IDT74LVCH32245A
3.3V CMOS 32-BIT BUS TRANSCEIVER WITH 3-STATE OUTPUTS
INDUSTRIAL TEMPERATURE RANGE
3.3V CMOS 32-BIT
IDT74LVCH32245A
BUS TRANSCEIVER
WITH 3-STATE OUTPUTS,
5 VOLT TOLERANT I/O, BUS-HOLD
• Typical t
SK(o)
(Output Skew) < 250ps
• ESD > 2000V per MIL-STD-883, Method 3015; > 200V using
machine model (C = 200pF, R = 0)
• V
CC
= 3.3V ± 0.3V, Normal Range
• V
CC
= 2.7V to 3.6V, Extended Range
• CMOS power levels (0.4μ W typ. static)
μ
• All inputs, outputs, and I/O are 5V tolerant
• Supports hot insertion
• Available in 96-ball LFBGA package
FEATURES:
DESCRIPTION:
DRIVE FEATURES:
• Balanced Output Drivers: ±24mA
• Reduced system switching noise
APPLICATIONS:
This 32-bit bus transceiver is built using advanced dual metal CMOS
technology. This high-speed, low power transceiver is ideal for asynchro-
nous communication between two busses (A and B). The Direction and
Output Enable controls are designed to operate the device as either four
independent 8-bit transceivers or one 32-bit transceiver. The direction
control pins (DIR) control the direction of data flow. The output enable pins
(OE) override the direction control and disable both ports. All inputs are
designed with hysteresis for improved noise margin.
All pins can be driven from either 3.3V or 5V devices. This feature allows
the use of this device as a translator in a mixed 3.3V/5V supply system.
The LVCH32245A has been designed with a
±
24mA output driver. This
driver is capable of driving a moderate to heavy load while maintaining
speed performance
The LVCH32245A has “bus-hold” which retains the inputs’ last state
whenever the input goes to a high impedance. This prevents floating inputs
and eliminates the need for pull-up/down resistors.
• 5V and 3.3V mixed voltage systems
• Data communication and telecommunication systems
FUNCTIONAL BLOCK DIAGRAM
A3
A4
J3
J4
1
DIR
3
DIR
1
OE
3
OE
1
A
1
A5
A2
3
A
1
1
B
1
J5
J2
3
B
1
TO SEVEN OTHER CHANNNELS
TO SEVEN OTHER CHANNNELS
2
DIR
H3
H4
4
DIR
2
OE
T3
T4
4
OE
4
A
1
N5
N2
2
A
1
E5
E2
2
B
1
4
B
1
TO SEVEN OTHER CHANNNELS
TO SEVEN OTHER CHANNNELS
IDT and the IDT logo are registered trademarks of Integrated Device Technology, Inc.
INDUSTRIAL TEMPERATURE RANGE
©2016 Integrated Device Technology, Inc.
1
FEBRUARY 2016
DSC-4767/5
IDT74LVCH32245A
3.3V CMOS 32-BIT BUS TRANSCEIVER WITH 3-STATE OUTPUTS
INDUSTRIAL TEMPERATURE RANGE
PIN CONFIGURATION
6
1
A
2
1
A
4
1
A
6
1
A
8
2
A
2
2
A
4
2
A
6
2
A
7
3
A
2
3
A
4
3
A
6
3
A
8
4
A
2
4
A
4
4
A
6
4
A
7
5
1
A
1
1
A
3
1
A
5
1
A
7
2
A
1
2
A
3
2
A
5
2
A
8
3
A
1
3
A
3
3
A
5
3
A
7
4
A
1
4
A
3
4
A
5
4
A
8
4 1
OE
GND
GND
1
B
3
V
CC
V
CC
GND
GND
V
CC
V
CC
GND
GND
2
OE
3
OE
GND
GND
3
B
3
V
CC
V
CC
3
B
5
GND
GND
3
B
7
GND
GND
4
B
1
V
CC
V
CC
4
B
3
GND
GND
4
B
5
4
OE
3 1
DIR
GND
1
B
7
GND
2
B
1
2
DIR
3
DIR
4
DIR
2
1
B
1
1
B
5
2
B
3
2
B
5
2
B
8
3
B
1
4
B
8
1
1
B
2
A
1
B
4
B
1
B
6
C
1
B
8
D
2
B
2
E
2
B
4
F
2
B
6
G
2
B
7
H
3
B
2
J
3
B
4
K
3
B
6
L
3
B
8
M
4
B
2
N
4
B
4
P
4
B
6
R
4
B
7
T
LFBGA
TOPVIEW
96 BALL LFBGA PACKAGE ATTRIBUTES
1.5 mm Max.
1.4 mm Nom.
1.3 mm Min.
0.8mm
6
5
4
3
2
1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
T
TOP VIEW
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
T
1
2
3
5.5mm
4
5
6
13.5mm
2
IDT74LVCH32245A
3.3V CMOS 32-BIT BUS TRANSCEIVER WITH 3-STATE OUTPUTS
INDUSTRIAL TEMPERATURE RANGE
ABSOLUTE MAXIMUM RATINGS
(1)
Symbol
V
TERM
T
STG
I
OUT
I
IK
I
OK
I
CC
I
SS
Description
Max
Terminal Voltage with Respect to GND
Storage Temperature
DC Output Current
Continuous Clamp Current,
V
I
< 0 or V
O
< 0
Continuous Current through each
V
CC
or GND
–0.5 to +6.5
–65 to +150
–50 to +50
–50
±100
Unit
V
°C
mA
mA
mA
CAPACITANCE
(T
A
= +25°C, F = 1.0MHz)
Symbol
C
IN
C
OUT
C
I/O
Parameter
(1)
Input Capacitance
Output Capacitance
I/O Port Capacitance
Conditions
V
IN
= 0V
V
OUT
= 0V
V
IN
= 0V
Typ.
4.5
6.5
6.5
Max.
6
8
8
Unit
pF
pF
pF
NOTE:
1. As applicable to the device type.
NOTE:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause
permanent damage to the device. This is a stress rating only and functional operation
of the device at these or any other conditions above those indicated in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect reliability.
PIN DESCRIPTION
Pin Names
xOE
xDIR
xAx
xBx
Description
Output Enable Input (Active LOW)
Direction Control Input
Side A Inputs or 3-State Outputs
Side B Inputs or 3-State Outputs
(1)
(1)
FUNCTION TABLE
(1)
Inputs
xOE
L
L
H
NOTE:
1. H = HIGH Voltage Level
L = LOW Voltage Level
X = Don’t Care
Z = High Impedance
xDIR
L
H
X
Outputs
Bus B data to Bus A
Bus A data to Bus B
Z
NOTE:
1. These pins have "Bus-Hold". All other pins are standard inputs, outputs, or I/Os.
BUS-HOLD CHARACTERISTICS
Symbol
I
BHH
I
BHL
I
BHH
I
BHL
I
BHHO
I
BHLO
NOTES:
1. Pins with Bus-Hold are identified in the pin description.
2. Typical values are at V
CC
= 3.3V, +25°C ambient.
Parameter
(1)
Bus-Hold Input Sustain Current
Bus-Hold Input Sustain Current
Bus-Hold Input Overdrive Current
V
CC
= 3V
V
CC
= 2.3V
V
CC
= 3.6V
Test Conditions
V
I
= 2V
V
I
= 0.8V
V
I
= 1.7V
V
I
= 0.7V
V
I
= 0 to 3.6V
Min.
– 75
75
—
—
—
Typ.
(2)
—
—
—
—
—
Max.
—
—
—
—
±500
Unit
μA
μA
μA
3
IDT74LVCH32245A
3.3V CMOS 32-BIT BUS TRANSCEIVER WITH 3-STATE OUTPUTS
INDUSTRIAL TEMPERATURE RANGE
DC ELECTRICAL CHARACTERISTICS OVER OPERATING RANGE
Following Conditions Apply Unless Otherwise Specified:
Operating Condition: T
A
= –40°C to +85°C
Symbol
V
IH
V
IL
I
IH
I
IL
I
OZH
I
OZL
I
OFF
V
IK
V
H
I
CCL
I
CCH
I
CCZ
ΔI
CC
High Impedance Output Current
(3-State Output pins)
Input/Output Power Off Leakage
Clamp Diode Voltage
Input Hysteresis
Quiescent Power Supply Current
V
CC
= 0V, V
IN
or V
O
≤
5.5V
V
CC
= 2.3V, I
IN
= –18mA
V
CC
= 3.3V
V
CC
= 3.6V
V
IN
= GND or V
CC
—
—
—
—
—
—
—
–0.7
100
—
—
—
±50
–1.2
—
10
10
500
μA
V
mV
μA
V
CC
= 3.6V
V
O
= 0 to 5.5V
—
—
±10
μA
Parameter
Input HIGH Voltage Level
Input LOW Voltage Level
Input Leakage Current
V
CC
= 2.3V to 2.7V
V
CC
= 2.7V to 3.6V
V
CC
= 2.3V to 2.7V
V
CC
= 2.7V to 3.6V
V
CC
= 3.6V
V
I
= 0 to 5.5V
Test Conditions
Min.
1.7
2
—
—
—
Typ.
(1)
—
—
—
—
—
Max.
—
—
0.7
0.8
±5
μA
V
Unit
V
Quiescent Power Supply Current
Variation
3.6
≤
V
IN
≤
5.5V
(2)
One input at V
CC
- 0.6V, other inputs at V
CC
or GND
μA
NOTES:
1. Typical values are at V
CC
= 3.3V, +25°C ambient.
2. This applies in the disabled state only.
OUTPUT DRIVE CHARACTERISTICS
Symbol
V
OH
Parameter
Output HIGH Voltage
V
CC
= 2.3V
V
CC
= 2.3V
V
CC
= 2.7V
V
CC
= 3V
V
CC
= 3V
V
OL
Output LOW Voltage
V
CC
= 2.3V to 3.6V
V
CC
= 2.3V
V
CC
= 2.7V
V
CC
= 3V
I
OH
= – 24mA
I
OL
= 0.1mA
I
OL
= 6mA
I
OL
= 12mA
I
OL
= 12mA
I
OL
= 24mA
Test Conditions
(1)
V
CC
= 2.3V to 3.6V
I
OH
= – 0.1mA
I
OH
= – 6mA
I
OH
= – 12mA
Min.
V
CC
– 0.2
2
1.7
2.2
2.4
2.2
—
—
—
—
—
Max.
—
—
—
—
—
—
0.2
0.4
0.7
0.4
0.55
V
Unit
V
NOTE:
1. V
IH
and V
IL
must be within the min. or max. range shown in the DC ELECTRICAL CHARACTERISTICS OVER OPERATING RANGE table for the appropriate V
CC
range.
T
A
= – 40°C to + 85°C.
4
IDT74LVCH32245A
3.3V CMOS 32-BIT BUS TRANSCEIVER WITH 3-STATE OUTPUTS
INDUSTRIAL TEMPERATURE RANGE
OPERATING CHARACTERISTICS, V
CC
= 3.3V ± 0.3V, T
A
= 25°C
Symbol
C
PD
C
PD
Parameter
Power Dissipation Capacitance per Transceiver Outputs enabled
Power Dissipation Capacitance per Transceiver Outputs disabled
Test Conditions
C
L
= 0pF, f = 10Mhz
Typical
76
8
Unit
pF
SWITCHING CHARACTERISTICS
(1)
V
CC
= 2.7V
Symbol
t
PLH
t
PHL
t
PZH
t
PZL
t
PHZ
t
PLZ
t
PZH
t
PZL
t
PHZ
t
PLZ
t
SK
(o)
Parameter
Propagation Delay
xAx to xBx, xBx to xAx
Output Enable Time
xOE to xAx or xBx
Output Disable Time
xOE to xAx or xBx
Output Enable Time
xDIR to xAx or xBx
Output Disable Time
xDIR to xAx or xBx
Output Skew
(2)
—
—
—
500
ps
1.5
7.4
1.5
6.6
ns
1.5
7
1.5
5.5
ns
1.5
7.1
1.5
6.6
ns
1.5
6.7
1.5
5.5
ns
Min.
1.5
Max.
4.7
V
CC
= 3.3V ± 0.3V
Min.
1
Max.
4
Unit
ns
NOTES:
1. See TEST CIRCUITS AND WAVEFORMS. T
A
= – 40°C to + 85°C.
2. Skew between any two outputs of the same package and switching in the same direction.
5
