KQ
high Q inductor
features
•
Surface mount
•
Flat top suitable for high speed pick-and-place
components
•
Excellent high frequency applications
•
High Q factors and self-resonant frequency values
•
Marking: Black body color with white marking
(0603, 0805, 1008)
White body color with no marking
(0402)
inductors
dimensions and construction
L
W1
Flat Top
Film
Ceramic
Core
h
d
Magnetic
Wire
W2
Electrode
Size
Code
KQ0402
t
L
W1
Dimensions
inches
(mm)
W2
t
h
d
.04±.004 .022±.031 .02±.004 .022±.004 .006±.004 .01±.004
(1.1±0.1) (0.55±0.1) (0.5±0.1) (0.55±0.1) (0.15±0.1) (0.25±0.1)
.01±.006
KQ0603
.063±.004 .039±.004 .033±.004 .035±.004
(0.25±0.15)
.014±.004
(1.6±0.1) (1.0±0.1) (0.85±0.1) (0.9±0.1)
(0.35±0.1)
.016±.006
KQ0805
.079±.008 .059±.008 .053±.004 .051±.008
(0.40±0.15)
.018±.004
(2.0±0.2) (1.5±0.2) (1.35±0.1) (1.3±0.2)
(0.45±0.1)
.071
+.008
.018±.006 .018±.004
-0
KQ1008
.098±.008 .087±.008 .079±.004
(2.5±0.2) (2.2±0.2) (2.0±0.1) (1.8
+0.2
) (0.45±0.15) (0.45±0.1)
-0
0402
KQT0402
.039±.004 .02±.004
(1.0±0.1) (0.5±0.1)
.02±.004 .022±.004 .006±.004 .01±.004
(0.5±0.1) (0.55±0.1) (0.15±0.1) (0.25±0.1)
L
W1
Flat Top
Film
t
h
Ceramic/Ferrite
Core
Electrode
W2
KQT0402, KQ0603, 0805, 1008
d
Magnetic Inner
Wire
Coating
ordering information
Old Part #
New Part #
KQ
KQ
Type
KQ
KQT
1008
1008
Size Code
0402
0603
0805
1008
L
Termination
Material
L: SnPb
T: Sn
TE
TE
Packaging
TE: 7" embossed plastic
TD: 7" paper tape
10N
10N
Nominal
Resistance
10N: 10nH
R10: 0.1µH
1R0: 1.0µH
J
J
Tolerance
C: 0.2nH
G: ±2%
H: ±3%
J: ±5%
K: ±10%
M:±20%
For further information
on packaging, please
refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
11/01/03
