PICOD137ALULS

Description
THUMB/PUSHWHEEL SWITCH-1SWITCHES, BCD COMPLEMENT, 0.02A, 20VDC, THROUGH HOLE-RIGHT ANGLE
CategoryMechanical and electronic products    switch
File Size126KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

PICOD137ALULS Overview

THUMB/PUSHWHEEL SWITCH-1SWITCHES, BCD COMPLEMENT, 0.02A, 20VDC, THROUGH HOLE-RIGHT ANGLE

PICOD137ALULS Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
body width7.62 mm
body height14 mm
Body length or diameter34.49 mm
Contact (AC) maximum rated R load.02A@20VAC
Maximum contact current (AC)0.02 A
Maximum contact current (DC)0.02 A
Contact (DC) maximum rated R load.02A@20VDC
Maximum contact voltage (AC)20 V
Maximum contact voltage (DC)20 V
Electrical life1000000 Cycle(s)
Installation featuresTHROUGH HOLE-RIGHT ANGLE
Number of positions10
Number of switching segments1
Maximum operating temperature60 °C
Minimum operating temperature-20 °C
sealEPOXY TERMINAL SEALED
surface mountNO
switch functionBCD COMPLEMENT
Switch typeTHUMB/PUSHWHEEL SWITCH
Termination typeSOLDER

Preview

Download Datasheet
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Switches & Knobs > Product Feature Selector > Product Details
PICOD137ALULS Product Details
Pushwheel Switches
Not EU RoHS or ELV Compliant
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Switch
PICO­D Series
Code Type = BCD Complement
Termination Type = PCB Long Downward
Mount = Front
PICOD137ALULS
(1571506­1)
TE Internal Number: 1571506­1
View all Features
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
CODE SWITCH (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Switch
Code Type = BCD Complement
Mechanical Attachment:
Mount = Front
Electrical Characteristics:
Contact Rating = 0.4 VA @ 20 VDC Max.
Termination Features:
Termination Type = PCB Long Downward
Body Features:
Mount Style = Snap Detent
Contact Features:
Contact Base Material = Copper Alloy
Configuration Features:
Wheel Markings = 0­9, A­F
Repeating Readout = Without
Configuration (Pole­Throw) = Single Pole ­ Single Throw
Industry Standards:
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
Other:
Series = PICO­D
Brand = Alcoswitch
