Series AM3T-Z
3 Watt | DC-DC Converter
FEATURES:
•
•
•
•
RoHS compliant
Wide 2:1 input range
High efficiency up to 82%
Continuous short circuit protection
•
•
•
•
Operating temperature -40
o
C to + 85
o
C
Input / Output Isolation 1500 and 3500 VDC
Pin compatible with multiple manufacturers
Low profile metal package
Models
Single output
Model
AM3T-1203SZ
AM3T-1205SZ
AM3T-1207SZ
AM3T-1209SZ
AM3T-1212SZ
AM3T-1215SZ
AM3T-1218SZ
AM3T-1224SZ
AM3T-2403SZ
AM3T-2405SZ
AM3T-2407SZ
AM3T-2409SZ
AM3T-2412SZ
AM3T-2415SZ
AM3T-2418SZ
AM3T-2424SZ
AM3T-4803SZ
AM3T-4805SZ
AM3T-4807SZ
AM3T-4809SZ
AM3T-4812SZ
AM3T-4815SZ
AM3T-4818SZ
AM3T-4824SZ
AM3T-1203SH35Z
AM3T-1205SH35Z
AM3T-1207SH35Z
AM3T-1209SH35Z
AM3T-1212SH35Z
AM3T-1215SH35Z
AM3T-1218SH35Z
AM3T-1224SH35Z
AM3T-2403SH35Z
AM3T-2405SH35Z
AM3T-2407SH35Z
AM3T-2409SH35Z
AM3T-2412SH35Z
AM3T-2415SH35Z
AM3T-2418SH35Z
AM3T-2424SH35Z
AM3T-4803SH35Z
AM3T-4805SH35Z
AM3T-4807SH35Z
AM3T-4809SH35Z
AM3T-4812SH35Z
AM3T-4815SH35Z
www.aimtec.com
F 051e R12.B
Input Voltage
(V)
9-18
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
36-72
36-72
9-18
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
Output Voltage
(V)
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
Output Current
max (mA)
800
600
417
333
250
200
167
125
800
600
417
333
250
200
167
125
800
600
417
333
250
200
167
125
800
600
417
333
250
200
167
125
800
600
417
333
250
200
167
125
800
600
417
333
250
200
Isolation
(VDC)
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
Capacitive load,
max (μF)
470
470
68
68
47
47
22
22
470
470
68
68
47
47
22
22
470
470
68
68
47
47
22
22
470
470
68
68
47
47
22
22
470
470
68
68
47
47
22
22
470
470
68
68
47
47
Efficiency
(%)
73
76
78
77
79
79
80
79
73
77
79
78
78
78
79
78
75
80
80
80
82
82
80
80
73
76
78
77
79
79
80
79
75
80
80
80
82
82
80
80
80
77
81
78
80
80
Tel: +1 514 620 2722
1 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM3T-Z
3 Watt | DC-DC Converter
Models
Single output (continue)
Model
AM3T-4818SH35Z
AM3T-4824SH35Z
Input Voltage
(V)
36-72
36-72
Output Voltage
(V)
18
24
Output Current
max (mA)
167
125
Isolation
(VDC)
3500
3500
Capacitive load,
max (μF)
22
22
Efficiency
(%)
80
80
Models
Dual output
Model
AM3T-1203DZ
AM3T-1205DZ
AM3T-1207DZ
AM3T-1209DZ
AM3T-1212DZ
AM3T-1215DZ
AM3T-1218DZ
AM3T-1224DZ
AM3T-2403DZ
AM3T-2405DZ
AM3T-2407DZ
AM3T-2409DZ
AM3T-2412DZ
AM3T-2415DZ
AM3T-2418DZ
AM3T-2424DZ
AM3T-4803DZ
AM3T-4805DZ
AM3T-4807DZ
AM3T-4809DZ
AM3T-4812DZ
AM3T-4815DZ
AM3T-4818DZ
AM3T-4824DZ
AM3T-1203DH35Z
AM3T-1205DH35Z
AM3T-1207DH35Z
AM3T-1209DH35Z
AM3T-1212DH35Z
AM3T-1215DH35Z
AM3T-1218DH35Z
AM3T-1224DH35Z
AM3T-2403DH35Z
AM3T-2405DH35Z
AM3T-2407DH35Z
AM3T-2409DH35Z
AM3T-2412DH35Z
AM3T-2415DH35Z
AM3T-2418DH35Z
AM3T-2424DH35Z
AM3T-4803DH35Z
AM3T-4805DH35Z
AM3T-4807DH35Z
AM3T-4809DH35Z
AM3T-4812DH35Z
www.aimtec.com
F 051e R12.B
Input Voltage
(V)
9-18
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
36-72
36-72
9-18
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
Output Voltage
(V)
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
Output Current
max (mA)
±400
±300
±208
±167
±125
±100
±84
±63
±400
±300
±208
±167
±125
±100
±84
±63
±400
±300
±208
±167
±125
±100
±84
±63
±400
±300
±208
±167
±125
±100
±84
±63
±400
±300
±208
±167
±125
±100
±84
±63
±400
±300
±208
±167
±125
Isolation
(VDC)
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
3500
Capacitive load,
max (μF)
±220
±220
±33
±33
±22
±22
±10
±10
±220
±220
±33
±33
±22
±22
±10
±10
±220
±220
±33
±33
±22
±22
±10
±10
±220
±220
±33
±33
±22
±22
±10
±10
±220
±220
±33
±33
±22
±22
±10
±10
±220
±220
±33
±33
±22
Efficiency
(%)
75
78
78
79
80
80
78
80
75
77
81
78
80
80
80
80
76
78
78
79
80
80
78
80
75
78
80
79
80
80
80
80
75
78
80
79
80
80
80
80
76
78
78
79
80
Tel: +1 514 620 2722
2 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM3T-Z
3 Watt | DC-DC Converter
Models
Dual output (continue)
Model
AM3T-4815DH35Z
AM3T-4818DH35Z
AM3T-4824DH35Z
Input Voltage
(V)
36-72
36-72
36-72
Output Voltage
(V)
±15
±18
±24
Output Current
max (mA)
±100
±84
±63
Isolation
(VDC)
3500
3500
3500
Capacitive load,
max (μF)
±22
±10
±10
Efficiency
(%)
80
78
80
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at rated output load
unless otherwise specified
Input Specifications
Parameters
Voltage range
Filter
Turn on Transient process time
Start up time
Absolute Maximum Rating
Peak Input Voltage time
12 Vin
24 Vin
48 Vin
Nominal
12
24
48
Typical
9-18
18-36
36-72
π
(Pi) Network
500
-0.7-24
-0.7-40
-0.7-80
100
Maximum
Units
VDC
350
ms
ms
VDC
ms
Isolation Specifications
Parameters
Tested I/O voltage
Resistance
Capacitance
Conditions
3 sec
Typical
> 1000
470
Rated
1500 and 3500
Units
VDC
MOhm
pF
Output Specifications
Parameters
Voltage accuracy
Voltage balance Dual output
Short Circuit protection
Short circuit restart
Line voltage regulation (Single)
Line voltage regulation (Dual)
Load voltage regulation (Single)
Load voltage regulation (Single)
3.3V output model
Load voltage regulation (Dual)
Load voltage regulation (Dual)
±3.3V output model
Temperature coefficient
Ripple & Noise
Rising time
Conditions
Typical
±1
±1
Continuous
Auto-recovery
Maximum
Units
%
%
LL-HL
LL-HL
Load: 10…100%
Load: 10…100%
Load: 10…100%
Load: 10…100%
±0.5
±0.5
±0.5
±1.5
±0.5
±1.5
±0.02
60
10
%
%
%
%
%
%
%/
o
C
mV p-p
ms
At 20MHz Bandwidth
General Specifications
Parameters
Switching frequency
Operating temperature
Storage temperature
Max Case temperature
Cooling
Humidity
Case material
Weight
Dimensions(L x W x H)
MTBF
www.aimtec.com
F 051e R12.B
Conditions
100% load
Full Load without Derating
Typical
266
Maximum
-40 to +85
-40 to +125
100
Units
KHz
o
C
o
C
o
C
%
Free air convection
90
Nickel-coated copper
17
g
Tolerance ±0.5 mm or ±0.02 inches
1.28 x 0.84 x 0.41 inches 32.25 x 21.35 x 10.50mm
>1 039 000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Tel: +1 514 620 2722
3 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
Series AM3T-Z
3 Watt | DC-DC Converter
Pin Out Specifications
Pin
Single
1
2
3
9
10
11
12/13
14
15
16
22
23
24
+V Input
N.C.
N.C.
No pin
-V Output
+V Output
-V Input
+V Output
-V Output
No pin
N.C.
N.C.
+V Input
1500VDC
Dual
+V Input
-V Output
Common
No pin
Common
+V Output
-V Input
+V Output
Common
No pin
Common
-V Output
+V Input
3500VDC
Single
No pin
-V Input
-V Input
No pin
No pin
N.C.
No pin
+V Output
No pin
-V Output
+V Input
+V Input
No pin
Dual
No pin
-V Input
-V Input
Common
No pin
-V Output
No pin
+V Output
No pin
Common
+V Input
+V Input
No pin
Dimensions
NOTE: 1.
Datasheets are updated as needed and as such, specifications are subject to change without notice. Once printed or downloaded, datasheets are no longer controlled
by Aimtec; refer to www.aimtec.com for the most current product specifications.
2.
Product labels shown, including safety agency certifications on labels, may vary based on the
date manufactured.
3.
Mechanical drawings and specifications are for reference only.
4.
All specifications are measured at an ambient temperature of 25°C, humidity<75%,
nominal input voltage and at rated output load unless otherwise specified.
5.
Aimtec may not have conducted destructive testing or chemical analysis on all internal components
and chemicals at the time of publishing this document. CAS numbers and other limited information are considered proprietary and may not be available for release.
6.
This
product is not designed for use in critical life support systems, equipment used in hazardous environments, nuclear control systems or other such applications which necessitate
specific safety and regulatory standards other the ones listed in this datasheet.
7.
Warranty is in accordance with Aimtec’s standard Terms of Sale available at www.aimtec.com.
www.aimtec.com
F 051e R12.B
Tel: +1 514 620 2722
4 of 4
Toll free: + 1 888 9 AIMTEC
(924 6832)
North America only
京公网安备 11010802033920号
EEWORLD
