NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Input Specifications
Voltage range
Filter
Start up time
Input Specifications
Nominal
12
24
48
12
24
48
Typical
9-18
18-36
36-75
20
Maximum
Units
VDC
Absolute Maximum Rated Input
Voltage
Peak Input Voltage time
On/Off Control
ms
25
50
VDC
100
100
ms
ON – high or open (2.5V TO 5.5V); OFF – low (-0.7V to 0.8V or short circuit between pin 2 & 3)
π(Pi) Network
Isolation Specifications
Tested I/O voltage
Resistance
Capacitance
Parameters
Conditions
3 sec
Typical
1000
1200
Rated
1500
VDC
MOhm
pF
Units
www.aimtec.com
F 051e R8.F
Tel: +1 514 620 2722
1 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
30 Watt | DC-DC Converter
Output Specifications
Output Specifications
Conditions
Balanced Load
Series AM30K-Z
Units
%
%
%
%
Voltage accuracy
Voltage balance (Dual Output model)
Over voltage protection
Over current protection
Short Circuit protection
Short circuit restart
Line voltage regulation (Single)
Line voltage regulation (Dual)
Load voltage regulation (Single)
Load voltage regulation (Dual)
Temperature coefficient
Ripple & Noise
Voltage adjustment range
Typical
±5
±5
125
120
Maximum
HL-LL
HL-LL
10% to 100% Load
10% to 100% Load
At 20MHz Bandwidth
Continuous
Auto Recovery
±5
±5
±0.5
±0.5
±0.02
75
±10
%
%
%
%
%/
o
C
m Vp-p
%
General Specifications
Switching frequency
Operating temperature
Storage temperature
Max Case temperature
Cooling
Humidity
Over Temperature Protection
Case material
Weight
Dimensions (L X W X H)
MTBF
Input Specifications
100% load
With drating above 60
o
C (see graph below)
Conditions
Typical
270
Maximum
Units
KHz
o
C
o
C
%
g
-40 to +85
-40 to +125
100
Free air convection
95
110
Nickel-coated
Copper and Epoxy (UL94V-0 rated)
48
2.00 x1.60 x0.40 inches
50.80 x 40.60 x 10.20 mm
>1000000 hrs Calculated using MIL-HDBK-217 F at +25
o
C
Safety Specifications
Standards
Agency approvals
CE
IEC/EN 60950-1
EN55022 Class A
EN55022 Class A
EN61000-4-2 Perf. Criteria B
EN61000-4-3 Perf. Criteria A
EN61000-4-4 Perf. Criteria B
EN61000-4-5 Perf. Criteria B
EN61000-4-6 Perf. Criteria A
EN61000-4-8 Perf. Criteria A
Safety
www.aimtec.com
F 051e R8.F
Tel: +1 514 620 2722
2 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
30 Watt | DC-DC Converter
Pin Out Specifications
Pin
1
2
3
4
5
6
7
+Vin
-Vin
On/Off Control
No Pin
+Vout
-Vout
Trim
Series AM30K-Z
Single
+Vin
-Vin
On/Off Control
+Vout
Com
-Vout
Trim
Dual
Dimensions
17.78
(0.70)
7.62 10.16 5.08
(0.30) (0.40) (0.20)
40.60
(1.60)
1
2
3
5
Bottom View
6
7
Printed
Face
10.16
(0.40)
Built-in Stand-offs to
ease PCB Cleaning
Dimensions mm (inch)
Case Tolerance ±0.50 (±0.02)
Pin Pitch Tolerance ±0.35 (±0.014)
Ø 1.00
(0.04)
Trimming
www.aimtec.com
F 051e R8.F
5.08
(0.20)
2.54
(0.10)
Tel: +1 514 620 2722
3 of 4
5.10
(0.20)
45.72
(1.80)
10.16 10.16 10.16
(0.40) (0.40) (0.40)
4
5.10
(0.20)
50.80
(2.00)
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
30 Watt | DC-DC Converter
Derating
Free Air Convection
60º C
100
Series AM30K-Z
Output Power (%)
80
60
40
20
0
- 40
- 20
0
20
40
60
80
85
Safe Operating Area
100
Ambient Temperature
º C
Control ON/OFF pin connection example:
The filter capacitor Aimtec suggests: 1000uF, 100V.
Note A:
An external filter capacitor is required if the module has to meet EN61000-4-4 and EN61000-4-5.
Models
AM30K-12XXXZ
AM30K-24XXXZ
AM30K-48XXXZ
C1
330 μf, 100V
330 μf, 100V
330 μf,
100V
L
12μH
12μH
12μH
C2
100μ, 100V
100μ, 100V
100μ, 100V
C3
N/A
N/A
1000Pf, 2000V
mounted as close as possible to the module; and all leads should be minimized to decrease radiated noise.
Note B:
Input filter components (C1, C2, L) are used to help meet conducted emissions requirement for the module. These components should be
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
