BAS16SL — Small Signal Diodes
October 2010
BAS16SL
Small Signal Diodes
Features
•
•
•
•
•
Low Forward Voltage Drop
Fast switching
Very Small and Thin SMD package
Profile height, 0.43mm max
Footprint, 1.0 x 0.6mm
1
Connection Diagram
2
2
SOD-923F
Marking: AB
1
Absolute Maximum Ratings *
Symbol
V
RRM
I
F(AV)
I
FSM
T
J,
T
STG
T
A
= 25°C unless otherwise noted
Parameter
Maximum Repetitive Reverse Voltage
Average Rectified Forward Current
Forward Surge Current
(8.3mS Single Half Sine-Wave)
Operating Junction & Storage Temperature Range
Value
85
150
500
-55 to +150
Unit
V
mA
mA
°C
* These ratings are limiting values above which the serviceability of the diode may be impaired.
The factory should be consulted on applications involving pulsed or low duty cycle operations.
Thermal Characteristics
Symbol
P
D
Power Dissipation
Parameter
Value
227
520
Unit
mW
°C/W
Thermal Resistance, Junction to Ambient
*
R
θJA
* Minimum land pad.
Electrical Characteristics
Symbol
V
R
V
F
T
A
=25°C unless otherwise noted
Parameter
Breakdown Voltage
Forward Voltage
Test Conditions
I
R
= 100μA
I
F
= 1mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
V
R
= 75V
V
R
= 25V@150°C
V
R
= 75V@150°C
V
R
= 0, f = 1.0MHz
Min.
85
Max.
715
855
1.0
1.25
1.0
30
50
8.0
2.0
Unit
V
mV
mV
V
V
μA
μA
μA
nS
pF
I
R
Reverse Leakage
trr
C
j
Reverse Recovery Time I
F
= I
R
= 10mA, irr = 0.1I
R
Junction Capacitance
© 2010 Fairchild Semiconductor Corporation
BAS16SL Rev. A3
1
www.fairchildsemi.com
BAS16SL — Small Signal Diodes
Physical Dimensions
SOD-923F
0.90 - 1.10
0.27
0.17
0.82
A
0.75 - 0.85
B
0.55 - 0.65
0.08 A B
2X
0.05 - 0.15
TOP VIEW
LAND PATTERN RECOMMENDATION
0.32
0.28
0.43 Max
0.08 - 0.14
0.39 - 0.41
0.05
0.00
SEATING PLANE
SIDE VIEW
END VIEW
0.26
0.10
0.15
0.05
BOTTOM VIEW
NOTES:
A) THIS PACKAGE DOES NOT COMPLY
TO ANY CURRENT PACKAGING STANDARD.
B) ALL DIMENSIONS ARE IN MILLIMETERS.
C) BODY DIMENSIONS ARE INCLUSIVE OF BURRS, AND
MOLD FLASH.
D) DIMENSIONS AND TOLERANCES PER ASME Y14.5M, 1994
E) LANDPATTERN BASED ON NOMINAL PACKAGE
DIMENSIONS.
F) DRAWING FILE NAME : SOD923F1REV2
Dimensions in Millimeters
© 2010 Fairchild Semiconductor Corporation
BAS16SL Rev. A3
3
www.fairchildsemi.com
TRADEMARKS
