DAC1214U: DescriptionQUAD, SERIAL INPUT LOADING, 0.5 us SETTLING TIME, 12-BIT DAC, PDSO28, SOIC-28; CategoryAnalog mixed-signal IC converter; File Size864KB，8 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

DAC1214U Overview

QUAD, SERIAL INPUT LOADING, 0.5 us SETTLING TIME, 12-BIT DAC, PDSO28, SOIC-28

DAC1214U Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOP,
Contacts	28
Reach Compliance Code	unknown
Maximum analog output voltage	5 V
Minimum analog output voltage	-5 V
Converter type	D/A CONVERTER
Enter bit code	BINARY
Input format	SERIAL
JESD-30 code	R-PDSO-G28
JESD-609 code	e0
Maximum linear error (EL)	0.0244%
Humidity sensitivity level	2A
Number of digits	12
Number of functions	4
Number of terminals	28
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	220
Certification status	COMMERCIAL
Nominal settling time (tstl)	0.5 µs
Nominal supply voltage	5 V
surface mount	YES
technology	BICMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.52 mm
