Data Sheet No. 2C5109
Chip Type 2C5109
Geometry 1007
Polarity NPN
Generic Packaged Parts:
2N5109
Chip type
2C5109
by Semicoa Semi-
conductors provides performance
similar to these devices.
Part Numbers:
Product Summary:
APPLICATIONS:
Designed for broadband applications. Us-
able as high frequency current mode
switch to 200 mA.
Features:
Special Characteristics
ft = 1200 MHz (typ) at 50 mA/15V
2N5109,
2N5109UB, SD5109, SD5109F,
SQ5109, SQ5109F
Mechanical Specifications
Metallization
Bonding Pad Size
Die Thickness
Chip Area
Top Surface
Top
Backside
Emitter
Base
Al - 15 kÅ min.
Au - 6.5 kÅ nom.
3.4 mils x 3.0 mils
3.4 mils x 3.0 mils
8 mils nominal
15 mils x 20 mils
Silox Passivated
Electrical Characteristics
T
A
= 25
o
C
Parameter
BV
CER
BV
CEO
I
CEO
I
EBO
h
FE1
h
FE2
Test conditions
I
C
= 5.0 mA, R
BE
= 10 Ohms
I
C
= 5.0 mA
V
CE
= 15 V dc
V
BE
= 3.0 V dc
I
C
= 360 mA, V
CE
= 3.0 V dc
I
C
= 50 mA, V
CE
= 15 V dc
Min
40
20
---
---
5.0
40
Max
---
---
20
100
---
120
Unit
V dc
V dc
µA
µA
---
---
Due to limitations of probe testing, only dc parameters are tested. This must be done with pulse width less
than 300 µs, duty cycle less than 2%.
