TAK CHEONG
500 mW DO-34 Hermetically
Sealed Glass Zener Voltage
Regulators
SEMICONDUCTOR
Absolute Maximum Ratings
Parameter
Power Dissipation
Storage Temperature Range
Operating Junction Temperature
T
A
= 25°C unless otherwise noted
Value
500
-65 to +200
+175
230
Units
mW
°C
°C
°C
AXIAL LEAD
DO34
Lead Temperature (1/16” from case for 10 seconds)
These ratings are limiting values above which the serviceability of the diode may be impaired.
DEVICE MARKING DIAGRAM
Specification Features:
Zener Voltage Range 2.0 to 39 Volts
DO-34 Package (JEDEC DO-204)
Through-Hole Device Type Mounting
Hermetically Sealed Glass
Compression Bonded Construction
All external surfaces are corrosion resistant and leads are readily solderable
Cathode indicated by polarity band
Cathode
L
xxx
T (tolerance)
Band color
=Tak Cheong Logo
=Device Code TCMTZJxxx
=A, B, C or D
=Black
L xxx T
Anode
ELECTRICAL SYMBOL
Electrical Characteristics
T
A
= 25°C unless otherwise noted
VZ@IZT
T
Device Type
Tolerance
Min
Nom
Max
TCMTZJ2V0
TCMTZJ2V2
TCMTZJ2V4
TCMTZJ2V7
TCMTZJ3V0
TCMTZJ3V3
TCMTZJ3V6
TCMTZJ3V9
TCMTZJ4V3
A
B
A
B
A
B
A
B
A
B
A
B
A
B
A
B
A
B
C
5.5%
4.3%
4.0%
4.1%
3.9%
4.0%
4.0%
3.9%
3.7%
3.4%
3.4%
3.1%
3.6%
3.3%
3.5%
3.3%
3.0%
3.0%
3.0%
1.880
2.020
2.120
2.220
2.330
2.430
2.540
2.690
2.850
3.010
3.160
3.320
3.455
3.600
3.740
3.890
4.040
4.170
4.300
1.990
2.110
2.210
2.315
2.425
2.530
2.645
2.800
2.960
3.115
3.270
3.425
3.575
3.723
3.875
4.025
4.165
4.300
4.435
2.100
2.200
2.300
2.410
2.520
2.630
2.750
2.910
3.070
3.220
3.380
3.530
3.695
3.845
4.010
4.160
4.290
4.430
4.570
Izt
(mA)
5
5
5
5
5
5
5
5
5
Zzt@Izt
(Ohms)
Max
100
100
100
110
120
120
100
100
100
Zzk@Izk
(Ohms)
Max
1000
1000
1000
1000
1000
1000
1000
1000
1000
Izk
(mA)
0.5
0.5
0.5
0.5
0.5
0.5
1
1
1
I
R
@V
R
(uA)
Max
120
100
120
100
50
20
10
5
5
V
R
(V)
0.5
0.7
1.0
1.0
1.0
1.0
1.0
1.0
1.0
November 2004 / Original
1
TCMTZJxxx Series
®
TAK CHEONG
Electrical Characteristics
T
A
= 25°C unless otherwise noted
Izt
V
Z
@Izt
T
Device Type
(mA)
Tolerance
Min
Nom
Max
TCMTZJ4V7
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
D
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
D
2.6%
2.8%
2.7%
2.6%
2.6%
2.7%
2.4%
2.5%
2.6%
2.7%
2.6%
2.5%
2.6%
2.6%
2.6%
2.7%
2.6%
2.5%
2.6%
2.6%
2.5%
2.6%
2.5%
2.6%
2.6%
2.6%
2.5%
2.5%
2.6%
2.6%
2.5%
2.5%
2.6%
2.6%
2.6%
2.6%
2.6%
2.5%
2.6%
2.5%
2.6%
2.6%
2.5%
2.5%
2.5%
2.6%
2.5%
2.5%
2.5%
2.5%
4.44
4.55
4.68
4.81
4.94
5.09
5.28
5.45
5.61
5.78
5.96
6.12
6.29
6.49
6.66
6.85
7.07
7.29
7.53
7.78
8.03
8.29
8.57
8.83
9.12
9.41
9.70
9.94
10.18
10.50
10.82
11.13
11.44
11.74
12.11
12.55
12.99
13.44
13.89
14.35
14.80
15.25
15.69
16.22
16.82
17.42
18.02
18.63
19.23
19.72
4.56
4.68
4.81
4.94
5.07
5.23
5.41
5.59
5.76
5.94
6.12
6.28
6.46
6.66
6.84
7.04
7.26
7.48
7.73
7.99
8.24
8.51
8.79
9.07
9.36
9.66
9.95
10.19
10.45
10.78
11.10
11.42
11.74
12.05
12.43
12.88
13.33
13.79
14.26
14.72
15.19
15.65
16.10
16.64
17.26
17.88
18.49
19.11
19.73
20.22
4.68
4.80
4.93
5.07
5.20
5.37
5.55
5.73
5.91
6.09
6.27
6.44
6.63
6.83
7.01
7.22
7.45
7.67
7.92
8.19
8.45
8.73
9.01
9.30
9.59
9.90
10.20
10.44
10.71
11.05
11.38
11.71
12.03
12.35
12.75
13.21
13.66
14.13
14.62
15.09
15.57
16.04
16.51
17.06
17.70
18.33
18.96
19.59
20.22
20.72
5
Zzt@Izt
(Ohms)
Max
80
SEMICONDUCTOR
Zzk@Izk
(Ohms)
Max
900
Izk
(mA)
1
I
R
@V
R
(uA)
Max
5
V
R
(V)
1.0
TCMTZJ5V1
5
80
800
1
5
1.5
TCMTZJ5V6
5
60
500
1
5
2.5
TCMTZJ6V2
5
60
300
1
5
3.0
TCMTZJ6V8
5
20
150
0.5
2
3.5
TCMTZJ7V5
5
20
120
0.5
0.5
4.0
TCMTZJ8V2
5
20
120
0.5
0.5
5.0
TCMTZJ9V1
5
25
120
0.5
0.5
6.0
TCMTZJ10V
5
30
120
0.5
0.2
7.0
TCMTZJ11V
5
30
120
0.5
0.2
8.0
TCMTZJ12V
5
30
110
0.5
0.2
9.0
TCMTZJ13V
5
35
110
0.5
0.2
10
TCMTZJ15V
5
40
110
0.5
0.2
11
TCMTZJ16V
5
40
150
0.5
0.2
12
TCMTZJ18V
5
45
150
0.5
0.2
13
TCMTZJ20V
5
55
200
0.5
0.2
15
November 2004 / Original
2
®
TAK CHEONG
Electrical Characteristics
T
A
= 25°C unless otherwise noted
V
Z
@Izt
T
Device Type
Tolerance
Min
Nom
Max
Izt
(mA)
Zzt@Izt
(Ohms)
Max
SEMICONDUCTOR
Zzk@Izk
(Ohms)
Max
Izk
(mA)
I
R
@V
R
(uA)
Max
V
R
(V)
A
2.2% 20.15
20.68 21.20
B
2.5% 20.64
21.18 21.71
TCMTZJ22V
5
30
200
0.5
0.2
17
C
2.5% 21.08
21.63 22.17
D
2.5% 21.52
22.08 22.63
A
2.5% 22.05
22.62 23.18
B
2.5% 22.61
23.19 23.77
TCMTZJ24V
5
35
200
0.5
0.2
19
C
2.5% 23.12
23.72 24.31
D
2.5% 23.63
24.24 24.85
A
2.5% 24.26
24.89 25.52
B
2.5% 24.97
25.62 26.26
TCMTZJ27V
5
45
250
0.5
0.2
21
C
2.5% 25.63
26.29 26.95
D
2.5% 26.29
26.97 27.64
A
2.5% 26.99
27.69 28.39
B
2.5% 27.70
28.42 29.13
TCMTZJ30V
5
55
250
0.5
0.2
23
C
2.5% 28.36
29.09 29.82
D
2.5% 29.02
29.77 30.51
A
2.5% 29.68
30.45 31.22
B
2.5% 30.32
31.10 31.88
TCMTZJ33V
5
65
250
0.5
0.2
25
C
2.5% 30.90
31.70 32.50
D
2.5% 31.49
32.30 33.11
A
2.5% 32.14
32.97 33.79
B
2.5% 32.79
33.64 34.49
TCMTZJ36V
5
75
250
0.5
0.2
27
C
2.5% 33.40
34.27 35.13
D
2.5% 34.01
34.89 35.77
A
2.5% 34.68
35.58 36.47
B
2.5% 35.36
36.28 37.19
TCMTZJ39V
5
85
250
0.5
0.2
30
C
2.5% 36.00
36.93 37.85
D
2.5% 36.63
37.58 38.52
VF (forward voltage) = 1.2 V maximum @ IF = 200mA for all types
Note:
1. The zener voltage subdivision (VZ) is measured 40mS after diode is powered up.
2. The operating resistance (Zzt and Zzk) is measured by superimposing a minute alternation current
in the regulated current (Iz).
3. When ordering, please specify tolerance A, B, C or D.
Electrical Symbol Definition
Symbol
Parameter
(mA)
Typical Characteristics
I
VZ
I
zt
Z
zt
I
zk
Z
zk
I
R
V
R
I
F
V
F
Reverse Zener Voltage @ I
zt
I
F
Reverse Current
Maximum Zener Impedance @
I
zt
Reverse Current
Maximum Zener Impedance @
I
zk
Reverse Current @
V
R
Breakdown Voltage
Forward Current
Forward Voltage @
I
F
(nA)
(µA)
(V)
B
V
V
R
I
R
I
R
V
(mV)
V
November 2004 / Original
3
®
TAK CHEONG
Ordering Information
Device
TCMTZJXXXT
TCMTZJXXXT.TB
TCMTZJXXXT.TR
TCMTZJXXXT
Package
Bulk
Tape and Ammo
Tape and Reel
Quantity
10,000
5,000
10,000
SEMICONDUCTOR
Others (…contact Tak Cheong sales representatives)
Axial-Lead Tape Packaging Standards
This axial-lead component’s packaging requirements use in automatic testing and assembly equipment. And this standard practices for
lead-tape packaging of axial-lead components meets the requirements of EIA Standard RS-296-D “Lead-taping of Components on Axial
Lead Configuration for Automatic Insertion”.
November 2004 / Original
4
®
TAK CHEONG
Tape & Reel Packaging Information
SEMICONDUCTOR
Label
Corrugated outer liner
Write (Anode)
Tape & Reel
Outline
Red or Blue (Cathode)
Kraft paper wound
between layers
DIM
D1
Millimeters
356
30
84
77.5
Reel
Dimensions
D2
D3
D4
Package Type
Quantity Per Reel
Quantity Per
Reel
DO-34
10,000
Tape & Ammo Packaging Information
November 2004 / Original
5
