We, Samsung, declare that our component EMC is produced in accordance
with EU RoHS directive.
1.RoHS Compliance and restriction of Br
The following restricted materials are not used in packaging materials as well as products in compliance with the law and restriction.
- Cd, Pb, Hg, Cr6+, As, Br and the compounds, PCB, asbestos
2.No use of materials breaking Ozone layer
The following ODS materials are not used in our fabrication process.
- ODS material : Freon, Haron, 1-1-1 TCE, CCl4, HCFC
If you want more detailed Information,Please Visit Samsung Electro-mechanics Website
[http://www.semlcr.com]
Please, see the last page of this catalog for our environmental certi cation list.
CONTENTS
Product Guide
Chip Inductors
CIGT Series(Power Inductor)
CIG Series (Power Inductor)
CIH Series (High Frequency Inductor)
CIL Series (General Inductor)
4
7
11
21
33
Chip Beads
CIB/CIM Series (For General)
CIC/CIS Series (For High Current)
CIV Series (For GHz Noise suppression)
41
58
77
EMI Products
Filters
Common Mode Filter
3 Terminal Capacitor
79
83
Products For Communication Equipment
Diplexer
Band Pass/Low Pass Filter
85
88
Appendix
Soldering Condition
Packaging
95
96
Metal Composite Power Inductor
Product
Product
Guide
Guide
Type
Series
CIGT201210UM
Metal Composite
Thin Film
Power Inductor
DC-DC
Converter
CIGT201608UM
CIGT201610UM
CIGT201610LM
CIGT252010LM
CIGT252012LM
Size Code
mm (inch)
2012(0805)
2016(0806)
2016(0806)
2016(0806)
2016(0806)
2520(1008)
Inductance(H) Range
1n
10n
100n
1u
10u
100u
1m
0.16~1.5
μ
H
0.24~2.2
μ
H
0.24~2.2
μ
H
0.24~1.0
μ
H
0.47~1.0
μ
H
0.47~1.0
μ
H
Ferrite Multilayer Power Inductor
Type
Series
CIG10F(Low Profile)
CIG10W(Normal)
CIG10L(Low Rdc)
CIG21F(Low Profile)
Ferrite Multilayer
Power Inductor
DC-DC
Converter
CIG21L(Low Rdc)
CIG2MW
CIG22L(Low Rdc)
CIG22H(High Current)
CIG22E(High Efficiency Type)
CIG21E(High Current Type)
CIG22B
Size Code
mm (inch)
1608(0603)
1608(0603)
1680(0603)
2012(0805)
2012(0805)
2012(0805)
2520(1008)
2520(1008)
2520(1008)
2012(0805)
2520(1008)
Inductance(H) Range
1n
10n
100n
1u
10u
100u
1m
0.47~2.2
μ
H
0.27~4.7
μ
H
2.5
μ
H
0.47~2.2
μ
H
0.47~4.7
μ
H
0.47~4.7
μ
H
0.47~10
μ
H
0.33~4.7
μ
H
0.47~4.7
μ
H
0.47~2.2
μ
H
0.27~4.7
μ
H
Inductor
Type
Series
CIL05
General Frequency
range
CIL10
CIL21
CIL31
CIH02T
CIH03T
CIH03Q
High Frequency
range
CIH03U
CIH03W
CIH05T
CIH05Q
CIH10T
Size Code
mm (inch)
1005(0402)
1608(0603)
2012(0805)
3216(1206)
0402(01005)
0603(0201)
0603(0201)
0603(0201)
0603(0201)
1005(0402)
1005(0402)
1608(0603)
Inductance(H) Range
1n
10n
100n
1u
10u
100u
1m
2.2
μ
H
0.047~33
μ
H
0.047~33
μ
H
0.047~33
μ
H
0.4~47nH
0.6~100nH
0.6~100nH
0.6~100nH
0.6~22nH
1~100nH
1~270nH
1~270nH
4
5
