SUF302C-C: Description3A, 100V, SILICON, RECTIFIER DIODE, SMC, 2 PIN; CategoryDiscrete semiconductor diode; File Size369KB，2 Pages; ManufacturerSECOS; Websitehttp://www.secosgmbh.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SUF302C-C Overview

3A, 100V, SILICON, RECTIFIER DIODE, SMC, 2 PIN

SUF302C-C Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SECOS
package instruction	R-PDSO-C2
Reach Compliance Code	compliant
ECCN code	EAR99
application	SUPER FAST RECOVERY
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.98 V
JESD-30 code	R-PDSO-C2
Maximum non-repetitive peak forward current	80 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	3 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum repetitive peak reverse voltage	100 V
Maximum reverse current	10 µA
Maximum reverse recovery time	0.035 µs
surface mount	YES
Terminal form	C BEND
Terminal location	DUAL

Preview

Download Datasheet

View All

SUF301C~SUF305C

Elektronische Bauelemente

Voltage 50 V ~ 600 V

3.0 Amp Surface Mount Super Fast Recovery

Rectifiers

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURES



SMC

Ideal for surface mount applications

Easy pick and place

Built-in strain relief

Super Fast switching speed under 35ns

A

B

C

MECHANICAL DATA



Case: Molded plastic SMC

Epoxy: UL 94V-0 rate flame retardant

Polarity: Color band denotes cathode

Mounting position: Any

H

D

G

E

F

REF.

E

F

G

H

Millimeter

Min.

Max.

-

0.203

7.750

8.130

0.760

1.520

0.150

0.305

PACKAGE INFORMATION

Package

SMC

MPQ

3K

Leader Size

13’ inch

REF.

A

B

C

D

Millimeter

Min.

Max.

2.750

3.250

6.520

7.110

5.590

6.220

2.000

2.620

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

(Rating 25°C ambient temperature unless otherwise specified. Single phase half wave, 60Hz, resistive or inductive load.

For capacitive load, de-rate current by 20%.)

Parameter

Maximum Repetitive Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified

Current.375”(9.5mm) Lead Length at

T

A

=55°C

Peak Forward Surge Current, 8.3ms single

half sine-wave superimposed on rated

load@ T

L

=100°C

Maximum Instantaneous Forward Voltage

@ 3A

Maximum DC Reverse Current

at Rated DC Blocking Voltage

T

A

=25°C

T

A

=100°C

Symbol

SUF301C

SUF302C

Part Number

SUF303C

SUF304C

SUF305C

Unit

400

280

400

600

420

600

V

A

V

RRM

V

RMS

V

DC

I

F

50

35

50

100

70

100

200

140

200

3

I

FSM

V

F

I

R

T

RR

C

J

R

θJL

R

θJA

T

J

,T

STG

50

0.98

80

1.3

10

500

35

40

12

47

-55~150

1.7

A

V

μA

nS

pF

°C/W

°C

Maximum Reverse Recovery Time

1

Typical Junction Capacitance

2

Typical Thermal Resistance

3

Operating & Storage Temperature

Notes:

1. Reverse Recovery Time test condition：I

F

=0.5A, I

R

=1A, I

RR

=0.25A

2. Measured at 1MHz and applied reverse voltage of 4.0V D.C.

3. Units Mounted on P.C.B. with 0.31*0.31’’(8*8mm) Copper Pad Areas.

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

29-Jul-2013 Rev.B

Page 1 of 2
