Single Junction Drop-In Isolator
2.3 GHz—2.5 GHz
Features
•
•
•
•
•
•
Designed for WiMax market
25dB Isolation typical
0.20dB Insertion Loss typical
Low cost package
RoHS compliant
Flat pack packaging
MAFR-000247-000001
V1
Description
This isolator is designed specifically for WiMax appli-
cations and features high reliability performance at a
low cost. It is in a low cost package ideally suited for
high volume manufacturing. M/A Com is one of the
largest suppliers of isolator and circulators in the
world.
Electrical Specifications
T = T
op1
, Z
0
= 50 Ohms
Parameter
Frequency Range
Insertion Loss
Isolation
Return Loss
(Port 1 & 2)
Intermodulation
Circulation
1. See “Absolute Maximum Ratings” for T
op
.
2.3 GHz—2.5 GHz
2.3 GHz—2.5 GHz
2.3 GHz—2.5 GHz
2.3 GHz—2.5 GHz
Test Conditions
Units
GHz
dB
dB
dB
dBc
20.0
20.0
60.0
Min
2.3
0.20
25.0
25.0
65.0
Clockwise
Typ
@25ºC
Max
2.5
0.25
Absolute Maximum Ratings
Parameter
Forward Power, CW
Peak Forward Power
Absolute Maximum
200 Watts
1000 Watts
Reverse Power, CW
60 Watts max for 2 minutes max
1. Operation of this device above any one of these parameters may cause permanent damage.
Operating Temperature
Storage Temperature
1
M/A-COM Inc. and its affiliates reserve the right to make changes to the
product(s) or information contained herein without notice. M/A-COM makes
no warranty, representation or guarantee regarding the suitability of its
products for any particular purpose, nor does M/A-COM assume any liability
whatsoever arising out of the use or application of any product(s) or
information.
-40°C to +85°C
-40°C to +100°C
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
Visit www.macom.com for additional data sheets and product information.
