Standard Products
MUX8562 Dual 16-Channel Analog Multiplexer Module
+5V, Radiation Tolerant
Preliminary
www.aeroflex.com/mux
December 7, 2009
FEATURES
❑
❑
❑
32-channels provided by two independent 16-channel multiplexers
Single +5V power supply
Radiation performance
- Total dose:
150 krads(Si), Dose rate = 50 - 300 rads(Si)/s
- SEU:
Immune up to 90 MeV-cm
2
/mg
- SEL:
Immune by process design
Full military temperature range
Low power consumption < 5mW
CMOS analog switching allows rail to rail operation and low switch impedance
Separate address (A
0-3
& B
0-3
) and enable (EN
0-15
& EN
16-31
) for CH
0-15
and CH
16-31
Fast access time < 500ns typical
Break-Before-Make switching
High analog input impedance (power on or off )
Designed for aerospace and high reliability space applications
Packaging – Hermetic ceramic
- 56 leads, 0.80"Sq x 0.20"Ht quad flat pack
- Typical Weight 6 grams
DSCC SMD 5962-10209 pending
Note: Aeroflex Plainview does not currently have a DSCC certified Radiation Hardened Assurance Program.
❑
❑
❑
❑
❑
❑
❑
❑
❑
❑
GENERAL DESCRIPTION
Aeroflex’s MUX8562 is a radiation tolerant +5V only Dual 16 channel multiplexer MCM (Multi Chip
Module).
The MUX8562 has been specifically designed to meet exposure to radiation environments. It is available in
a 56 lead High Temperature Co-Fired Ceramic (HTCC) Quad Flatpack (CQFP). It is guaranteed
operational from -55°C to +125°C. Available screened in accordance with MIL-PRF-38534, the
MUX8562 is ideal for demanding military and space applications.
ORGANIZATION AND APPLICATION
The MUX8562 consists of two independent 16 channel +5V only multiplexers arranged as shown in the
block diagram.
A Section
Sixteen (16) channels addressable by bus A
0
~A
3
, enabled by EN
0-15
and outputted on Output1(
0-15).
B Section
Sixteen (16) channels addressable by bus B
0
~B
3
, enabled by EN
16-31
and outputted on Output2(
16-31).
SCD8562 Rev A
SECTION A
CH 0
16
CH 15
•
•
•
MUX 1
OUTPUT1 (0-15)
EN 0-15
A0
A1
A2
A3
SECTION B
CH 16
16
CH 31
•
•
•
MUX 2
OUTPUT2 (16-31)
EN 16-31
B0
B1
B2
B3
+V
EE
V
REF
GND
MUX8562: DUAL 16 CHANNEL ANALOG MUX BLOCK DIAGRAM
SCD8562 Rev A
Preliminary
12/07/09
2
Aeroflex Plainview
ABSOLUTE MAXIMUM RATINGS
1/
Parameter
Case Operating Temperature Range
Storage Temperature Range
Supply Voltage
+V
EE
(Pin 18)
V
REF
(Pin 39)
Digital Input Overvoltage
V
EN
0-15 (Pin 13), V
EN
16-31 (Pin 44), V
A
(Pins 14, 15, 16, 17), V
B
(Pins 40, 41, 42, 43)
Analog Input Over Voltage
V
S
Notes:
1/ All measurements are made with respect to ground.
NOTICE: Stresses above those listed under "Absolute Maximums Rating" may cause permanent damage to the device. These are stress rating
only; functional operation beyond the "Operation Conditions" is not recommended and extended exposure beyond the "Operation Conditions" may
affect device reliability.
Range
-55 to +125
-65 to +150
+7.5
+7.5
< V
REF
+0.5
> GND -0.5
-0.5 < Vs < +7.5
Units
°C
°C
V
V
V
V
V
RECOMMENDED OPERATING CONDITIONS
1/
Symbol
+V
EE
V
REF
V
AL
V
AH
+5V Power Supply Voltage
Reference Voltage
Logic Low Level
Logic High Level
Parameter
Typical
+5.0
+5.00
+0.8
+4.0
Units
V
V
V
V
1/ Power Supply turn-on sequence shall be as follows: +V
EE
, followed by V
REF
(or tie these together).
DC ELECTRICAL PERFORMANCE CHARACTERISTICS
1/
(T
C
= -55°C to +125°C, +V
EE
= +5V, V
REF
= +5.0V - Unless otherwise specified)
Parameter
Supply Current
Symbol
+I
EE
+I
SBY
Address Input Current
I
AL
(0-3)
A
I
AH
(0-3)
A
I
AL
(0-3)
B
I
AH
(0-3)
B
Enable Input Current
I
ENL
(0-15)
I
ENH
(0-15)
I
ENL
(16-31)
I
ENH
(16-31)
Conditions
V
EN
(0-15) = V
EN
(16-31) = V
A
(0-3) = V
B
(0-3) = 0
V
EN
(0-15) = V
EN
(16-31) = 4V, V
A
(0-3) = V
B
(0-3) = 0 7/
V
A
= 0V
V
A
= 5V
V
B
= 0V
V
B
= 5V
V
EN
(0-15) = 0V
V
EN
(0-15) = 5V
V
EN
(16-31) = 0V
V
EN
(16-31) = 5V
Min
Max
Units
mA
mA
μA
μA
μA
μA
μA
μA
μA
μA
0
0
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
SCD8562 Rev A
Preliminary
12/07/09
3
Aeroflex Plainview
DC ELECTRICAL PERFORMANCE CHARACTERISTICS
1/
(continued)
(T
C
= -55°C to +125°C, +V
EE
= +5V, V
REF
= +5.0V - Unless otherwise specified)
Parameter
Positive Input Leakage
Current CH0-CH31
Negative Input Leakage
Current CH0-CH31
Positive Output
Leakage Current
OUTPUTS (pins 12,45)
Switch ON Resistance
OUTPUTS
(pins 12,45) 6/
Symbol
+I
SOFFOUTPUT
(
ALL
)
-I
SOFFOUTPUT
(
ALL
)
Conditions
V
IN
= +5V, V
EN
= 4V, output and all unused MUX inputs
under test = 0V 2/, 3/
V
IN
= 0V, V
EN
= 4V, output and all unused MUX inputs
under test = +5V 2/, 3/
V
OUT
= +5V, V
EN
= 4V, and inputs grounded except
channel being tested. 3/, 4/
Min
-100
-100
Max
+100
+100
Units
nA
nA
+I
DOFFOUTPUT
(
ALL
)
-50
+1500
nA
R
DS
(
ON
)(0-31)
A
V
IN
= +5V, V
EN
= 0.8V, I
OUT
= -1mA 2/, 3/, 5/
50
1000
Ω
Notes:
1/ Measure inputs sequentially. Ground all unused inputs of the device under test. V
A
is the applied input voltage to the address lines A(0-3). V
B
is
the applied input voltage to the address lines B(0-3).
2/ V
IN
is the applied input voltage to the input channels CH0-CH31.
3/ V
EN
is the applied input voltage to the enable line EN (0-15) and EN (16-31)
4/ V
OUT
is the applied input voltage to the output lines OUTPUT1 (0-15), OUTPUT2 (16-31)
5/ Negative current is the current flowing out of each of the MUX pins. Positive current is the current flowing into each MUX pin.
6/ The MUX8562 cannot be operated with analog inputs below 0 volts.
7/ Not tested, guaranteed to the specified limits.
SWITCHING CHARACTERISTICS
((T
C
= -55°C
TO
+125°C, +V
EE
= +5V,
V
REF
= +5.0V - U
NLESS OTHERWISE SPECIFIED
))
Parameter
Switching Test MUX
Symbol
tAHL
tALH
t
ON
EN
t
OFF
EN
Conditions
R
L
= 10K
Ω
,
C
L
= 50pF
Min
100
100
100
Max
700
700
700
700
Units
ns
ns
ns
ns
R
L
= 1K
Ω
,
C
L
= 50pF
100
SCD8562 Rev A
Preliminary
12/07/09
4
Aeroflex Plainview
16
TRUTH TABLE (CH0 – CH15)
A3
X
L
L
L
L
L
L
L
L
H
H
H
H
H
H
H
H
A2
X
L
L
L
L
H
H
H
H
L
L
L
L
H
H
H
H
A1
X
L
L
H
H
L
L
H
H
L
L
H
H
L
L
H
H
A0
X
L
H
L
H
L
H
L
H
L
H
L
H
L
H
L
H
EN (0-15)
H
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
"ON" CHANNEL, 1/ (OUTPUT 1)
NONE
CH0
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10
CH11
CH12
CH13
CH14
CH15
1/ Between CH0-15 and OUTPUT1 (0-15)
TRUTH TABLE (CH16 – CH31)
B3
X
L
L
L
L
L
L
L
L
H
H
H
H
H
H
H
H
B2
X
L
L
L
L
H
H
H
H
L
L
L
L
H
H
H
H
B1
X
L
L
H
H
L
L
H
H
L
L
H
H
L
L
H
H
B0
X
L
H
L
H
L
H
L
H
L
H
L
H
L
H
L
H
EN (16-31)
H
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
"ON" CHANNEL, 1/ (OUTPUT 2)
NONE
CH16
CH17
CH18
CH19
CH20
CH21
CH22
CH23
CH24
CH25
CH26
CH27
CH28
CH29
CH30
CH31
1/ Between CH16-31 and OUTPUT2 (16-31)
SCD8562 Rev A
Preliminary
12/07/09
5
Aeroflex Plainview
