Features
■
Low cost, high quality
■
Excellent temperature stability
■
High currents
■
E12 series 100 µH to 33mH
■
Open construction
■
RoHS compliant*
*R
oH
S
CO
M
PL
PT121 Series - Radial High Q Inductors
Electrical Specifications (@ 25
°C)
Part
Number
Inductance
Typical (1)
mH –10 %
Q
(ref.)
Measure
frequency
Q and
Inductance
kHz
Self
Resonant
frequency
MHz min. (2)
DCR
Ω
(max.)
Rated
I DC
mA (max.)
Product Dimensions
10.15
MAX.
(0.40)
Heat Shrink
Tube Coated
12.70
MAX.
(0.50)
PT12110SL
PT12111SL
PT12112SL
PT12113SL
PT12114SL
PT12115SL
PT12116SL
PT12117SL
PT12118SL
PT12119SL
PT12120SL
PT12121SL
PT12123SL
PT12124SL
PT12125SL
PT12126SL
PT12127SL
PT12128SL
PT12129SL
PT12130SL
PT12131SL
PT12132SL
PT12133SL
PT12134SL
PT12135SL
PT12136SL
PT12137SL
PT12138SL
PT12139SL
PT12140SL
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.60
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.00
12.00
15.00
18.00
22.00
27.00
33.00
80
80
80
80
80
80
80
80
80
80
80
90
90
90
90
90
90
90
90
90
90
90
90
100
100
100
100
100
100
100
796.0
796.0
796.0
796.0
796.0
796.0
796.0
796.0
796.0
796.0
796.0
252.0
252.0
252.0
252.0
252.0
252.0
252.0
252.0
252.0
252.0
252.0
252.0
79.6
79.6
79.6
79.6
79.6
79.6
79.6
5.30
4.50
3.80
3.30
2.90
2.60
2.30
2.10
1.90
1.70
1.60
1.30
1.20
1.10
1.00
0.90
0.80
0.70
0.70
0.60
0.60
0.50
0.50
0.40
0.40
0.40
0.30
0.30
0.30
0.30
2.0
2.0
2.0
3.0
3.0
3.0
4.0
4.0
4.0
4.0
4.0
6.0
9.0
9.0
9.0
13.0
13.0
13.0
13.0
18.0
18.0
26.0
26.0
40.0
40.0
60.0
60.0
80.0
80.0
80.0
200
200
200
200
200
200
200
200
200
200
200
150
150
150
100
100
100
100
50
50
50
50
50
40
40
40
30
30
30
30
DIA.
0.70
(0.027)
5.00
(0.197)
5.00
(.197)
Recommended PCB Layout
0.90
±
0.1
DIA.
(0.035
±
0.004)
5.00
±
0.1
(0.197
±
0.004)
RECOMMENDED
PCB LAYOUT
DIMENSIONS:
MM
(INCHES)
TOLERANCE: ±
0.25
(0.010)
Electrical Schematic
1
2
Schematic
NOTES:
(1) Version J: Inductance Value ±5 % is also
available. Please insert ‘J’ after ‘S’ in part
number if Inductance Value ±5 % is required
(i.e. PT12110SJL).
(2)
Measurements are made at 25 °C using
HP4277A LCZ Meter Self Resonant Frequency
is for reference only.
General Specifications
Terminal..........................................Cu/Sn
Operating Temperature Range
...................................-20
°C
to +80
°C
Storage Temperature Range
...................................-25
°C
to +85
°C
Full encapsulated units with Epoxy Resin are also
available. Please consult factory for details.
REV. 04/06
*RoHS Directive 2002/95/EC Jan 27 2003 including Annex
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
