LC125S
SMD Shielded
Power Inductors
11.6
+/- 0.5
5.4
+/- 0.5
10.0
Typ.
9.0
Typ.
2.1
Typ.
12.6
+/- 0.5
CHARACTERISTICS
INDUCTANCE RANGE 1 µH to 68 µH.
TOLERANCE 10% over entire range.
CURRENT RATING Current to cause maximum 10% of
inductance drop, or 40°C temperature rise.
OPERATING TEMPERA
TURE -30°C to +100°C.
FEATURES
High current rating
Low core loss for high frequency power application
APPLICATIONS
DC/DC Converters
Computers
Telecomm
unications equipment
Filters
LCD display
TEST
FREQUENCY
(MHz)
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
TEST
FREQUENCY
(kHz)
SELF RESONANT
FREQUENCY
TYPIC AL (MHz)
24.2
21.2
18.9
16.1
15.2
13.9
12.8
11.6
10.4
9.12
8.50
7.85
DC RESISTANCE
MAXIMUM
(OHMS)
0.05
0.05
0.06
0.06
0.07
0.08
0.10
0.11
0.12
0.15
0.17
0.20
RATED DC
CURRENT
MAXIMUM (AMPS)
2.65
2.50
2.45
2.40
2.20
2.00
1.80
1.65
1.50
1.38
0.26
0.14
PAR T
NUMBER
LC125S-100M
LC125S-120M
LC125S-150M
LC125S-180M
LC125S-220M
LC125S -270M
LC125S -330M
LC125S -390M
LC125S -470M
LC125S -560M
LC125S -680M
LC125S -820M
L ±20%
µH
10
12
15
18
22
27
33
39
47
56
68
82
LC125S -101M
LC125S -121M
LC125S -151M
LC125S -181M
LC125S -221M
LC125S -271M
LC105S -331M
LC125S -391M
LC125S -471M
LC125S -561M
LC125S -681M
LC125S -821M
100
120
150
180
220
270
330
390
470
560
680
820
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
6.92
6.34
5.55
5.10
4.51
4.37
3.90
3.55
3.25
2.94
2.64
2.42
0.25
0.28
0.40
0.48
0.52
0.70
0.80
1.08
1.20
1.34
1.78
2.00
1.05
0.95
0.85
0.77
0.70
0.63
0.57
0.52
0.48
0.44
0.40
0.36
