SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 125, REV D.1
1N5415/US thru 1N5420/US
Standard
3A FAST RECOVERY
RECTIFIERS
A
V AI L AB L E AS
1 N , J AN , J AN T X , J AN T XV
J AN S
J AN EQ U I VAL EN T *
SJ*, SX*, SV*, SS*
Fast Recovery Rectifiers
Qualified per MIL-PRF-19500/411
DESCRIPTION:
This voidless hermetically sealed fast recovery rectifier diode series is military qualified per MIL-
PRF-19500/411 and is targeted for space, commerical and military aircraft, military vehicles,
shipboard markets and all high reliability applications.
FEATURES / BENEFITS:
Hermetic, non-cavity glass package
Category I Metallurgically bonded
All parts are 100% hot solder dipped
JAN/ JANTX/ JANTXV available per MIL-PRF-19500/411
“JANS Plus” removes atypical/out of family V
F
ELECTRICAL CHARACTERISTICS
MAX. RATINGS / ELECTRICAL CHARACTERISTICS
RATING
Peak Inverse Voltage (PIV)
1N5415,US
1N5416,US
1N5417,US
1N5418,US
1N5419,US
1N5420,US
Average DC Output Current (I
o
)
Peak Single Cycle Surge
Current (I
fsm
)
-
CONDITIONS
All ratings are at T
A
= 25 C unless otherwise specified.
MIN
-
TYP
-
MAX
50
100
200
400
500
600
3.0
80
UNIT
Vdc
o
T
A
= +55 C
t
p
= 8.3 ms Single Half
Cycle Sine Wave,
Superimposed On
Rated Load
-
I
f
= 9.0A (300
sec
pulse, duty cycle < 2%)
o
-
-
-
-
Amps
Amps(pk)
Operating and Storage Temp.
(T
op
& T
stg
)
Maximum Forward Voltage (V
f
)
1N5415/US, 1N5416,US
1N5417,US, 1N5418,US
1N5419/US, 1N5420,US
Maximum Instantaneous
Reverse Current At Rated (PIV)
-65
-
-
-
+175
C
Volts
1.6
1.7
1.8
-
-
1.0
20
Amps
T
A
= 25 C
T
A
= 100 C
©2013 Sensitron Semiconductor
221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798
www.sensitron.com
sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 125, REV D.1
1N5415/US thru 1N5420/US
Standard
3A FAST RECOVERY
RECTIFIERS
PART ORDERING INFORMATION
The following part numbers can be screened and tested to the military screening flow. The parts are marked in
accordance with the testing performed, example:
Sensitron Screening Level
1N
JAN
JANTX
JANTXV
SJ
SX
SV
JANS
SS
*Part Number--
Leaded Package
(example for 1N5415)
1N5415
JAN1N5415
JANTX1N5415
JANTXV1N5415
SJ5415
SX5415
SV5415
JANS1N5415
SS5415
*Part Number--
Surface Mount Package
(example for 1N5415US)
1N5415US
JAN1N5415US
JANTX1N5415US
JANTXV1N5415US
SJ5415US
SX5415US
SV5415US
JANS1N5415US
SS5415US
*Parts can also be ordered Tape & Reel
