Cross Reference Guide
TN6153 / SN6153*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
300.0 - 1800.0 MHz
11.5 dB Typical
10.5 dB Min
3.0 dB Typical
4.0 dB Max
11.5 dBm Typical
10.5 dBm Min
18.0 dBm Typical
22.0 dBm Typical
2.5/3.0 Input Typ/Max
2.0/3.0 Output Typ/Max
-17.0 dB Typical
-15.0 dB Min
15.0 Volts
18.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
300.0
400.0
600.0
800.0
1000.0
1200.0
1400.0
1600.0
1800.0
0.270
0.290
0.330
0.380
0.390
0.380
0.320
0.200
0.280
-41.00
-53.00
-76.00
-96.00
-117.00
-137.00
-163.00
140.00
22.00
3.830
3.790
3.740
3.670
3.720
3.830
4.020
4.140
4.130
148.00
138.00
117.00
97.00
78.00
56.00
31.00
1.00
-31.00
0.110
0.110
0.110
0.110
0.110
0.120
0.120
0.130
0.140
-14.00
-19.00
-30.00
-40.00
-49.00
-60.00
-75.00
-94.00
-118.00
0.050
0.060
0.070
0.060
0.070
0.060
0.050
0.050
0.220
25.00
12.00
-15.00
-36.00
-41.00
-58.00
-55.00
-22.00
-21.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
13.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
Amplifonix | 2707 Black Lake Place | Philadelphia, PA 19154
Tel: 215.464.4000 | FAX: 215.464.4001 | Email:
info@amplifonix.com
Cross Reference Guide
TN6160 / SN6160*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
100.0 - 600.0 MHz
28.0 dB Typical
26.0 dB Min
2.0 dB Typical
3.0 dB Max
17.0 dBm Typical
16.0 dBm Min
32.0 dBm Typical
46.0 dBm Typical
1.8/2.0 Input Typ/Max
1.8/2.0 Output Typ/Max
-43.0 dB Typical
-40.0 dB Min
15.0 Volts
65.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
