PS2501L-2-E3-N datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> PS2501L-2-E3-N

PS2501L-2-E3-N: DescriptionTransistor Output Optocoupler, 2-Element, 5000V Isolation, SURFACE MOUNT, PLASTIC PACKAGE-8; CategoryLED optoelectronic/LED photoelectric; File Size154KB，16 Pages; ManufacturerNEC Electronics

Download Datasheet Parametric View All

PS2501L-2-E3-N Overview

Transistor Output Optocoupler, 2-Element, 5000V Isolation, SURFACE MOUNT, PLASTIC PACKAGE-8

PS2501L-2-E3-N Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	NEC Electronics
package instruction	SURFACE MOUNT, PLASTIC PACKAGE-8
Reach Compliance Code	compliant
Other features	UL RECOGNIZED
Coll-Emtr Bkdn Voltage-Min	80 V
Configuration	SEPARATE, 2 CHANNELS
Nominal current transfer ratio	80%
Maximum dark power	100 nA
Maximum forward current	0.08 A
Maximum insulation voltage	5000 V
JESD-609 code	e0
Number of components	2
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Optoelectronic device types	TRANSISTOR OUTPUT OPTOCOUPLER
Terminal surface	Tin/Lead (Sn/Pb)

Preview

Download Datasheet

View All

DATA SHEET

PHOTOCOUPLER

PS2501-1,-2,-4,PS2501L-1,-2,-4

HIGH ISOLATION VOLTAGE

SINGLE TRANSISTOR TYPE

MULTI PHOTOCOUPLER SERIES

DESCRIPTION

The PS2501-1, -2, -4 and PS2501L-1, -2, -4 are optically coupled isolators containing a GaAs light emitting diode

and an NPN silicon phototransistor.

The PS2501-1, -2, -4 are in a plastic DIP (Dual In-line Package) and the PS2501L-1, -2, -4 are lead bending type

(Gull-wing) for surface mount.

−NEPOC

Series−

FEATURES

• High isolation voltage (BV = 5 000 Vr.m.s.)

• High collector to emitter voltage (V

CEO

= 80 V)

• High-speed switching (t

= 3

s TYP., t

= 5

s TYP.)

• Ordering number of tape product: PS2501L-1-E3, E4, F3, F4, PS2501L-2-E3, E4

• Safety standards

• UL approved: File No. E72422

PIN CONNECTION

(Top View)

PS2501-1, PS2501L-1

1. Anode

2. Cathode

3. Emitter

4. Collector

APPLICATIONS

• Power supply

• Telephone/FAX.

• FA/OA equipment

• Programmable logic controller

PS2501-2, PS2501L-2

1, 3. Anode

2, 4. Cathode

5, 7. Emitter

6, 8. Collector

PS2501-4, PS2501L-4

16 15 14 13 12 11 10 9

2 3 4 5 6 7 8

1, 3, 5, 7. Anode

2, 4, 6, 8. Cathode

9, 11, 13, 15. Emitter

10, 12, 14, 16. Collector

The information in this document is subject to change without notice. Before using this document, please confirm that

this is the latest version.

Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices

representative for availability and additional information.

Document No. PN10225EJ02V0DS (2nd edition)

Date Published April 2005 CP(K)

Printed in Japan

The mark

shows major revised points.



NEC Compound Semiconductor Devices, Ltd. 1988, 2005
