DP19-020-05: DescriptionDC-DC Regulated Power Supply Module, 1 Output, Hybrid, 1.250 X 0.800 INCH, 0.400 INCH HEIGHT, DIP-24/12; CategoryPower/power management The power supply circuit; File Size160KB，2 Pages; ManufacturerSemiconductor Circuits Inc

Download Datasheet Parametric Compare View All

DP19-020-05 Overview

DC-DC Regulated Power Supply Module, 1 Output, Hybrid, 1.250 X 0.800 INCH, 0.400 INCH HEIGHT, DIP-24/12

DP19-020-05 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Semiconductor Circuits Inc
Parts packaging code	DIP
package instruction	,
Contacts	24/12
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	5.25 V
Minimum input voltage	4.75 V
Nominal input voltage	5 V
JESD-30 code	R-XDMA-P12
Maximum grid adjustment rate	0.2%
Maximum load regulation	0.5%
Number of functions	1
Output times	1
Number of terminals	12
Maximum operating temperature	71 °C
Minimum operating temperature	-25 °C
Maximum output voltage	9.45 V
Minimum output voltage	8.55 V
Nominal output voltage	9 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Protect	CURRENT
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL EXTENDED
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Fine-tuning/adjustable output	NO

Preview

Download Datasheet

View All

765432121098765432109876543210987654321

ENVIRONMENTAL

GENERAL

OUTPUT

INPUT

Voltage Tolerance

Ripple and Noise (PARD)

Short Circuit Protection

Temperature Coefficient

Regulation:

Line

Load

Efficiency

I/O Isolation

Switching Frequency

Operating Temperature

Storage Temperature

Cooling

All specifications are typical at nominal line and full load at 25°C unless

otherwise noted and are subject to change without notice.

Voltage Range

Reflected Ripple

Filtering

DP Series

-25°C to +71°C No Derating

-25°C to +85°C

Free-air Convection

0.2%

0.5%

60% (typ)

500 Vdc

100kHz

4.75-5.25 Vdc

20mA pk-pk (typ. full load)

All Models

± 5%

20mV pk-pk (max)

Current Limit

0.02% / °C

MOSFET design

Continuous short circuit

protection

500 Vdc I/O isolation

Regulated outputs

24 pin DIP compatible

packaging

The DP Series is ideally suited for high

density PC board applications where

real estate is at a premium. Applica-

tions include telecommunications,

automatic test equipment, process

control, etc.

Applications

he DP family is an economically

priced high performance series

of regulated DC/DC converters

offering single and dual outputs.

Features include MOSFET design

operating at a switching frequency of

100Khz, continuous short circuit

protection, LC input filter, 500 Vdc

I/O isolation, and an operating

temperature range of -25°C to +71°C

with no derating. These miniature

converters maintain excellent regula-

tion over varying line and load condi-

tions (0.2% for line and 0.5% for load).

They are packaged in an IC compatible

24 pin DIP configuration measuring

1.25” x 0.8” x 0.4” high.

Single/Dual Outputs

1.5 to 2.4 Watts
