SM935E406PAL270 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> SM935E406PAL270

SM935E406PAL270: DescriptionCeramic Capacitor, Multilayer, Ceramic, 50V, 100% +Tol, 0% -Tol, Z5U, -56/+22% TC, 40uF, Surface Mount, DIP; CategoryPassive components capacitor; File Size75KB，3 Pages; ManufacturerAVX

Download Datasheet Parametric View All

SM935E406PAL270 Overview

Ceramic Capacitor, Multilayer, Ceramic, 50V, 100% +Tol, 0% -Tol, Z5U, -56/+22% TC, 40uF, Surface Mount, DIP

SM935E406PAL270 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	AVX
package instruction	DIP
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	40 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
JESD-609 code	e0
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	10 °C
Package shape	RECTANGULAR PACKAGE
positive tolerance	100%
Rated (DC) voltage (URdc)	50 V
surface mount	YES
Temperature characteristic code	Z5U
Temperature Coefficient	-56/+22% ppm/°C
Terminal surface	Tin/Lead (Sn/Pb)
Terminal shape	GULL WING

Preview

Download Datasheet

View All

SMPS Stacked MLC Capacitors

(SM9 Style) Technical Information on SMPS Capacitors

ELECTRICAL SPECIFICATIONS

Temperature Coefficient

C0G: A Temperature Coefficient - 0 ±30 ppm/°C, -55° to +125°C

X7R: C Temperature Coefficient - ±15%, -55° to +125°C

Z5U: E Temperature Coefficient - +22, -56%, +10° to +85°C

Capacitance Test

(MIL-STD-202 Method 305)

C0G: 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

X7R: 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

Z5U: 25°C, 0.5 Vrms max (open circuit voltage) at 1KHz

Dissipation Factor 25°C

C0G: 0.15% Max @ 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

X7R: 2.5% Max @ 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

Z5U: 3.0% Max @ 25°C, 0.5 Vrms max (open circuit voltage) at 1KHz

Insulation Resistance 25°C

(MIL-STD-202 Method 302)

C0G and X7R: 100K MΩ or 1000 MΩ-μF, whichever is less.

Z5U: 10K MΩ or 1000 MΩ-μF, whichever is less.

Insulation Resistance 125°C

(MIL-STD-202 Method 302)

C0G and X7R: 10K MΩ or 100 MΩ-μF, whichever is less.

Z5U: 1K MΩ or 100 MΩ-μF, whichever is less.

Dielectric Withstanding Voltage 25°C

(Flash Test)

C0G and X7R: 250% rated voltage for 5 seconds with 50 mA max

charging current. (500 Volt units @ 750 VDC)

Z5U: 200% rated voltage for 5 seconds with 50 mA max charging

current.

Life Test

(1000 hrs)

C0G and X7R: 200% rated voltage at +125°C. (500 Volt units @

600 VDC)

Z5U: 150% rated voltage at +85°C

Moisture Resistance

(MIL-STD-202 Method 106)

C0G, X7R, Z5U: Ten cycles with no voltage applied.

Thermal Shock

(MIL-STD-202 Method 107, Condition A)

Immersion Cycling

(MIL-STD-202 Method 104, Condition B)

Resistance To Solder Heat

(MIL-STD-202, Method 210,

Condition B, for 20 seconds)

Typical ESR Performance (mΩ)

ESR @ 10KHz

ESR @ 50KHz

ESR @ 100KHz

ESR @ 500KHz

ESR @ 1MHz

ESR @ 5MHz

ESR @ 10MHz

Aluminum

Electrolytic

100μF/50V

300

285

280

265

335

560

Low ESR

Solid Tantalum

100μF/10V

Solid Aluminum

Electrolytic

100μF/16V

MLCC

SMPS

100μF/50V

2.5

12.5

MLCC

SMPS

4.7μF/50V

7.5

HOW TO ORDER

SM9

AVX Styles: SM91, SM92, SM93, SM94, SM95, SM96

106

660

AVX Style

Size

SM9 = Plastic

Case

Size

See

dimen-

sions

chart

Voltage

50V = 5

100V = 1

200V = 2

500V = 7

Temperature

Coefficient

C0G = A

X7R = C

Z5U = E

Capacitance

Test

Code

Tolerance

Level

(2 significant C0G: J = ±5%

A = Standard

digits + no.

K = ±10%

B = Hi-Rel

of zeros)

M = ±20%

10 pF = 100 X7R: K = ±10%

100 pF = 101

M = ±20%

1,000 pF = 102

Z = +80, -20%

22,000 pF = 223 Z5U: Z = +80, -20%

220,000 pF = 224

P = GMV (+100, -0%)

1 μF = 105

10 μF = 106

100 μF = 107

Termination

N = Straight Lead

J = Leads formed

L = Leads formed

out

Height

See table

page 28 for

max cap.

per

height

Note: Capacitors with X7R and Z5U dielectrics are not intended for applications

across AC supply mains or AC line filtering with polarity reversal. Contact plant

for recommendations.

Hi-Rel

screening for C0G and X7R only. Screening consists of 100% Group A

(B Level), Subgroup 1 per MIL-PRF-49470.
