Electrical Specifications @ 25°C — Operating Temperature 0°C to 70°C
Part
Number
PL1241
PL1241-1
Inductance
(mH± 35%)
0.760
0.760
Irated
(A)
4.7
4.7
Leakage Inductance
(µH N
om
)
4.559
4.559
DCR
(µΩ MAX)
40
40
Inpedance Curve
#6
#6
Weight
(Grams)
6.2
6.2
Quantity in Tube
30
30
Notes:
1. Leakage inductance tested to 100 kHz, 1140 mV, (1-2) with (3-4) shorted.
2. Add the suffix “T” to the part number for Tape & Reel packaging
Mechanicals
PL1241
.670
MAX
17,02
Schematics
1
16Ts
16Ts
3
2
DATE CODE
COUNTRY OF ORIGIN
PAT PEND
4
1:1 ± 2%
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
Mechanicals
PL1241-1
.670
MAX
17,02
Schematics
1
3
DATE CODE
COUNTRY OF ORIGIN
PAT PEND
2
1:1 ± 2%
Part hardened for aerospace use.
4
.390
MAX
9,90
.650 .015
±
16,51 0,38
.670
MAX
0.770
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
1
pulseelectronics.com
M184.A (3/13)
SMT COMMON CHOKES
500 Vrms Isolation
Impedance Curve
PL1241NL/ PL1241-1NL
7.5 K
6.0 K
6
Impedance
(Ω)
4.5 K
9
7
3.0 K
1.5 K
0
100 kHz
1 MHz
8
Frequency
10 MHz
100 MHz
For More Information
Pulse North America
Headquarters
Two Pearl Buck Court
Bristol, PA 19007
U.S.A.
Tel: 215 781 6400
Fax: 215 781 6403
Pulse Europe
Zeppelinstrasse 15
71083 Herrenberg
Germany
Pulse China Headquarters
B402, Shenzhen Academy of
Aerospace Technology Bldg.
10th Kejinan Road
High-Tech Zone
Nanshan District
Shenzen, PR China 518057
Tel: 86 755 33966678
Fax: 86 755 33966700
Pulse North China
Room 2704/2705
Super Ocean Finance Ctr.
2067 Yan An Road West
Shanghai 200336
China
Tel: 86 21 62787060
Fax: 86 2162786973
Pulse South Asia
135 Joo Seng Road
#03-02
PM Industrial Bldg.
Singapore 368363
Tel: 65 6287 8998
Fax: 65 6287 8998
Pulse North Asia
3F No. 198, Zhongyuan Road
Zhongli City
Taoyuan County (32068)
Taiwan
Tel: 886 3 4356768
Fax: 886 3 4356823
Tel: 49 7032 7806 0
Fax: 49 7032 7806 12
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may be
