DN8665S

Description
LED Driver, 8-Segment, BICMOS, PDSO20, SOP-20
CategoryAnalog mixed-signal IC    Drivers and interfaces
File Size317KB,6 Pages
ManufacturerPanasonic
Websitehttp://www.panasonic.co.jp/semicon/e-index.html
Download Datasheet Parametric View All

DN8665S Overview

LED Driver, 8-Segment, BICMOS, PDSO20, SOP-20

DN8665S Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerPanasonic
Parts packaging codeSOIC
package instructionSOP, SOP20,.3
Contacts20
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresCOMMON-ANODE
display modeSEGMENT
Interface integrated circuit typeLED DISPLAY DRIVER
JESD-30 codeR-PDSO-G20
JESD-609 codee0
length12.63 mm
Number of functions1
Number of segments8
Number of terminals20
Maximum operating temperature85 °C
Minimum operating temperature-20 °C
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Encapsulate equivalent codeSOP20,.3
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
power supply5 V
Certification statusNot Qualified
Maximum seat height2.45 mm
Maximum supply voltage5.5 V
Minimum supply voltage4.5 V
Nominal supply voltage5 V
surface mountYES
technologyBICMOS
Temperature levelOTHER
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width5.5 mm
