PBRVFREQ2M70Z0AB datasheet, PDF

Datasheet> All Categories > Passive components> Crystal/resonator> PBRVFREQ2M70Z0AB

PBRVFREQ2M70Z0AB: DescriptionCeramic Resonator, 8.01MHz Min, 20MHz Max, ROHS COMPLIANT, MINIATURE, SMD, 3 PIN; CategoryPassive components Crystal/resonator; File Size75KB，1 Pages; ManufacturerAVX; Environmental Compliance

Download Datasheet Parametric View All

PBRVFREQ2M70Z0AB Overview

Ceramic Resonator, 8.01MHz Min, 20MHz Max, ROHS COMPLIANT, MINIATURE, SMD, 3 PIN

PBRVFREQ2M70Z0AB Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	AVX
package instruction	ROHS COMPLIANT, MINIATURE, SMD, 3 PIN
Reach Compliance Code	compliant
Other features	BULK
Crystal/Resonator Type	CERAMIC RESONATOR
frequency stability	0.2%
frequency tolerance	7000 ppm
Manufacturer's serial number	PBRV-M
Installation features	SURFACE MOUNT
Maximum operating frequency	20 MHz
Minimum operating frequency	8.01 MHz
Maximum operating temperature	150 °C
Minimum operating temperature	-40 °C
physical size	L4.5XB2.0XH1.2 (mm)/L0.177XB0.079XH0.047 (inch)
surface mount	YES

Preview

Download Datasheet

View All

MHz Band Ceramic Chip Resonators (SMD)

PBRV-H / PBRV-M Series

for Automotive

Features

• Miniature & low profile

• Rectangular shape allows easy pick

and placement

• Component cost and space saving

• High density mounting possible

• Reflow solderable & washable

• High reliability, high temperature

operating with ceramic case

How to Order

PBRV 15.00 H R 10 Y 0AB

e r t y u

qSeries

(PBRV: Automotive)

wFrequency

(MHz)

eType(H,M)

rPacking

_ Bulk

(Null)

Reel

tFrequency

Tolerance at 25

°C

±0.1%

±0.3%

±0.5%

−40

/ 85°C

−40

/ 150°C

Applications

RoHS Conforming

• Automotive

• ABS

• ECU

• Air-Bag System

±0.2%

±0.4%

±0.7%

−40

/ 125°C

yOperating

temperature

uUnique

code

Dimensions

PBRV-H Type

(Unit : mm)

Test Circuit

5.0V

PBRV-M Type

3.4

XXXX

7.4

6.7

XXX

1.6

2.0

MC14069UB or MC74HCU04

Out

Resonator

4.5

4.1

2.0max

1.2max

0.6

0.4

6-R0.45

3.0

0.4

6-0.3

1.7

6-R0.2

3-1.2

2.5

1.5

: 5V

R : 1MΩ

IC : MC14069UB (4 to 8MHz)

MC74HCU04 (8.01 to 20MHz)

1. 3 Input, Output(No polarity)

2. GND

Standard Tol. :

±0.3

Pin #

Input

Ground

Output

Notice

Please refer to IC Application Guide on our WEB site for IC

matching.

Recommended Land pattern

PBRV-H Type

2.5

(Unit : mm)

Specifications

Frequency Frequency Temperature

Series Range(MHz) Tolerance(25°C)

Stability

±0.5%

±0.5%(−40

+125°C)

(op.

±0.3%)

±0.5%(−40

+150°C)

±0.7%

±0.1%(−40

+125°C)

(op.

±0.5%)

±0.2%(−40

+150°C)

PBRV-M Type

1.5

PBRV-H

PBRV-M

4.0

1.7

2.6

0.4

4.00 to 8.00

8.01 to 20.00

Please contact our local sales office if you need without

capacitor type and tight frequency tolerance type for

CANBUS Application.

1.0

1.7

1.5

1.7

1.0

The thickness of solder paste : 0.2mm
