TEMPERATURE COMPENSATING THERMISTORS
ST Series: Surface Mount
DIMENSION
Size
0603
0805
Code
ST16
ST20
L
W
T
1.6±0.2 0.8±0.2 1.0max
2.0±0.2 1.25±0.2 1.2max
t
W
Insulation coat
L
Electrode (Ni, Solder plated)
SPECIFICATIONS
Size
Zero Power
Part Number Resistance
at 25°C (W)
ST16-502
ST16-103
ST16-103
ST16-473
0603
ST16-503
ST16-683
ST16-104
ST16-154
ST16-204
ST20-202
ST20-502
ST20-103
ST20-103
0805
ST20-473
ST20-503
ST20-683
ST20-104
ST20-154
ST20-204
5K
10K
10K
47K
50K
68K
100K
150K
200K
2K
5K
10K
10K
47K
50K
68K
100K
150K
200K
B-Constant
(25/85) (K)
3500
3450
4100
4100
3950
4100
4100
4100
4100
3500
3500
3450
4100
4100
3950
4100
4100
4100
4100
Resistance
Tolerance
(±%)
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
1,2,3,5%
Thermal Dissipation
Constant (mW /°C)
£1.7
£1.7
£1.7
£1.7
£1.7
£1.7
£1.7
£1.7
£1.7
£2
£2
£2
£2
£2
£2
£2
£2
£2
£2
Thermal Time
Constant (sec)
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
£5
Operating
Temperature
(°C)
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
-40 ~ +125°C
TAPING
Unit: mm
Code
ST16
ST20
A
1.1±0.2
1.65±0.2
B
1.9±0.2
2.4±0.2
W
8.0±0.2
F
3.5±0.05
E
1.75±0.1
P1
4.0±0.10
P2
2.0±0.05
P0
4.0±0.1
D0
1.5
-0.1
-0
†1
1.0max
†2
1.4max
REEL
Unit: mm
Code
ST16, ST20
A
f180
+0
-3
B
f60
+1
-0
C
f13±0.2
D
f21±0.8
E
2.0±0.5
W1
9.0±0.3
W2
11.4±1.0
RFE International
• Tel:(949) 833-1988 • Fax:(949) 833-1788 • E-Mail Sales@rfeinc.com
C6A04
2006.3.2
