REVISION M
DO NOT
SCALE FROM
THIS PRINT
C1
DESIGNED & DIMENSIONED
IN MILLIMETERS
"E" REF (SEE TABLE 2, SHEET 2)
MPSC-XX-XX-XX-X.XX-XX-X-V-XX
POWER PINS (PER END)
OPTION
***-00
*
-01, -02
-LC: LOCKING CLIP
SIGNAL PINS
(USE LC-07-TM)
*-80 (4 X 20)
(SEE FIG. 2, SHT 2)
-48 (4 X 12)
-36 (4 X 9)
VERTICAL
-24 (4 X 6)
M *** -20 (4 x 5)
-16 (4 X 4)
PLATING SPECIFICATION
M *** -12 (4 x 3)
-L: SEE TABLE 3
-08 (4 X 2)
-T: SEE TABLE 3
-04 (4 X 1)
POWER PINS (PER END)
*-01, -02
10.16 .400
***-03, ***-04 M
***-H1,***-H2,***-H3,***-H4
"A" REF
TAIL LENGTH
(H-X INDICATES HOT SWAP
-01: FOR 1.57[.062] THICK PCB
OPTION)
-02: FOR 2.36[.093] THICK PCB
LEAD STYLE
-7.70
01 (POWER)
**
-9.70
(SEE TABLE 1)
* = SEE TABLE 2 FOR AVAILABLE COMBINATIONS
** = NOT TOOLED
M
*** = NOT RELEASED
FIG. 1
MPSC-01-80-01-7.70-01-X-V SHOWN
MPS-XX-XX.XX-V-80
5.08 .200
REF (TYP)
SUB-C-214-XX.XX-XX-X
2.50 .098
REF
"C" REF
C8
"F" REF (SEE TABLE 2, SHEET 2)
4.44 .175 (TYP)
C
L
04
"A"
05
01
C2
1.47
- 0.18
.058
- .007
+0.05
+.002
2.00 .079 REF (TYP)
0.38 .015 REF (TYP)
C
L
"C"
"B"
1.27 .050
REF (TYP)
1.00 .039
REF (TYP)
0.41 .016
REF (TYP)
1.88 .074 (TYP)
0.50 .020 SQ REF (TYP)
C3
"B" REF
C7
"D"
- 0.13
+0.25
C-79-XX-X
C4
"C"
2 MAX SWAY
(TYP)
"B"
0.38 .015 REF
+0.25
"A"
- 0.50
3° MAX
SWAY
CHECK BOW ON THIS SURFACE
2.54 .100
(SEE NOTE 5)
0.79 .031 REF (TYP)
2.54 .100
REF (TYP)
C9
2.54 .100
6.00 .236
(3 EQ SPACES
@ 2.00[.079])
("K" EQ SPACES @ 2.00[.079])
(SEE TABLE 2, SHEET 2)
"J" REF (SEE TABLE 2, SHEET 2)
C5
SECTION "A"-"A"
SECTION "B"-"B"
SECTION "C"-"C"
** = NOT TOOLED
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. BURR ALLOWANCE: 0.038[.0015] MAX.
3. MINIMUM PUSHOUT FORCE: 4.45 N [1.0 LB].
4. PARTS TO BE PACKAGED IN TRAYS.
5. BOW ALLOWED AT .05 MM/MM [.002 IN/IN].
6. MINIMUM SIGNAL CONTACT & -LC PULLOUT FORCE: 4.45 N [1.0 LB]
7. PARTS TO BE PACKAGED IN TRAYS.
F:\DWG\MISC\MKTG\MPSC-XX-XX-XX-X.XX-XX-X-V-XX-MKT.SLDDRW
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILLIMETERS.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
INSULATOR: LCP, COLOR: BLACK
POWER CONTACT: COPPER ALLOY
SIGNAL CONTACT: PHOS BRONZE
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
VERTICAL MINI-POWER W/ SIGNAL SOCKET
MPSC-XX-XX-XX-X.XX-XX-X-V-XX
SHEET
1
OF
3
BY:
BRATCHER 2/16/2007
REVISION M
C1
"F"
MPSC-01-80-01-7.70-01-X-V-LC SHOWN
(SAME AS FIG. 1, UNLESS OTHERWISE STATED)
FIG. 2
12.95 .510
REF
C
L
MPS-02-XX.XX-V-80-LC
28.13 1.107
REF
1.42
- 0.13
.056
- .005
(2 PLCS)
LC-07-TM
+0.33
+.013
C6
C10
"G"
"J"
1.42 .056 REF (TYP)
0.25 .010 REF (TYP)
2.16 .085 REF
IN PROCESS
(ONLY FOR MPSC-XX-XX-XX-X.XX-02-X-V-XX SHOWN)
2 MAX SWAY
(TYP)
C11
C1
"E"
"F"
C
L
SUB-C-XX-X
SUB-C-214-XX.XX-XX-X
C12
5.00 .197 (TYP)
MPS-04-XX.XX-V-80-LC
C
L
C12
C
L
5.00 .197 (TYP)
MPSC-00-24-01-7.70-01-X-V-LC SHOWN
(SAME AS FIG. 1, UNLESS OTHERWISE STATED)
C6
**FIG.
4
M
LC-07-TM
"G"
"J"
***NOT RELEASED FOR PRODUCTION
MPSC-02-80-02-7.70-01-X-V-LC SHOWN
(SAME AS FIG. 1, UNLESS OTHERWISE STATED)
FIG. 3
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.75:1
VERTICAL MINI-POWER W/ SIGNAL SOCKET
MPSC-XX-XX-XX-X.XX-XX-X-V-XX
BY:
BRATCHER 2/16/2007
SHEET
2
OF
3
F:\DWG\MISC\MKTG\MPSC-XX-XX-XX-X.XX-XX-X-V-XX-MKT.SLDDRW
REVISION M
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.75:1
VERTICAL MINI-POWER W/ SIGNAL SOC
MPSC-XX-XX-XX-X.XX-XX-X
SHEET
3
OF
3
F:\DWG\MISC\MKTG\MPSC-XX-XX-XX-X.XX-XX-X-V-XX-MKT.SLDDRW
BY:
BRATCHER 2/16/2007
