1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0005
General Information
Part Number:
76650-0005
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Country of Origin:
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire:
Product Highlights
Molex offers one of the industry's broadest selections of high-density
FFC/FPC connectors for Flat Panel Display (FPD) and other high pincount
applications. Molex applied its existing Easy-On™ actuator technologies
to create a robust connector that has a strong latch and is easy to use.
Molex offers a complete product line of FFC jumpers to terminate to ZIF (zero
insertion force) connectors for a flexible interconnection.
Features and Benefits
Applications
Wire-to-Board
0.5mm (0.020”)
Receptacles
Right Angle
6, 8, 10, 12, 14 and 16
0.5 Amps
30 Volts (Premo-Flex™FFC Jumper) and 50 Volts (FPC Connector)
Flat Flex Cable
Molex / Waldom
FFC/FPC Connector Kit
Ultra Low Profile SMT ZIF Right Angle Receptacle and Premo-Flex Cable
FFC/FPC Connectors
(Molex Parts within this kit) - EU and China RoHS Compliant
Kit assembled in U.S.A.
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 3
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0005
• Robust design, more durable than
competition
• Low profiles, space savings
• Contact area on same or opposite side of
jumper
• FFC Jumpers are used in many industries
and applications where the total installed
cost is considered important
• Design flexibility
• Suitable for movable extension of printed
circuit boards and/or displays units
• Plasma Display Panels (PDP)
• Liquid Crystal Display (LCD) Panels
• HDTV, TV Tuners and Set Top Box
• Power Units
• Notebook PCs and Keyboards
• Printers and Scanners
• Camcorders and CD Players
• Video Games
• Automotive
• Military
• Medical
• Industrial
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 3
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0005
Bill of Materials for Part No. 76650-0005
Molex Part No.
21020-0055
21020-0077
21020-0099
21020-0121
21020-0143
21020-0165
54548-0670
54548-1270
54548-1670
54550-0694
54550-0894
54550-1094
54550-1494
Country
of Origin
USA
USA
USA
USA
USA
USA
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Description
0.5mm FFC Jumper, 6 Circuit, 3" long
0.5mm FFC Jumper, 8 Circuit, 3" long
0.5mm FFC Jumper, 10 Circuit, 3" long
0.5mm FFC Jumper, 12 Circuit, 3" long
0.5mm FFC Jumper, 14 Circuit, 3" long
0.5mm FFC Jumper, 16 Circuit, 3" long
0.5mm FPC Connector R/A, Bottom Style, 6 CKT, ZIF, Low
Profile
0.5mm FPC Connector R/A, Bottom Style, 12 CKT, ZIF, Low
Profile
0.5mm FPC Connector R/A, Bottom Style, 16 CKT, ZIF, Low
Profile
0.5mm FPC Connector R/A, Top Style, 6 CKT, ZIF, Low
Profile
0.5mm FPC Connector R/A, Top Style, 8 CKT, ZIF, Low
Profile
0.5mm FPC Connector R/A, Top Style, 10 CKT, ZIF, Low
Profile
0.5mm FPC Connector R/A, Top Style, 14 CKT, ZIF, Low
Profile
Quantity in
Kit
2
2
2
2
2
2
5
5
5
5
5
5
5
No Recommended Molex Tool for Part No. 76650-0005
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 3 of 3
