High Power Low Ohmic Chip Resistors<Wide Terminal type>
LTR10 (2012 size : 1 / 2W)
Features
1) Improved welding strength
The structure of longer electrodes provides the wider welding area than the chip resistors with normal electrodes, and this
enhanced the solder welding strength.
2) Increased surge-resistance
This is achieved by Rohm’s original trimming technology plus resistive element patterning.
3) High-power tolerance
Two times of the rated power is guaranteed than the normal-electrode resistors.
4) ROHM resistors are ISO-9001 & ISO/TS16949 certified.
Design and specifications are subject to change without notice. Carefully check the specification sheet before using or
ordering it.
Applications
Automotive, industrial and power supply.
Ratings
Item
Rated power
Conditions
Power must be derated according to the power derating curve in
Figure 1 when ambient temperature exceeds 70°C.
100
80
POWER LOAD (%)
Specifications
0.5W (1 /2W)
at 70°C
60
40
20
0
−55
0
70
100
155
AMBIENT TEMPERATURE (
°
C)
Fig.1
Rated voltage
Rated current
The voltage rating is calculated by the following equation.
E=
I =
P
×
R
P/R
E : Rated voltage (V)
I : Rated current (A)
P : Rated power (W)
R : Nominal resistance (Ω)
Nominal resistance
Operating temperature
Table 1
Resistance range
(Ω)
See Table 1.
−55°
C to
+ 155°C
Resistance
tolerance
F (±1%)
J (±5%)
Special part number
Resistance temperature coefficient
(ppm/°C)
0.047 to 9.1
S
L
±150
Before using components in circuits where they will be exposed to transients such as pulse loads (short–duration, high– level loads), be certain to evaluate the
component in the mounted state. In addition, the reliability and performance of this component cannot be guaranteed if it is used with a steady state voltage that
is greater than its rated voltage.
www.rohm.com
c
○
2009 ROHM Co., Ltd. All rights reserved.
1/3
2009.10 - Rev.B
LTR10
Characteristics
Item
Guaranteed value
Resistor type
Test conditions (JIS C 5201-1)
JIS C 5201-1 4.5
Voltage : A
Measuring method : Measure under termination by 4 probes
Under termination
Terminal
Data Sheet
Resistance
F :
±1%
J :
±5%
Variation of resistance
with temperature
See Table.1
JIS C 5201-1 4.8
Measurement :
−55
/
+25
/
+125°C
JIS C 5201-1 4.13
Rated voltage (current)
×
2.5, 2s.
JIS C 5201-1 4.17
Rosin·Ethanol (25%WT)
Soldering condition : 235±5°C
Duration of immersion : 2.0±0.5s.
JIS C 5201-1 4.18
Soldering condition : 260±5°C
Duration of immersion : 10±1s.
JIS C 5201-1 4.19
Test temp. :
−55°C
to
+125°C
5cyc
JIS C 5201-1 4.24
40°C, 93%RH
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.1
Rated voltage (current), 70°C
1.5h : ON
−
0.5h : OFF
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.3
155°C
Test time : 1,000h to 1,048h
JIS C 5201-1 4.29
23±5°C, Immersion cleaning, 5±0.5min.
Solvent : 2-propanol
JIS C 5201-1 4.33
Overload
±
(2.0%+0.1Ω)
Solderability
A new uniform coating of minimum of
95% of the surface being immersed
and no soldering damage.
±
(1.0%+0.005Ω)
No remarkable abnormality on the appearance.
±
(1.0%+0.005Ω)
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
±
(3.0%+0.005Ω)
Endurance at 70°C
±
(3.0%+0.005Ω)
Endurance
±
(3.0%+0.005Ω)
Resistance to solvent
Bend strength of
the end face plating
±
(0.5%+0.005Ω)
Without open.
www.rohm.com
c
○
2009 ROHM Co., Ltd. All rights reserved.
2/3
2009.10 - Rev.B
