Ordering number : ENA1062A
2SC5226A
SANYO Semiconductors
DATA SHEET
2SC5226A
Features
•
•
•
NPN Epitaxial Planar Silicon Transistor
VHF to UHF Wide-Band Low-Noise
Amplifier Applications
Low-noise
: NF=1.0dB typ (f=1GHz)
High gain
:
⏐
S21e
⏐
2
=12dB typ (f=1GHz)
High cut-off frequency : fT=7GHz typ
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
VCBO
VCEO
VEBO
IC
PC
Tj
Tstg
Conditions
Ratings
20
10
2
70
150
150
-
-55 to +150
Unit
V
V
V
mA
mW
°C
°C
Package Dimensions
unit : mm (typ)
7023A-009
2.0
3
0.15
Product & Package Information
• Package
: MCP
• JEITA, JEDEC
: SC-70, SOT-323
• Minimum Packing Quantity : 3,000 pcs./reel
2SC5226A-4-TL-E
2SC5226A-5-TL-E
0.425
Packing Type: TL
Marking
LOT No.
1.25
2.1
0 to 0.08
0.2
LN
0.425
1
0.65
2
0.3
TL
R
A
N
K
LOT No.
Electrical Connection
1 : Base
2 : Emitter
3 : Collector
SANYO : MCP
1
3
0.9
0.3
2
http://semicon.sanyo.com/en/network
71812 TKIM/51408AB TIIM TC-00001340 No. A1062-1/8
2SC5226A
Electrical Characteristics
at Ta=25°C
Parameter
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain-Bandwidth Product
Output Capacitance
Reverse Transfer Capacitance
Forward Transfer Gain
Noise Figure
Symbol
ICBO
IEBO
hFE
fT
Cob
Cre
⏐S21e⏐
1
⏐S21e⏐
2
NF
2
2
Conditions
VCB=10V, IE=0A
VEB=1V, IC=0A
VCE=5V, IC=20mA
VCE=5V, IC=20mA
VCB=10V, f=1MHz
VCE=5V, IC=20mA, f=1GHz
VCE=2V, IC=3mA, f=1GHz
VCE=5V, IC=7mA, f=1GHz
Ratings
min
typ
max
1.0
10
60*
5
7
0.75
0.5
9
12
8
1.0
1.8
1.2
270*
Unit
μA
μA
GHz
pF
pF
dB
dB
dB
*
: The 2SC5226A is classified by 20mA hFE as follows :
Rank
hFE
3
60 to 120
4
90 to 180
5
135 to 270
Ordering Information
Device
2SC5226A-4-TL-E
2SC5226A-5-TL-E
Package
MCP
MCP
Shipping
3,000pcs./reel
3,000pcs./reel
memo
Pb Free
3
2
hFE -- IC
VCE=5V
2
fT -- IC
VCE=5V
Gain-Bandwidth Product, fT -- GHz
10
7
5
DC Current Gain, hFE
100
7
5
3
2
3
2
10
7
5
3
5
7 1.0
2
3
5
7 10
2
3
5
7 100
2
ITR07919
1.0
7
5
7
1.0
2
3
5
7
10
2
3
5
7 100
2
ITR07920
Collector Current, IC -- mA
3
2
Cob -- VCB
Reverse Transfer Capacitance, Cre -- pF
f=1MHz
Collector Current, IC -- mA
3
2
Cre -- VCB
f=1MHz
Output Capacitance, Cre -- pF
1.0
7
5
3
2
1.0
7
5
3
2
0.1
7
5
7
0.1
2
3
5
7 1.0
2
3
5
7 10
2
3
0.1
7
5
7 0.1
2
3
5
7 1.0
2
3
5
7
10
2
3
Collector-to-Base Voltage, VCB -- V
ITR07921
Collector-to-Base Voltage, VCB -- V
ITR07922
No. A1062-2/8
2SC5226A
14
⏐
S21e
⏐
2
-- IC
f=1GHz
12
NF -- IC
VCE=5V
f=1GHz
Forward Transfer Gain,⏐
S21e
⏐
2
-- dB
12
10
V
10
Noise Figure, NF -- dB
5
7 10
2
3
5
7 100
2
ITR07924
V
CE =
5
8
8
V
CE
=2
V
6
6
4
4
2
2
0
3
5
7 1.0
2
3
0
3
5
7 1.0
2
3
5
7 10
2
3
5
Collector Current, IC -- mA
160
150
140
120
100
80
60
40
20
0
0
PC -- Ta
Collector Current, IC -- mA
7 100
2
ITR07923
Collector Dissipation, PC -- mW
20
40
60
80
100
120
140
160
Ambient Temperature, Ta --
°C
ITR07925
No. A1062-3/8
2SC5226A
f=100MHz, 200MHz to 2000MHz(200MHz Step)
j50
j25
j100
j150
j10
j200
j250
150°
f=100MHz, 200MHz to 2000MHz(200MHz Step)
0.1GH
z
120°
90°
VCE=5V
IC=20mA
60°
VCE =5V
IC =7mA
2.0GHz
0
10
2.0GHz
2.0GHz
25
50 100
150 250
±180°
VCE=2V
0.1GHz
I =3mA
C
0.1GHz
2.0GHz
2.0GHz
8
2.0GHz
4
30°
12
16 20
0
VCE=2V
IC=3mA
VCE=5V
IC=20mA
--j10
0.1GHz
VCE=5V
IC=7mA
0.1GHz
--j25
--j50
--j250
--j200
--j150
0.1GHz
--j100
--150°
--30°
--120°
ITR07926
--60°
--90°
ITR07927
f=100MHz, 200MHz to 2000MHz(200MHz Step)
90°
120°
f=100MHz, 200MHz to 2000MHz(200MHz Step)
2.0GHz
j50
60°
2.0GHz
j25
j100
j150
j10
j200
j250
VCE=5V
IC=20mA
150°
2.0GHz
VCE=2V
30°
IC=3mA
VCE=5V
IC=7mA
±180°
0.1GHz
0.1GHz
0.04 0.08 0.12 0.16 0.2
0
0.1GHz
0
10
25
50
100
150
250
VCE=5V
IC=7mA
2.0GHz
VCE=5V
IC=20mA
--j10
--150°
--30°
2.0GHz
2.0GHz
V =2V
CE
IC=3mA
--j250
--j200
--j150
--j100
--j25
--120°
--90°
--60°
ITR07928
--j50
ITR07929
No. A1062-4/8
2SC5226A
S Parameters (Common emitter)
VCE=5V, IC=7mA, ZO=50
Ω
Freq(MHz)
100
200
400
600
800
1000
1200
1400
1600
1800
2000
⏐
S11
⏐
0.720
0.612
0.497
0.456
0.440
0.436
0.434
0.433
0.433
0.434
0.439
∠
S11
-46.0
-80.9
-121.3
-143.5
-157.6
-167.5
-176.1
176.6
170.9
165.0
159.6
⏐
S21
⏐
17.973
13.927
8.656
6.080
4.725
3.864
3.258
2.847
2.329
2.252
2.057
∠
S21
148.5
127.3
105.0
92.8
84.3
77.0
70.3
64.5
57.4
54.2
49.2
⏐
S12
⏐
0.030
0.047
0.066
0.079
0.094
0.110
0.126
0.143
0.160
0.178
0.197
∠
S12
68.5
57.1
51.3
52.9
55.4
56.8
57.9
58.4
58.9
58.6
58.1
⏐
S22
⏐
0.880
0.697
0.479
0.382
0.339
0.323
0.312
0.304
0.296
0.293
0.294
∠
S22
-23.6
-37.6
-47.6
-50.5
-51.8
-53.4
-55.8
-58.3
-62.0
-65.0
-68.1
VCE=5V, IC=20mA, ZO=50
Ω
Freq(MHz)
100
200
400
600
800
1000
1200
1400
1600
1800
2000
⏐
S11
⏐
0.481
0.420
0.391
0.386
0.381
0.382
0.385
0.388
0.390
0.391
0.394
∠
S11
-78.8
-119.2
-151.6
-166.4
-175.9
178.2
172.1
166.7
162.1
156.7
152.1
⏐
S21
⏐
29.795
19.008
10.416
7.084
5.407
4.401
3.701
3.217
2.839
2.534
2.319
∠
S21
132.9
112.2
95.4
86.6
80.1
74.1
68.5
63.6
58.8
54.3
50.1
⏐
S12
⏐
0.022
0.033
0.052
0.071
0.092
0.114
0.134
0.156
0.176
0.197
0.219
∠
S12
63.9
60.8
64.7
67.2
68.4
67.8
66.8
65.6
64.0
62.4
60.6
⏐
S22
⏐
0.707
0.470
0.296
0.236
0.213
0.208
0.204
0.202
0.199
0.197
0.197
∠
S22
-38.2
-51.1
-55.3
-56.1
-56.6
-57.9
-60.7
-63.5
-67.9
-71.2
-74.2
VCE=2V, IC=3mA, ZO=50
Ω
Freq(MHz)
100
200
400
600
800
1000
1200
1400
1600
1800
2000
⏐
S11
⏐
0.858
0.782
0.653
0.588
0.557
0.543
0.536
0.533
0.527
0.525
0.528
∠
S11
-32.4
-60.7
-101.1
-126.5
-143.7
-156.3
-166.8
-175.5
177.0
170.3
163.8
⏐
S21
⏐
9.413
8.187
5.855
4.337
3.444
2.871
2.446
2.145
1.904
1.714
1.564
∠
S21
157.2
138.5
113.8
98.4
87.7
78.5
70.5
63.5
57.1
51.7
45.9
⏐
S12
⏐
0.040
0.070
0.101
0.114
0.122
0.130
0.137
0.146
0.155
0.168
0.183
∠
S12
72.6
59.2
44.5
39.1
38.0
38.6
40.3
42.5
45.0
47.3
49.2
⏐
S22
⏐
0.945
0.833
0.637
0.515
0.454
0.426
0.407
0.393
0.382
0.379
0.378
∠
S22
-16.5
-29.3
-43.2
-50.0
-53.8
-57.1
-60.3
-63.8
-68.0
-72.0
-75.8
No. A1062-5/8
