BAS81, BAS82, BAS83
www.vishay.com
Vishay Semiconductors
Small Signal Schottky Diodes
FEATURES
• Integrated
discharge
protection
ring
against
static
• Low capacitance
• Low leakage current
• Low forward voltage drop
• Very low switching time
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
MECHANICAL DATA
Case:
MiniMELF (SOD-80)
Weight:
approx. 31 mg
Cathode band color:
black
Packaging codes/options:
GS18/10K per 13" reel (8 mm tape), 10K/box
GS08/2.5K per 7" reel (8 mm tape), 12.5K/box
APPLICATIONS
• HF-detector
• Protection circuit
• Diode for low currents with a low supply voltage
• Small battery charger
• Power supplies
• DC/DC converter for notebooks
PARTS TABLE
PART
BAS81
BAS82
BAS83
TYPE DIFFERENTIATION
V
R
= 40 V
V
R
= 50 V
V
R
= 60 V
ORDERING CODE
BAS81-GS18 or BAS81-GS08
BAS82-GS18 or BAS82-GS08
BAS83-GS18 or BAS83-GS08
CIRCUIT CONFIGURATION
Single
Single
Single
REMARKS
Tape and reel
Tape and reel
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse voltage
Peak forward surge current
Repetitive peak forward current
Forward continuous current
t
p
= 1 s
TEST CONDITION
PART
BAS81
BAS82
BAS83
SYMBOL
V
R
V
R
V
R
I
FSM
I
FRM
I
F
VALUE
40
50
60
500
150
30
UNIT
V
V
V
mA
mA
mA
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
Junction temperature
Storage temperature range
TEST CONDITION
On PC board
50 mm x 50 mm x 1.6 mm
SYMBOL
R
thJA
T
j
T
stg
VALUE
320
125
-65 to +150
UNIT
K/W
°C
°C
Rev. 2.0, 02-Jun-17
Document Number: 85509
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAS81, BAS82, BAS83
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
F
= 0.1 mA
SYMBOL
V
F
V
F
V
F
I
R
C
D
MIN.
TYP.
MAX.
330
410
1000
200
1.6
UNIT
mV
mV
mV
nA
pF
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
I
F
= 1 mA
I
F
= 15 mA
Reserve current
Diode capacitance
V
R
= V
Rmax.
V
R
= 1 V, f = 1 MHz
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
P
R
- Reverse Power Dissipation (mW)
14
V
R
= 60
V
1000
I
F
- Forward Current (mA)
12
R
thJA
= 540 K/W
10
8
6
P
R
Limit
at 100
V
V
P
R
- Limit
at 100 %
%
R
R
4
P
R
- Limit at 80 %
V
R
2
0
25
50
75
100
125
150
100
T
j
= 125 °C
10
T
j
= 25 °C
1
0.1
0.01
0
15796
0.5
1
1.5
2.0
15794
T
j
- Junction Temperature (°C)
V
F
- Forward
Voltage
(V)
Fig. 1 -
Max. Reverse Power Dissipation vs.
Junction Temperature
1000
Fig. 3 -
Forward Current vs. Forward Voltage
2.0
C
D
- Diode Capacitance (pF)
V
R
=
V
RRM
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
f = 1 MHz
I
R
- Reverse Current (µA)
100
10
1
0.1
25
15795
0
50
75
100
125
150
15797
0.1
1
10
100
T
j
- Junction Temperature (°C)
V
R
- Reverse
Voltage
(V)
Fig. 2 -
Reverse Current vs. Junction Temperature
Fig. 4 -
Diode Capacitance vs. Reverse Voltage
Rev. 2.0, 02-Jun-17
Document Number: 85509
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAS81, BAS82, BAS83
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
MiniMELF (SOD-80)
Vishay Semiconductors
Cathode indentification
*
0.47 (0.019) max.
3.7 (0.146)
3.3 (0.130)
* The gap between plug and glass can
be either on cathode or anode side
Foot print recommendation:
2.5 (0.098) max.
1.6 (0.063)
1.4 (0.055)
1.25 (0.49) min.
Document no.:6.560-5005.01-4
Rev. 8 - Date: 07.June.2006
96 12070
5 (0.197) ref.
Rev. 2.0, 02-Jun-17
Document Number: 85509
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
2 (0.079) min.
