ALUMINUM ELECTROLYTIC CAPACITORS
HCGF5 Series
(Warranty of 2,000 hours at 85°C)
HCGF5 Product Specifications
Features
• Standard products that have been used for many years.
Items
Specifications
Temperature range
−25℃∼＋85℃
Capacitance tolerance
±20％（20℃,120Hz）
Rated voltage
160∼450V.DC
0.01 CV (μA) or 5 mA, whichever is smaller or less
Leakage current
[C = nominal capacitance (μF), V = rated voltage (V)]
160∼250V.DC……0.25 or less（20℃,120Hz）
350∼450V.DC……0.20 or less（20℃,120Hz）
Permissible ripple current
As per the following "Standard value and case size" (40℃, 120 Hz)
Dissipation factor
After the rated voltage (specified ripple current convolution) is applied at 85℃ for 2000 hours:
Capacitance tolerance: ±15% or less of the initial value
High-temperature load
Dissipation factor: 175% or less of the specified initial value
Leakage current: Specified initial value or less
Others
JIS C 5101-4.
Ripple current correction coefficient
Temperature (°C)
40
60
70
85
Correction coefficient 1.0
0.75 0.62 0.37
Frequency (Hz) 50/60 120
300
1K
≧10K
1.0
1.1
1.3
1.4
Correction coefficient 0.7
Ripple current should be under 60Arms at M5 terminal in
accordance with from the permissible current.
Product symbol : (Example) HCGF5 Series A case 400V 10,000µF
±20%
HCGF5 A 2G 103 Y
Type of bracket
Capacitance code
Rated voltage code
Terminal code A (screw)
Type of series
※
( ) Put first letter of case code to ( ) in case there are two case sizes in
the same CV value.
Standard value and case size
Capacitance
µF
Code
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
39000
271
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
273
333
393
A12
C8R
C8R
C10R
C10R
C12R
D10R
D10R
D13R
D13R
E13R
E13R
F13R
F16R
14.0
14.4
15.8
19.0
21.0
24.7
28.0
30.6
38.6
42.2
49.4
54.7
64.2
75.3
Case code
A10
A12
C8R
C8R
C10R
C12R
C13R
D10R
D10R
E10R
E10R
E13R
E16R
F13R
F16R
10.6
12.7
13.3
14.4
17.4
20.4
23.7
25.4
28.0
32.6
39.0
44.6
53.0
58.2
69.0
Maximum ripple current (A)
at 40°C,120Hz
A10
A10
C8R
C8R
C10R
C12R
D10R
D10R
D12R
D12R
D13R
E12R
E13R
E16R
F16R
8.7
9.5
10.8
12.0
14.6
17.0
19.2
21.0
24.7
27.1
31.5
34.8
40.8
47.8
56.5
A5
A8
A8
A8
A10
A10
C8R
C8R
C10R
C10R
C13R
C13R
D12R
D13R
E12R
E13R
E16R
F16R
F16R
F20R
F24R
4.5
5.8
6.4
7.0
8.3
9.2
10.3
11.5
13.9
15.4
19.3
21.4
24.2
27.9
30.7
35.4
41.7
49.0
54.1
66.2
77.9
A5
A8
A8
A8
A10
A10
C8R
C8R
C10R
C10R
C13R
D10R
D12R
D13R
E12R
E13R
E16R
F16R
F16R
F20R
F24R
4.1
5.3
5.8
6.4
7.6
8.3
9.4
10.3
12.7
13.9
17.4
18.8
22.2
25.4
28.2
32.2
38.0
44.4
49.4
59.1
71.1
Rated voltage V.DC (Code)
160
（2C）
200
（2D）
250
（2E）
350
（2V）
400
（2G）
450
（2W）
A5
A8
A8
A8
A10
A10
C8R
C8R
C10R
C12R
C13R
D10R
D12R
D13R
E12R
E13R
E16R
F16R
F16R
F20R
F24R
3.7
4.9
5.3
5.8
6.9
7.6
8.6
9.4
11.4
13.7
15.8
17.0
20.2
23.4
25.6
29.4
34.6
40.5
44.6
53.9
63.8
Ripple current should be under 60Arms
