.090
0.100
0.135
0.150
0.165
0.184
0.260
0.280
0.340
0.450
0.500
0.600
0.700
0.800
1.000
1.150
1.500
1.700
2.200
2.500
4.000
5.000
8.000
12.000
16.500
24.000
26.000
40.000
IDC
( mA )
max
5600
4800
4400
3800
3400
3000
2500
2200
2000
1900
1800
1700
1500
1400
1350
1250
1050
1000
900
800
700
650
600
550
500
450
380
350
320
300
250
200
150
120
100
97
95
75
SS09081R5ML□-□□□
1.50±20%
SS09082R7ML□-□□□
2.70±20%
SS09083R9ML□-□□□
3.90±20%
SS09085R6ML□-□□□
5.60±20%
SS09087R5ML□-□□□
7.50±20%
SS0908100ML□-□□□
10.00±20%
SS0908120ML□-□□□
12.00±20%
SS0908150ML□-□□□
15.00±20%
SS0908180ML□-□□□
18.00±20%
SS0908220ML□-□□□
22.00±20%
SS0908270ML□-□□□
27.00±20%
SS0908330ML□-□□□
33.00±20%
SS0908390ML□-□□□
39.00±20%
SS0908470ML□-□□□
47.00±20%
SS0908560ML□-□□□
56.00±20%
SS0908680ML□-□□□
68.00±20%
SS0908820ML□-□□□
82.00±20%
SS0908101YL□-□□□
100.00±15%
SS0908121YL□-□□□
120.00±15%
150.00±15%
SS0908151YL□-□□□
180.00±15%
SS0908181YL□-□□□
220.00±15%
SS0908221YL□-□□□
270.00±15%
SS0908271YL□-□□□
SS0908331YL□-□□□
330.00±15%
SS0908391YL□-□□□
390.00±15%
SS0908471YL□-□□□
470.00±15%
SS0908561YL□-□□□
560.00±15%
SS0908681YL□-□□□
680.00±15%
SS0908821YL□-□□□
820.00±15%
SS0908102YL□-□□□
1000.00±15%
SS0908152YL□-□□□
1500.00±15%
2200.00±15%
SS0908222YL□-□□□
SS0908332YL□-□□□
3300.00±15%
SS0908472YL□-□□□
4700.00±15%
SS0908682YL□-□□□
6800.00±15%
SS0908822YL□-□□□
8200.00±15%
SS0908103YL□-□□□ 10000.00±15%
SS0908153YL□-□□□ 15000.00±15%
1).
□：Packaging
information… A：Bulk
2)."-
":Reference code
□□□
B：Taping Reel
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 3
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0908□□□□L□-□□□
Ⅵ﹒INDUCTANCE
VS. DC CURRENT CURVE：
10 4
7
5
3
2
10 3
7
5
472
Inductance（uH）
3
2
10 2
7
5
3
2
10 1
7
5
3
2
10 0
10 1
391
101
330
100
1R5
2 3
5 7 10 2 2 3
5 7 10 3
2 3
5 7 10 4
DC Current (mA)
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 4
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0908□□□□L□-□□□
Ⅶ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover tape
2.0±0.5
A
B
∮
C
∮
C
N
G
D
Embossed carrier
※
Carrier tape width : D
P:16 m/m
End
4 m/m
Start
101
Leader
no component
200 m/m Min.
101
101
101
101
Trailer
no component
400 m/m Min.
Components
User direction of feed
( 2 ) Dimensions
Style
13 - 24
A
330
B
21±0.8
C
13
D
24
G
26
+0
N
50
-0
Unit:m/m
T
30.4
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SS0908
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
400
1,600
13 - 24
1,600
8.6
40 x 40 x 24
AE-001A
SPECIFICATION FOR APPROVAL
REF :
PROD.
NAME
PAGE: 5
SHIELDED SMD
POWER INDUCTOR
ABC'S DWG NO.
ABC'S ITEM NO.
SS0908□□□□L□-□□□
Ⅷ﹒DWGING
NUMBER EXPRESSION：
S
S
0
9
0
8
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
Inner package
T.B.D.
T / R ( Reel package )
Inner package Q'TY
T.B.D.
400
pcs
Remark
AE-001A
